VA9905 Actuator and

VG1600 Series Six-Way Valves

Installation Instructions

14-88360-03206, Rev. A

Contents

Compliance Information............................................................................1

About This Document ...............................................................................1

Accessories ..............................................................................................1

Support Information..................................................................................1

Parts Included...........................................................................................2

Tools Required..........................................................................................2

Flow Disk Set............................................................................................3

Installing the Six-Way Valve to a System .................................................4

Clearance Required to Install an Actuator ................................................4

Attaching the Actuator to the Six-way Valve .............................................5

Setting the DIP Switches..........................................................................6

Wiring the Actuator ...................................................................................6

Manual Override and Flow Direction ........................................................7

VA9905 Technical Specications..............................................................8

VG1600 Valve Series Technical Specications ........................................9

Compliance Information

IMPORTANT:Use this VA9905 Actuator only to control equipment under normal operating conditions.

Where failure or malfunction of the VA9905 Actuator could lead to personal injury or property damage to the con-

trolled equipment or other property, additional precautions must be designed into the control system. Incorporate

and maintain other devices, such as supervisory or alarm systems or safety or limit controls, intended to warn of or

protect against failure or malfunction of the device.

IMPORTANT : Utiliser ce [nom complet de l’appareil] uniquement en tant que dispositif de contrôle de

fonctionnement. Lorsqu’une défaillance ou un dysfonctionnement du [nom abrégé de l’appareil] risque de

provoquer des blessures ou d’endommager l’équipement contrôlé ou un autre équipement, la conception du

système de contrôle doit intégrer des dispositifs de protection supplémentaires. Veiller dans ce cas à intégrer de

façon permanente d’autres dispositifs, tels que des systèmes de supervision ou d’alarme, ou des dispositifs de

sécurité ou de limitation, ayant une fonction d’avertissement ou de protection en cas de défaillance ou de

dysfonctionnement du [nom abrégé de l’appareil].

About This Document

This guide describes how to install and congure the VA9905 Actuator and Six-Way Valve. The procedures in this

guide must be completed sequentially, as they are listed.

Accessories (order separately)

Code Number Name Description

VG1600-01 Wall Mounting Bracket Kit Provides a mounting bracket for the VA9905 Actuator.

VG1600-02 Flow Disk Kit Provides replacement ow disks.

VG1600-03 Insulation Shell Kit Provides valve insulation.

VG1600-04 Sweat Union Fitting Kit Provides sweat union ttings.

M9300-100 Conduit Adapter Kit (5 per kit) Provides a conduit adapter that protects the input cable.

Support Information

European Single Point of Contact: NA/SA Single Point of Contact: APAC Single Point of Contact:

Johnson Controls Johnson Controls Johnson Controls

Westendhof 3 507 E Michigan Street C/O Controls Product Management

45143 Essen Milwaukee WI 53202 No. 22 Block D, New District

Germany USA Wuxi Jiangsu Province 214142

China

14-88360-03206, Rev. A

Parts Included

Tools Required

• 8mm (5/16 in) slotted screwdriver

or a TORX® T-20 driver

Two Flow Disk Sets

VA9905 Actuator VG1600 Series Valve

Two Ring Nuts

14-88360-03206, Rev. A

Disk Storage

Disassembly

123

1234

Flow Disk Set

Note: Use blue restriction disks with cold water and red disks with hot water only.

Flow restriction disks have markings that indicate the rate of restriction they provide.

Using the supplied restriction disks, you can set the following ow rates in ports 4 and 6:

Disk Opening Smallest Small Medium Largest No disk

CV 0.7 1.2 1.9 2.9 3.9

Kv 0.63 1.0 1.6 2.5 3.3

Installation

14-88360-03206, Rev. A

Installing the Six-way Valve to a System

Note: Source 1 and 2 can be used for hot or cold water.

Attaching the Actuator to the Six-Way Valve

Valve port Description Analog Input Control

1 Source 1 supply Controlled by the gray wire

2 Coil supply

3 Coil return

4 Source 1 return Controlled by the gray wire

5 Source 2 supply Controlled by the orange wire

6 Source 2 return Controlled by the orange wire

The diagram below illustrates the input and output ows for the 6-way valve. Use this diagram as a guide on how to

install the 6-way valve to your system.

Note: Valve port 2 must only be used as coil supply. Valve port 3 must only be used as coil return.

Clearance Required to Install an Actuator

The diagrams below illustrate the clearance required to install an actuator to the VG1600 Valve Series.

100 mm (3 -15/16 in.)

89 mm

(3 - 1/2 in.)

75 mm

(2 - 15/16 in.)

150 mm (5 - 29/32 in.)66 mm (2 - 19/32 in.)

114 mm

(4 - 31/64 in.)

14-88360-03206, Rev. A

Attaching the Actuator to the Six-Way Valve

Use the valve key to adjust the valve stem

to a 90° angle, away from the curved section.

Ensure the valve stem is aligned as shown.

Press the manual override button on the actuator.

AC 24 V

DC 0

(2)

.10V

BLK

RED

GRY

ORN

Move the actuator lever to the extreme right position.

Align the top of the 6-way valve to the plate

at the back of the actuator.

Use a slotted screwdriver or a TORX® T-20 driver to

tighten the actuator screw to the 6-way valve. Tighten

to a torque of 0.9 to 1.4 Nm (8 to 12 lb-in).

Note: The VA9905 Actuator ts VG1600 series valves only.

14-88360-03206, Rev. A

Setting the DIP Switches

AC 24 V

DC 0(2).10V

BLK

RED

GRY

ORN

12345 67

AC 24 V

DC 0

(2)

.10V

BLK

RED

GRY

ORN

12345 67

OFF

Remove the dip switch cover by placing your

nger behind it and pulling it toward yourself.

You now have access to the actuator dip switches.

If the controller output signal range is:

• 2 to 10 V: Push dip switch 1 to the ON position.

-or-

• 0 to 10 V: Push dip switch 1 to the OFF position.

Wiring the Actuator

Wire Color Input

Black Com 24 V AC\DC

Red ~(+)

Gray (Source 1 control) Y1 DC 0(2)...10 V

Orange (Source 2 control) Y2

Risk of electric shock.

Disconnect the power supply before making electrical connections to avoid electric shock.

Risque de décharge électrique.

Débrancher l’alimentation avant de réaliser tout raccordement électrique an d’éviter tout risque de décharge électrique.

Wire the VA9905 Actuator as described in the table below:

12345 67

OFF

CAUTION

ATTENTION

14-88360-03206, Rev. A

Risk of electric shock.

Disconnect the power supply before making electrical connections to avoid electric shock.

Risque de décharge électrique.

Débrancher l’alimentation avant de réaliser tout raccordement électrique an d’éviter tout risque de décharge électrique.

Wire the VA9905 Actuator as described in the table below:

Manual Override and Flow Direction

The manual override lever is used to indicate which ports are in use.

In the absence of power to the actuator, manually set the pointer to the desired position to regulate the ow of the

valve.

Note: The setup procedure described in the Attaching the Actuator to a Six-way Valve section sets ports 1 and 4 to full

ow.

Note: The ball valve and actuator pointer rotate in opposite directions.

The following illustrations indicate lever position and ow:

Full Flow on ports 5 and 6 No Flow Full Flow on Ports 1 and 4

When no actuator is installed, use the following positions of the stem to set the ow of the valve:

Note: The cuts on the valve stem indicate the ports inside the valve.

Full Flow on Ports 5 and 6 No Flow Full Flow on Ports 1 and 4

14-88360-03206, Rev. A

VA9905 Actuator Technical Specications

Product description VA9905-KGA-1: Proportional mode, VA9905-KGA-2: Proportional mode

Power requirements AC 24 V ±20% at 50/60 Hz, Class 2 (North America) or SELV (Europe), 5.2 VA Running;

DC 24 V ±10% Class 2 (North America) or SELV (Europe), 1.1 W Running.

Transformer sizing

requirements

≥6 VA

Input signal/adjustments 0 (2) to 10 VDC or 0 (4) to 20 mA with eld furnished 500 ohm 1/4 W resistor

Control impedance 100k ohm

Rotation rate 1.5 ° per second

Cycles 60,000 full stroke cycles; 2,500,000 repositions

Audible noise <35 dBA at 1 m (39-13/32 in.)

Electrical connections -1 halogen-free

1.2 m (48 in.) halogen free cable with

0.82 mm² (18 AWG) conductors and

6 mm (0.25 in.) ferrule ends

-2 plenum-rated

3.05 m (120 in.) UL 444 type CMP plenum

rated cable with 0.75 mm² (19 AWG cable)

conductors and 6 mm (0.25 in.) ferrule ends

Conduit connections 13 mm NPSM (1/2 in.) threaded conduit connectors with M9300-100 conduit

Ambient conditions Operating: 0 to 60°C (32 to 140°F), 90% RH, noncondensing

Storage: -40 to 85°C (-40 to 185°F), 95% RH, noncondensing

Enclosure IP54/NEMA 5

Dimensions VA9905 Actuator: Width: 89 mm (3-1/2 in.), Height: 74 mm (2-15/16 in.), Length: 170

mm (5-11/16 in.)

Shipping weight Valves:

• VG1611AF: 0.7 Kg (1.55 lbs)

• VG1641AF: 0.8 Kg (1.85 lbs)

• VG1671AF: 1 Kg (2.20 lbs)

Actuator

• VA9905: 0.8 Kg (1.75 lbs)

Compliance United States: UL Listed, CCN XAPX, File E27734; to UL 60730-1: Automatic Electrical

Controls for Household and Similar Use, Part 1; and UL 60730-2-14: Part 2, Particular

Requirements for Electric Actuators. Plenum Rated (UL 2043). Suitable for use in Other

Environmental Air Space (Plenum) in accordance with section 300.22 (c) of the National

Electrical Code.

Canada: UL Listed, CCN XAPX7, File E27734; to CAN/CSA E60730-1:02: Automatic

Electrical Controls for Household and Similar Use, Part 1; and CAN/CSA-E60730-2-14,

Particular Requirements for Electric Actuators.

Europe:

CE Mark—Johnson Controls declares that this product is in compliance with the

essential requirements and other relevant provisions of the EMC Directive.

IEC 60730-1: Automatic Electrical Controls for Household and Similar Use, Part 1:

General Requirements and IEC 60730-2-14, Automatic Electrical Controls for Household

and Similar Use; Part 2—Particular Requirements for Electric Actuators

Australia and New Zealand: RCM—Australia/NZ Emissions Compliant

The performance specications are nominal and conform to acceptable industry standard. For application at conditions beyond

these specications, consult the local Johnson Controls ofce. Johnson Controls shall not be liable for damages resulting from

misapplication or misuse of its products.

14-88360-03206, Rev. A

VG1600 Valve Series Technical Specications

Total operation angle 270°

Sequence 1 0...>90°

Dead band >90…<180°

Sequence 2 >180…270°

Characteristic curve Linear

ID 10,5 mm

Fluid type Water, glycol solutions (max 50%) for HVAC applications

Fluid temperature 5 to 95 °C (41 to 203 °F)

Nominal pressure PN16 (232 psi)

Close off pressure 350 kPa (50 psi)

Max. differential pressure 240 kPa (35 psi)

Range ability 100:1

Max. Cv (Kv) 3.3 (3.8) - ½’’ pipe size

Connections • Valve Body with Male BSPP Thread (external)

• Valve Body with Female NPT Thread (internal

• Sweat Union Fitting kit

Flow coefcient Flow control disk

Leakage rate A, 100,000 cycles in iron-oxide contaminated water and air-bubble-tight (EN 12266-1)

Water quality Iron-oxide contaminated water (900ppm)

Maintenance Maintenance Free

Warranty Minimum 5 years to our customer

The performance specications are nominal and conform to acceptable industry standard. For application at conditions beyond

these specications, consult the local Johnson Controls ofce. Johnson Controls shall not be liable for damages resulting from

misapplication or misuse of its products.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Controladores de Johnson Controls

Johnson Controls

Johnson Controls FAC3613 Manual de usuario

Johnson Controls

Johnson Controls VA-8122 Manual de servicio

Johnson Controls

Johnson Controls FX-PCV1617 Manual de usuario

Johnson Controls

Johnson Controls CK721-A Instrucciones de montaje

Johnson Controls

Johnson Controls VA-77 Series Manual de usuario

Johnson Controls

Johnson Controls Metasys NCE25 series Manual de usuario

Johnson Controls

Johnson Controls EDA-8102 Manual de usuario

Johnson Controls

Johnson Controls A19ZBA Manual de usuario

Johnson Controls

Johnson Controls M9320-AUA-4 Manual de usuario

Johnson Controls

Johnson Controls EDA-8000 Instrucciones de montaje

Johnson Controls

Johnson Controls FA-33-741 Series Manual de usuario

Johnson Controls

Johnson Controls PEAK OEM 18 Manual de usuario

Johnson Controls

Johnson Controls tyco iSTAR Edge G2 Manual del operador

Johnson Controls

Johnson Controls M9108-A-1N Series Manual de usuario

Johnson Controls

Johnson Controls A25 Series Manual de servicio

Johnson Controls

Johnson Controls A350E Manual

Johnson Controls

Johnson Controls VA-8052 Manual de usuario

Johnson Controls

Johnson Controls VA-9070 Series Manual de servicio

Johnson Controls

Johnson Controls NIE29 Series Manual de usuario

Johnson Controls

Johnson Controls EasyIO FW-28 Manual de usuario

Johnson Controls

Johnson Controls SE-SPU101 Series Manual de usuario

Johnson Controls

Johnson Controls Metasys FAC4911 Manual de usuario

Johnson Controls

Johnson Controls FX-PCA2611-0 Manual de usuario

Johnson Controls

Johnson Controls VA9208-GG Series Manual de usuario

Manuales populares de Controladores de otras marcas

Digiplex

Digiplex DGP-848 Instrucciones de funcionamiento

YASKAWA

YASKAWA SGM series Manual de usuario

Sinope

Sinope Calypso RM3500ZB Manual de usuario

Isimet

Isimet DLA Series Style 2 Manual de instalación

LSIS

LSIS sv-ip5a Manual de usuario

Rockwell Automation

Rockwell Automation 1769-L31 Manual de usuario

Airflow

Airflow Uno hab Manual de usuario

ABB

ABB ACS580-01 drives Manual de usuario

Panasonic

Panasonic GM1 Series Manual de usuario

Emerson

Emerson SW93 Manual de usuario

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manual de usuario

Panasonic

Panasonic FP? Positioning Unit RTEX Manual de usuario

Samson

Samson Type 5824 Manual de servicio

Alpha IP

Alpha IP MIOB 21001 Manual de usuario

Siemens

Siemens OpenAir GMA 1 Series Manual de usuario

Surecom

Surecom SR-629 Manual de usuario

Fishman

Fishman TriplePlay Manual de usuario

Regulus

Regulus SRS1 T Manual de usuario
