JBM electronics C102 Manual de usuario

JBM Electronics

Gateway C102/C112

Reference Guide

Gateway C102/C112 Reference Guide Page 2

Table of Contents

1. Items Included in Shipment………………………………………Page 2

2. Installing the Configuration Program……………………………Page 3

3. Information Required……………………………………………..Page 4

4. GWLNX Configuration Procedures…………………………….. Page 5

5. Establishing Console Access to the Unit……………………….Page 24

6. Common Linux Commands………………………………………Page 29

7. Using the NICCFG Script for IP Interface Configuration…….. Page 30

8. Using Zmodem to Transfer Files to the Unit………………….. Page 31

9. Starting the GWLNX Application……………………………….. Page 35

10.Configuring the Auto Start Feature…………………………….. Page 37

11.Troubleshooting, Testing and Statistics……………………….. Page 40

Items Included with Shipment

A. Gateway Unit

B. 9 to 25 Pin DCE Adapter Cable (Ships only with the C100)

C. Power Adapter

D. Console Cable

E. Rubber Feet

F. Manual

Note: Use the picture below for comparison. If any items are missing, please contact

JBM at 1-800-489-7781. (Because the Manual’s appearance can change, it has not

been included in the product picture.)

Gateway C102/C112 Reference Guide Page 3

C102/C112 I/O Diagram

Installing the Configuration Program

The following steps provide information on how to install the Configuration

Program onto your computer. The configuration program is used to create a

configuration file.

1. The Configuration program is available on the JBM website

www.jbmelectronics.com. This program is a self-extracting file.

2. Using the root drive of a DOS compatible PC, execute the zip file that

comes on this CDROM under the ‘Programs’ section. Contact JBM

Electronics customer support to determine if there is an upgrade for the

application.

Important Information: Unless otherwise instructed, use only the default

path and filenames at the root directory of the PC that will be used to

develope and load configurations onto the Gateway Unit. In order to retain

the integrity of all JBM programs, and ensure the proper functioning of the

Gateway Unit(s), default folders and filenames will automatically be

extracted from the configuration program executable as JBMGATEW.

Gateway C102/C112 Reference Guide Page 4

Type SETUP at the \JBMGATEW prompt to initialize the self-extraction of

the sub-directories and associated files.

3. Enter the default User ID and Password, gateway, to enter the

configuration program. This default password must be entered in

lowercase

4. You can find additional information and support on our website:

www.jbmelectronics.com

Gathering Information

Determine what protocols will be used in this config. Select the corresponding

worksheet located on the software CD or at www.jbmelectronics.com. Use this

worksheet as an information-gathering tool. Complete and accurate information

on these sheets is essential to a successful installation.

For the IP interface(s) configuration you will need to have an IP address, default

gateway, and subnet mask assigned by your network staff for the new unit.

Gateway C102/C112 Reference Guide Page 5

Using the Gwlnx Configuration Utility

The JBM Electronics Gateways are used to convert Legacy serial data to IP

protocols. Because of the wide range of parameters that can be selected, JBM

has prepared a walk through to illustrate how the Gateway can be configured.

JBM supplies an offline configuration program that is used to build the

configuration file. The file is then transferred to the Gateway where it is used to

customize the unit to the specific environment.

The following information provides the proper steps and examples of how to build

a configuration converting Bisync 3270 (Host) to TCP (Client) using the

Configuration Utility.

Note: All setup worksheets should be filled out accordingly before configuring

the Gateway!!

You must navigate through all RED FIELDS!!!

At the login screen the default user logon ID and password are “gateway” (please

note that these fields are case sensitive). Press <Enter> after you have

completed these fields. For security purposes the user ID and password can be

changed in the ‘Define Remote Access Information’ section.

Gateway C102/C112 Reference Guide Page 6

You are now at the ‘Main Menu’ screen. Tab the cursor down and select ‘Unit

Configuration’ by pressing <Enter>.

When the selection box appears, select ‘New’ by pressing <Enter> on the field.

This will allow you to begin creating a new configuration to load into the Gateway.

Gateway C102/C112 Reference Guide Page 7

Assign a unique name to describe your configuration. Once you have entered a

name press <Enter> to advance to the next screen.

At this screen select the unit model you will be configuring by tabbing the cursor

to the appropriate field and pressing <Enter>. For example, if you are

configuring a G1000, tab your cursor to ‘Gateway 1000’ and press <Enter>.

Gateway C102/C112 Reference Guide Page 8

At the ‘Unit Parameters’ screen, highlight the ‘Define Remote Access Information’

field and press <Enter>. This will allow you to customize the LAN properties of

the Gateway.

Note: The Define Remote Access Information Field configures the LAN

properties for the Gateway 50 through 80 units only. The Gateway 100 through

900 series and the Gateway 1000’s LAN information is configured at the Linux

prompt by issuing the command niccfg eth0. Once the command has been

issued, you will be prompted to enter the correct IP information. If you are using a

G100-G1000 series unit, simply navigate into the Define Remote Access screen

and then press F12 to return to the Unit Paramters screen leaving the fields on

the Remote Access Information screen blank.

Gateway C102/C112 Reference Guide Page 9

Once returned to the ‘Unit Parameters’ screen, tab down to the ‘Define Port IDs’

field and press <Enter>. This allows you to customize the characteristics

performed by the port controllers of the Gateway.

Assign an identity to each port that you will be configuring. Complete the name

for the port and press <Enter> to continue to the ‘Port Parameters’ screen.

Gateway C102/C112 Reference Guide Page 10

Tab down to the ‘Protocol’ field and press <Enter> to choose the appropriate

protocol for the port controller.

Choose from a list of protocols that are supported by the Gateway. Use the

arrow keys to navigate to the appropriate protocol and press <Enter>. For this

example, select the Bisync 3270 (Host) protocol by highlighting its name and

pressing <Enter> on Bisync 3270 (Host).

The selected protocol determines how the Gateway port will behave. For

example, when Bisync 3270 (Host) is selected, the Gateway port will poll

attached Bisync 3270 protocol terminals.
