JAZE HOTSPOT GATEWAY
USER GUIDE
2
Jaze Hotspot Gateway –User Guide
Copyright © 2013 Jaze Networks Pvt Ltd. All rights reserved.
No part of this work may be reproduced, stored in a retrieval system, adopted or transmitted in
any form or by any means: electronic, mechanical, photographic, graphic, optic recording or
otherwise, translated in other language or computer language, without the prior written
permission of Jaze Networks.
The specifications and information regarding the products in this manual are subject to change
without notice. All statements, information, and recommendations in this manual are believed to
be accurate but are presented without warranty of any kind, express or implied. Users must take
full responsibility for their application of any products.
In no event shall Jaze Networks or its suppliers be liable for any indirect, special, consequential,
or incidental damages, including, without limitation, lost profits or loss or damage to data
arising out of the use or inability to use this manual, even if Jaze Networks or its suppliers have
been advised of the possibility of such damages.
Mention of third-party companies and products are for informational purposes only and do not
constitute an endorsement.
CORPORATE HEADQUARTERS
Jaze Networks Private Limited
Plot no 66, Raju Nagar Main Road, Thoraipakkam, Chennai 600097, TN, INDIA
Phone: +91 44 43835031
Email: support@jazenetworks.com
http://www.jazenetworks.com
3
Jaze Hotspot Gateway –User Guide
Table of Contents
Table of Contents.................................................................................................................... 3
Chapter 1 –Getting Started ................................................................................................... 5
1.1 Introduction 5
1.2 Jaze Hotspot Gateway 6
1.3 Jaze Voucher Printer 9
1.4 Physical setup 13
Chapter 2 –Network Setup.................................................................................................. 14
2.1 Default settings 14
2.2 Lan IP setting 15
2.3 Wan IP setting 17
2.4 Configuring DNS 18
2.5 Configuring DHCP server 19
Chapter 3 –System Settings ................................................................................................ 20
3.1 Changing the web GUI protocol and port number 20
3.2 Time settings 21
3.3 Changing administrator account settings 22
3.4 Non-administrator account setup 23
Chapter 4 –Hotspot Setup................................................................................................... 24
4.1 Setting up the captive portal 24
4.2 Setting up bill plans 29
4.2 Creating prepaid plans 30
4.3 Creating postpaid plans 36
4.4 Creating free access plans 43
4.5 Changing captive portal settings 47
4.6 Editing bill plans 51
Chapter 5 –Hotspot Advanced Settings............................................................................. 52
5.1 Auto configuration setup 52
5.2 Currency setup 53
5.3 User ID setup 54
5.4 Access credentials delivery modes 55
5.5 Defining IP addresses for bypassing captive portal 56
5.6 Defining MAC addresses for bypassing captive portal 58
4
Jaze Hotspot Gateway –User Guide
5.7 Defining permanent captive portal user accounts 60
Chapter 6 –Hotspot Operation ........................................................................................... 62
6.1 Creating users 62
6.2 Viewing current users 64
6.3Generating reports 67
Chapter 7 –Voucher Printer Settings.................................................................................. 69
7.1 Mapping Voucher Printer keys to bill plans 69
7.2 Printing vouchers 70
7.3 Billing postpaid users 72
7.4 Viewing statistics 75
7.5 Testing SIM card operations 76
7.6 Accessing help menu 79
Chapter 8 –Customisation ................................................................................................... 80
8.1 Voucher printer generated voucher customisation 80
8.2 PC generated voucher customisation 81
8.3 SMS customisation 82
Chapter 9 –Device Diagnostics............................................................................................ 83
9.1 Viewing system summary 83
9.2 Live monitoring 84
9.3 Viewing logs 86
9.4 Ping and Traceroute 88
9.5 Backing up configuration 90
9.6 Restoring configuration 91
9.7 Upgrading the firmware 92
9.8 Resetting to factory defaults 93
9.9 Rebooting the device 94
Chapter 10 –Command Line Setup ..................................................................................... 95
10.1 Getting connected to the console 95
10.2 Setting up interfaces 97
10.3 LAN IP AND DHCP setup 98
10.4 Reset Web GUI password 99
10.5 Reset to factory defaults 100
10.6 Reboot system 101
10.7 Ping host 102
5
Jaze Hotspot Gateway –User Guide
Chapter 1 –Getting Started
1.1 INTRODUCTION
Jaze Hotspot Gateway is a complete Internet access and billing solution for public hotspots. It has been
specifically designed for use in hotels, coffee shops, restaurants, libraries, airport lounges, etc. Jaze
Hotspot Gateway enables businesses to provide secure and convenient Internet access to its customers by
providing each one of them with a unique username and password. Jaze Hotspot Gateway provides the
following benefits:
Auto Configuration: Guest devices can get connected to the network with any network settings
stored on them even if they are incompatible with the network setup.
Generate instant vouchers: Easily create users with the press of a single button and also send the
credentials via SMS.
Multiple plan types: Create prepaid, postpaid or free access vouchers with fixed expiry date and
usage limits based on time or data transferred.
Bandwidth management: Define the bandwidth limit for upload and download for each plan type.
Customisation: Fully customizable login pages, vouchers and bills with your own logos and brand
name.
The solution comprises of two components:
1. Jaze Hotspot Gateway
2. Jaze Voucher Printer
6
Jaze Hotspot Gateway –User Guide
1.2 JAZE HOTSPOT GATEWAY
FIG 1.1 FRONT SIDE OF JAZE HOTSPOT GATEWAY
Jaze Hotspot Gateway comprises of the following ports:
Printer serial interface: This interface connects to the Jaze Voucher Printer via the serial cable provided. This
interface can also be connected to a COM port on a PC to access the command line interface of the device.
WAN interface: This interface connects to your Internet connection. Plug in the network cable from the
modem or router provided by your ISP into this port.
LAN interface: This interface connects to your wired or wireless network. Plug in the uplink from your existing
network into this port.
USB: This is used for backing up and restoring configuration files and firmware.
Power: Connect the pin from the power adapter provided into this jack.
7
Jaze Hotspot Gateway –User Guide
The Hotspot Gateway can function both with and without the voucher printer.
The WAN interface has been configured to get an IP address automatically from your ISP’s modem or router by
default. In case you have a leased line or if you need to set up a static IP you can do so by using the Web GUI
later.
The LAN interface is configured to assign IP address to clients through DHCP. The default IP address of the LAN
interface is 172.16.1.1. To access the Web GUI of the device, connect directly to the LAN interface with a
network cable to a laptop or PC. The laptop or PC will be assigned an IP address in the range through DHCP.
Once connected you can access the Web GUI of the device by typing in the following into a browser window.
http://172.16.1.1/
This will prompt you with a screen asking you for a username and password to login as show below:
FIG 1.2 WEB GUI ACCESS AUTHENTICATION SCREEN
Log in with the following default username and password:
Username: admin
Password: jaze
Once you have logged in using the default username and password will be able to access the Web GUI of the
device as shown on the next page.
8
Jaze Hotspot Gateway –User Guide
FIG 1.3 WEB GUI OF JAZE HOTSPOT GATEWAY
9
Jaze Hotspot Gateway –User Guide
1.3 JAZE VOUCHER PRINTER
FIG 1.4 JAZE VOUCHER PRINTER
Jaze Voucher Printer works with the Jaze Hotspot Gateway and allows you to print vouchers, send SMS, print
bills and view statistics. It comprises of a keypad with keys as follows:
1. Bill plan mapped keys: These keys can be mapped to a specific bill plans and are used to generate
10
Jaze Hotspot Gateway –User Guide
vouchers based on the bill plan to which they are mapped.
2. Search key: This key is used for searching for vouchers which are currently being used.
3. List key: This key lists all the vouchers that are currently being used.
4. Navigation keys: These keys are used for seleting options on the display by scrolling up or down
through lists.
5. Function keys: These keys perform fuctions based on soft keys displayed on the screen.
6. Statistics keys: These keys are used to display statistics about the number of vouchers created and the
number of vouchers currently connected.
7. Test key: This key is used for performing tests on the SIM card by sending a test SMS or by making a
test call.
8. Help key: This key provides a Help screen which displays the function provided by each key.
