jbl on stage micro portable iPod music dock
portable iPod music dock
User Guide
English
Deutsch
Français
Español
Italiano
Dutch
Korean
Danish
Norwegian
Japanese
Simplied Chinese
™*®
iPod not included
2
fcc regulations
FCC Declaration of Conformity Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference; and
(2) this device must accept any interference received, including interference that may cause undesired operation.
Radio and Television Interference
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause interference to radio or television reception, which can be determined by turning the equipment off and then on, the user is encour-
aged to try to correct the interference by one or more of the following measures:
• Increase the separation between the equipment and receiver.
• Connect the equipment to a different outlet so that the equipment and receiver are on different branch circuits.
• Consult the dealer or an experienced radio/TV technician for help.
Changes or modications not expressly approved by JBL could void the user’s authority to operate the equipment.
3
jbl on stage micro safety instructions
Please read the following precautions before use:
• Read instructions. All safety and operating instructions should be read thoroughly before attempting to operate this audio system.
• Retain instructions for future reference.
• Heed warnings. All warnings on this audio system and in the operating instructions should be adhered to.
• Follow instructions. All operating and use instructions should be followed.
• TO PREVENT THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER (OR BACK). THERE ARE NO USER-SERVICEABLE PARTS INSIDE THIS UNIT.
PLEASE REFER SERVICING TO QUALIFIED JBL SERVICE PERSONNEL.
• Do not expose the speakers to liquid or solvent.
• Never remove grille covers in order to service the speaker system. The speaker system does not contain any user-serviceable parts. Refer all servicing to the JBL
Technical Support Group.
• Do not expose the speaker system to temperature or humidity extremes, direct sunlight, excessive dust or vibrations.
• Place the speaker system on a stable, level surface. Do not drop, apply excessive force to the controls or put heavy objects on top of the speaker.
• If cleaning is required, use a soft, dry cloth. If necessary, use a damp cloth without any solvents.
• In order to protect the speaker system, avoid microphone feedback, continuous output from electronic musical instruments or distorted output from any
signal source.
• Do not place the speakers close to uorescent light sources or neon light xtures.
• Although the speakers are magnetically shielded, keep magnetic storage media (disks and tapes) at least four inches from the speaker system in order to avoid
data loss.
• WARNING: To reduce the risk of re or electric shock, do not expose this speaker system to rain or moisture.
• Use only JBL-approved power supplies listed on the product label.
™*
4
jbl on stage micro easy setup guide
Step 1. Unpack JBL On Stage
Micro, adapters, remote control
and input cable. Read these
instructions completely.
Step 2. Move the battery door to
the unlocked position to open
the battery compartment.
Step 3. Place four AAA batteries
in the battery compartment.
+
-
-
or
Step 5. Place the appropriate iPod® adapter onto JBL On Stage Micro.
Place your iPod on the docking connector or connect the audio input
cable to the rear of JBL On Stage Micro. Connect the audio cable to
the audio source.
Step 4. Connect the power adapter
plug into the input marked on the
rear of JBL On Stage Micro and
plug the power adapter into a wall
outlet or power strip.
Step 6. Press the Power button
on the back of JBL On Stage
Micro. A green LED will light
when the JBL On Stage Micro
system is on.
_
Step 7. Adjust the volume using
(+) to increase and (–) to decrease.
Press both to mute the JBL On
Stage Micro. Press either button to
unmute.
+
™*
5
troubleshooting your jbl on stage micro
Symptom Possible Problem Solution
Troubleshooting
If you have any questions or need further assistance, please visit www.jbl.com.
These specications are subject to change without notice.
No sound from the JBL
On Stage Micro speaker
system.
™*
JBL On Stage Micro Specications
Frequency Range:
70Hz – 20kHz
Power Consumption:
10W maximum
Power Input:
6V/1.5A
JBL On Stage Micro Transducer:
(2) 1 Full range per channel
Dimensions:
Diameter – 6 (150mm)
Height – 1-3/4 (38mm)
System Weight:
2.22 lb (1.01kg)
Battery:
Size – AAA
Type – Alkaline, NiMh
DO NOT MIX BATTERY TYPES.
DO NOT MIX CHARGED AND
PARTIALLY CHARGED BATTERIES.
BATTERIES WILL NOT RECHARGE
WHILE IN JBL ON STAGE MICRO.
Ensure that the power supply is connected to a live
power source and properly connected to JBL On Stage
Micro. Note: When JBL On Stage Micro is
powered, a green power LED on the JBL On Stage
Micro should light up.
Touch the volume “Up” (+) pad on the volume control
to unmute and/or increase the system volume level.
Note: Touching the volume “Down” (–) pad lowers
the system volume. Touching both the (+) and (–)
volume control pads at the same time will mute the
system.
Increase the volume level on the audio source device.
Replace the batteries.
Press the Play button on the iPod or remote control.
Note: If the iPod is paused more than ten minutes,
press the JBL On Stage Micro Power button to turn
the unit back on. Press either (+) or (–) to unmute.
No power to the system.
Power adapter plug is not
inserted correctly.
No volume or low volume.
Input source is low.
Low or drained batteries.
iPod paused.
iPod paused (battery only
mode).
6
Symptom Possible Problem Solution
Troubleshooting
This product is intended to be supplied by a listed direct plug-in power unit marked Class 2, with output rated 18V AC minimum 2.5A.
JBL On Stage Micro has been muted
for more than ten minutes in the bat-
tery-only mode.
Wall adapter is not plugged into JBL
On Stage Micro correctly.
Wall adapter is not receiving AC power.
No sound from the JBL On Stage
Micro speaker system (continued).
No power; green LED is not on.
Press JBL On Stage Micro Power button to turn the unit
back on. Press either (+) or (–) to unmute.
Check the connection of the wall adapter.
Place the wall adapter in a known powered outlet. Test the
outlet with a lamp or other device.
Connect JBL On Stage Micro to a known audio source. Test
the audio source with headphones.
7
jbl on stage micro remote easy setup guide
1 In the battery-only mode, JBL On Stage Micro will turn off to save battery power when muted or paused for longer than ten minutes.
volume down
iPod play/pause1
iPod previous/rewind
iPod play/iPod scroll up
iPod menu
volume up
JBL On Stage Micro
mute/unmute1
iPod next/fast forward
iPod scroll down
iPod select/enter
™*
Harman Consumer Group, Inc.
8500 Balboa Boulevard, Northridge, CA 91329 USA
1.516.255.4525 (USA only)
www.jbl.com
© 2006 Harman International Industries, Incorporated. All rights reserved.
JBL and Harman International are trademarks of Harman International Industries, Incorporated, registered in the United States and/or other countries.
*The trademark On Stage is used with permission of OSA International, Inc.
iPod is a trademark of Apple Computer, Inc., registered in the U.S. and other countries.
A Harman International®Company
