Johnson Controls MP-802 PG+ Manual de usuario

D-308439 MP-802 PG+ Rev.0

MP-802 PG+ Wireless PIR Motion Detector

Installation Guide

Installation guidelines

The reference to MP-802 PG+ throughout this manual includes the model MP-802 P9M0.

CAUTION:

Only qualified personnel may install this equipment. Place this device in non-

hazardous indoor locations only.

Important:

Check the device and the entire alarm system weekly to ensure optimal

performance.

Note:

Tocomply with FCCandISED Canada RFexposure compliance requirements, locate

the device at a distance of at least 20 cm from all persons during normal operation. Do not

co-locate the antennas used for this product, or operate them in conjunction with any other

antenna or transmitter.

Figure 1: MP-802 PG+

Callout

Description

Lens

Battery pull-tab

Enroll button

Tamper switch

For more information refer to About MP-802 PG+.

*D-308439*

D-308439

D-308439 MP-802 PG+ Rev.0

Figure 2: Optimizing detection and avoiding false alarms

Do not install near high-voltage electrical lines.

Keep away from heat sources.

Do not install outdoors.

Avoid direct sunlight.

Do not expose to air drafts.

Do not install behind partitions.

Do not mount on an unstable surface.

Install on a solid and stable surface at a height of 1.8 m to 2.4 m (6 ft. to 8 ft.)

Warning!

Do not obscure partially or completely the device's field of view.

2 MP-802 PG+ Wireless PIR Motion Detector Installation Guide

D-308439 MP-802 PG+ Rev.0

Enrolling the device

Refer to the control panel installation manual for the complete set of enrollment instructions

and testing procedures.

From the

Installation

menu, enter the

Device enrollment

menu and select the option to add

a new device.

Remove the battery pull-tab to power on the device and begin the auto-enrollment process.

If the battery pull-tab is not available or if the device does not automatically enroll, open the

device cover to trigger the enrollment. Alternatively, press the enroll button until the yellow

LED light turns on. See Figure 1 C.

If requested, enter the PIN code printed on the device label.

To manually enroll the device:

Scan the QR Code on the device box, using the IQ4 camera if available, or see step b.

Manually enter the device ID, printed on the product label, in the format ID:125-xxxx.

Note:

If the device has been powered up for more than 2 hours it will be identified by

the system only after the device has been reset.

The MP-802 PG+ is enrolled with device ID 125-XXXX. In fall back mode it enrolls as MP-802

K9-85 PG2 with device ID 126-XXXX.

Select the desired zone.

Configure any device parameters that are required.

Mount and test the device. See Local diagnostics test for information on testing the device.

MP-802 PG+ Wireless PIR Motion Detector Installation Guide 3

D-308439 MP-802 PG+ Rev.0

Configuring the device parameters

1. Enterthe

DEVICESETTINGS

menu and select the required configuration asdescribed inthe

following table.

Table 1: Configuration options

Option

Action

Alarm LED

Define whether the alarm LED indication will be activated.

Optional settings:

LED ON

(default) and

LED OFF

Event counter

Define whether an alarm will be activated upon continued

motion (low sensitivity) or upon a single alarm event (high

sensitivity).

Optional settings:

LOW sensitivity

(default) and

HIGH

sensitivity

Disarm activity

Define whether the device is active when the system is

disarmed.

Optional settings:

NOT Active

(default),

no delay

5 s delay

15 s delay

30 s delay

1 min delay

2 min delay

5 min delay

10 min delay

20 min delay

and

60 min delay

VERY HOT > 35°C [>95°F]

Define whether or not the control panel will report a very

hot alert when the temperature rises above the threshold

value for at least the

Alert Delay

duration value. Alert restore

will occur when the temperature drops 1°C (1.8°F) below the

threshold for at least the

Restore Delay

duration.

Note:

The default threshold value for very hot is 35°C

(95°F).

Optional settings: See Configuring the Temperature Alerts.

COLD < 19°C [<66°F]

Define whether or not the control panel reports a cold alert

when the temperature drops below the threshold value for at

least the

Alert Delay

duration. Alert restore occurs when the

temperature rises 1°C (1.8°F) above the threshold for at least

the

Restore Delay

duration.

Note:

The default threshold value for cold is 19°C (66°F).

Optional settings: See Configuring the Temperature Alerts.

4 MP-802 PG+ Wireless PIR Motion Detector Installation Guide

D-308439 MP-802 PG+ Rev.0

Table 1: Configuration options

Option

Action

FREEZING < 7°C [<45°F]

Define whether or not the control panel will report a freezer

alert when the temperature drops below the threshold value

for at least the

Alert Delay

duration. Alert restore will occur

when the temperature rises 1°C (1.8°F) above the threshold

for at least the

Restore Delay

duration.

Note:

The default threshold value for freezing is 7°C

(45°F).

Optional settings: See Configuring the Temperature Alerts.

FREEZER > -10°C [<14°F

Define whether or not the control panel will report a freezer

alert when the temperature rises above the threshold value

for at least the

Alert Delay

duration. Alert restore will occur

when the temperature drops 1 °C (1.8 °F) below threshold for

at least the

Restore Delay

duration.

Note:

The default threshold value for freezer is -10°C

(14°F).

Optional settings: See Configuring the Temperature Alerts.

MP-802 PG+ Wireless PIR Motion Detector Installation Guide 5

D-308439 MP-802 PG+ Rev.0

Configuring the temperature alerts

You can configure the temperature alerts with the settings described in the following table.

Table 2: Temperature alert configuration options

Option

Action

Threshold

Displays the last saved threshold value and provides the

installer with the ability to change the value using the back or

next button.

Disable/Enable

Define whether the panel reports an alert or not.

Alert delay

Define the amount of time the panel waits before an alert is

reported when the temperature exceeds the defined default.

The alert delay time values are:

Immediately

1 min

2 min

min

(default),

15 min

20 min

30 min

Restore delay

Define the amount of time the panel waits before an alert is

reported when the temperature exceeds the defined default.

The restore delay time values are:

Immediately

1 min

2 min

10 min

(default),

15 min

20 min

30 min

6 MP-802 PG+ Wireless PIR Motion Detector Installation Guide

D-308439 MP-802 PG+ Rev.0

Installing the pet mask

Install the pet mask if you require pet immunity. The optimal installation height for pet immunity is

2.1

m (7 ft.). Pet immunity is for pets weighing up to 38 kg (85 lb).

Note:

Pet immunity is not supported at heights of 2.4 m (7.87 ft.) and above. Do not install the

pet mask if you are mounting the device at this height or above.

To open the device cover, use a screwdriver to loosen the cover screw located on the

underside of the device. See A1 in the following figure. Press the snap to separate the base

from the cover. See A2 in the following figure.

Figure 3: Device cover removal

Insert the tabs at the base of the pet mask into the bottom holes and align the tabs on the

sides with the holes on both sides. See the following figure.

Press down gently to install the pet mask.

Figure 4: Installing the Pet Mask

To close the device cover, clip the cover onto the device base and tighten the cover screw. See

the following figure.

MP-802 PG+ Wireless PIR Motion Detector Installation Guide 7

D-308439 MP-802 PG+ Rev.0

Figure 5: Closing the device cover

8 MP-802 PG+ Wireless PIR Motion Detector Installation Guide

D-308439 MP-802 PG+ Rev.0

Removing the pet mask

Remove the pet mask if you do not require pet immunity.

Open the device cover. See Figure 3.

Remove the tabs at the side of the pet mask from both holes and gently lift the pet mask out

from the bottom holes. See the following figure.

Figure 6: Removing the Pet Mask

Close the device cover. See Figure 5.

MP-802 PG+ Wireless PIR Motion Detector Installation Guide 9

D-308439 MP-802 PG+ Rev.0

Mounting the device using tape

Peel the release liners off the two strips of double-sided adhesive tape and attach the tape to

the back of the bracket.

See Figure 7 A for flat surface mounting and B for corner surface mounting.

Figure 7: Double-sided adhesive tape placement on the bracket

For corner surface mounting, ensure the corner mounting insert is attached to the back of

the corner bracket. See Figure 10 B.

Mount the bracket on the wall.

Align the device with the bracket. See A1 in the figure below.

Slide the device upward until a click is heard. See A2 and A3 in the figure below.

Figure 8: Attaching the device to the flat bracket

10 MP-802 PG+ Wireless PIR Motion Detector Installation Guide
