jbc DMPSE-9QB Manual de usuario
Station
More Information at the
product web page
DMPSE
4-Tool Rework Station
This Plug & Play Guide corresponds to the following references:
Ref.
DMPSE-9QB (100 V)
DMPSE-1QB (120 V)
DMPSE-2QB (230 V)
2
Packing List
The following items are included according to purchased station reference:
DR560
Desoldering Iron ................................................................................. 1 unit
Ref. DR560-A
DME
4-Tool Control Unit .................................................................... 1 unit
Ref. DME-9A (100 V)
Ref. DME-1A (120 V)
Ref. DME-2A (230 V)
AM120
Adjustable Micro Tweezers ............................................................. 1 unit
Ref. AM120-A
MSE
Electric Desoldering Module .......................................................... 1 unit
Ref. MSE-A
T245
General Purpose Handle ................................................................. 1 unit
Ref. T245-A
T210
Precision Handle ............................................................................... 1 unit
Ref. T210-A
AMS
Stand for PA120 &
AM120 Micro Tweezers .................................................................... 1 unit
Ref. AM-SB
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm 130 mm
para manuales - color gris
200 mm
300 mm
3
P405
Pedal ...................................................................................................... 1 unit
Ref. P-405
ADS
Stand for T210 & T245 Handles ................................................... 2 units
Ref. AD-SF
DRS
Stand for DR560 ................................................................................. 1 unit
Ref. DR-SF
SCH
Cartridge Holder ................................................................................ 1 unit
Ref. SCH-A
Module Cable
Ref. 0024228
4
Stand Cable
Ref. 0024227
Installation
DRS
Stand for DR560
Desoldering Iron
ADS
Stand for T210 &
T245 Handles
DR560
Desoldering Iron
T245
General Purpose
Handle
DME
4-Tool Control Unit
Stand Cable
Ref. 0024227
MSE
Electric Desoldering Module for DDE
& DME
Suction
Filter
Ref. 0821830
To another peripheral
C245
Cartridge Range*
C560
Tip Range*
Power Cord
Included in DME Control Unit
* Not included, sold separately.
Stand Cable
Ref. 0024227
T210
Precision Handle
C210
Cartridge Range*
Stand Cable
Ref. 0024227
AM120
Adjustable Micro
Tweezers
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm 130 mm
para manuales - color gris
200 mm
300 mm
5
ADS
Stand for T210 &
T245 Handles
AMS
Stand for PA120 &
AM120 Micro Tweezers
P405
Pedal
* Not included, sold separately.
Notes
6
Notes
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm 130 mm
para manuales - color gris
200 mm
300 mm
7
This product should not be thrown in the garbage.
In accordance with the European directive 2012/19/EU, electronic equipment at the end of its life must be collected and returned to an authorized
recycling facility.
Warranty
Get 2 year JBC warranty by registering here:
https://www.jbctools.com/productregistration/
within 30 days of purchase.
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm 130 mm
para manuales - color gris
200 mm
300 mm
DMPSE
4-Tool Rework Station
Ref. DMPSE-9QB (100 V)
Ref. DMPSE-1QB (120 V)
Ref. DMPSE-2QB (230 V)
- Package Dimensions / Weight: 495 x 415 x 395 mm / 17.91 kg
(L x H x W) 19.49 x 16.34 x 15.55 in / 39.48 lb
Complies with CE standards.
ESD safe.
Specifications
0032039-200723
