Jbc DIV-D Series Manual de usuario

Premium Desoldering station

with Pneumatic Pump

Ref. DIV-D

www.jbctools.com

Packing List

The following items should be included:

Stand Cable ................ 2 units

R ef. 0 0112 83

Sponge ............................ 1 unit

Ref. S0354

Metal Brush .................... 1 unit

Ref. CL6217

Pneumatic Desoldering Module ........... 1 unit

Ref. MV-A

Module Cable ................ 1 unit

Ref. 0010207

DI Control Unit ............................................ 1 unit

Ref. DI-1D (120V)

DI-2D (230V)

DI-9D (100V)

Brass wool ...................... 1 unit

Ref. CL6210

Desoldering Iron ........... 1 unit

Ref. DR560-A

Stand ................................ 1 unit

Ref. DR-SD

Power cord .................... 1 unit

Ref. 0009401 (230V)

0009417 (100/120V)

ESD Tip Cleaner ........... 1 unit

Ref. CL8499

Check our website for the corresponding manuals. Also available in other languages.

Union Flanges ............... 1 unit

R ef. 0 0113 5 6

Manual ............................. 1 unit

Ref. 0020513

Suction Filter ................. 1 unit

Ref. 0821830

Cotton Filter ....................1 unit

Ref. 0781046

It contains 10 filters

DR560 Accessories

R ef. 0 010 211

Internal gasket .......... 1 unit

Ref. 0019208

It contains 2 gaskets

Filter Box .................... 1 unit

Ref. 0780840

It contains 10 filters

Spanner ...................... 1 unit

Ref. 0780550

Glass solder

collector ...................... 1 unit

Ref. 0002600

Metal solder

collector ...................... 1 unit

Ref. 0812630

Tips ............................. 3 units

Ref. C560005 (x1)

Ref. C560013 (x1)

Ref. C560004 (x1)

Cleaning stick .................1 unit

Ref. 0786640

Filter Box ..........................1 unit

Ref. 0005966

It contains 50 filters

Tip cleaning set ................................... 1 unit

Ref. 0965970

Long Tip Cleaning set ....................... 1 unit

Ref. 0781137

Premium Desoldering station

with Pneumatic Pump

Ref. DIV-D

www.jbctools.com

Features

Stand Cable

R ef. 0 0112 83

DI Control Unit

Ref. DI-1D (120V)

DI-2D (230V)

DI-9D (100V)

Desoldering Iron

Ref. DR560-A

Suction Filter

Ref. 0821830

Stand

Ref. DR-SD

Pneumatic

Desoldering

Module

Ref. MV-A

Main

Switch

Fuse

Equipotential

connection

Power

Socket

Module Cable

Ref. 0010207

Air pressure range

supply (4 - 6 bar)

6 Bar Max.

Compatibility

* The MN-A Nitrogen Flow Regulator is required.

Select the equipment that best suit your soldering or desoldering needs.

Basic working system Peripherals

Control

Unit Stand Tool Cartridge

Range

MS-A

MV-A MN-A FS500-1A

FS500-2A P-005

DI-D

AD-SD

T210-A C210

T245-A C245

T470 -A C245

DN-SE

T210-NA* C210

T245-NA*

C245

T470 -NA*

AP-SD AP250-A C250

PA-SD PA120-A C120

HT-SD HT420-A C420

DS-SD DS360-A C360

DR-SD DR560-A C560

www.jbctools.com

Fuse

Clean

periodically

Before carrying out maintenance, always allow the equipment to cool.

- Clean the station screen with a glass cleaner or a damp cloth.

- Use a damp cloth to clean the casing and

the tool. Alcohol can only be used to clean the

metal parts.

- Periodically check that the metal parts of the

tool and stand are clean so that the station

can detect the tool status.

- Maintain tip surface clean and tinned prior to

storage in order to avoid tip oxidation.

Rusty and dirty surfaces reduce heat transfer

to the solder joint.

- Periodically check all cables and tubes.

Maintenance

1. Pull off the fuse holder and remove the

fuse. If necessary use a tool to lever it off.

2. Insert the new fuse into the fuse holder

and return it to the station.

- Replace a blown fuse as follows:

- Replace any defective or damaged pieces. Only use original JBC spare parts.

- Repairs should only be performed by a JBC authorized technical service.

It is imperative to follow safety guidelines to prevent electric shock, injury,

fire or explosion.

- Do not use the units for any purpose other than soldering or rework. Incorrect use may cause fire.

- The power cord must be plugged into approved bases. Be sure that it is properly grounded

before use. When unplugging it, hold the plug, not the wire.

- Do not work on electrically live parts.

- The tool should be placed in the stand when not in use in order to activate the sleep mode.

The soldering tip, the metal part of the tool and the stand may still be hot even when the station

is turned off. Handle with care, including when adjusting the stand position.

- Do not leave the appliance unattended when it is on.

- Do not cover the ventilation grills. Heat can cause inflamable products to ignite.

- Avoid the contact of flux with skin or eyes to prevent irritation.

- Be careful with the fumes produced when soldering.

- Keep your workplace clean and tidy. Wear appropriate protection glasses and gloves when

working to avoid personal harm.

- Utmost care must be taken with liquid tin waste which can cause burns.

- This appliance can be used by children over the age of eight and also persons with reduced

physical, sensory or mental capabilities or lack of experience provided that they have been given

adequate supervision or instruction concerning use of the appliance and understand the hazards

involved. Children must not play with the appliance.

- Maintenance must not be carried out by children unless supervised.

Safety

www.jbctools.com

Exploded View

www.jbctools.com

产品中有害物质的名称及含量

有害物质含量表

部件名称

有害物质

铅(Pb) 汞(Hg) 镉(Cd) 六价铬

(Cr(VI))

多溴联苯

(PBB)

多溴二苯醚

(PBDE)

烙铁头 O O O O O O

手柄 O O O O O O

电源线 O O O O O O

主机 O O O O O O

电源插座 O O O O O O

保险丝 O O O O O O

主开关 O O O O O O

电位连接 X O O O O O

变压器 O O O O O O

线路板 X O O O O O

O 表示该有害物质在该部件所有均质材料中的含量均在GB/T 26572 规定的限量要求以下。

X 表示该有害物质至少在该部件的某一均质材料中的含量超出GB/T 26572 规定的限量要求。
