Jacuzzi SWIMSPA Power Pro J19 Manual de usuario

JACUZZI

–

POWER

PRO

Revision 12/12/22

      Smart Tub

Seating Capacity………………….................... 4 Person

Dimensions…………………………....................

220

''X

'' X

'' / (

569

X 2

cm X

cm)

Useable Swim Area Dimensions……………

…

148''or 375 cm

Dry

Weight……………………….......................

2,660

lbs /

207

Filled Weight (Spa Volume) ……................ 22,948 lbs / 10,412 kg

Water Capacity (Spa Volume) …................

378

US gallons /

205

Electronic Controls…………………………………. BP 2100 TRAPEZOID MAIN SWIM SPA Keypad

Pump 1…………………………………………………..

North America (60 Hz):

Speed,

HP, AMPs 1

2.0

/1.0

Europe (50 Hz): 2- Speed, 3 HP, AMPs 10.0/3.0

Pump

2…………………………………………………..

orth America (60 Hz): 2

Speed, 3.5 HP, AMPs 11.4/3.3

Europe (50 Hz): 2- Speed, 3 HP, AMPs 10.2/2.0

Pump 3………………………………………………….. North America (60 Hz): 2- Speed, 3.5 HP, AMPs 11.4/3.3

Europe (50 Hz): 2- Speed, 3 HP, AMPs 10.2/2.0

Pump 4………………………………………………….. North America (60 Hz): 2- Speed, 3.5 HP, AMPs 11.4/3.3

Europe (50 Hz): 2- Speed, 3 HP, AMPs 10.2/2.0

Total Seat Jets……………............................. 28

Seat A Jets…………………………………….. (2)-6015065; (6)-6030076

Seat B Jets…………………………………..... (2)-6030078

Seat C Jets……………………………………… (2)-6015065; (4)-6020079; (6)-6030063; (2)-6020079

Seat D Jets…………………………………….. (2)-6030076; (2)-6030063

Massage Selectors…………………………………. YES

Air Controls……………………………………………. 3

Water Management System…………………… CLEARRAY® Active Oxygen Technology

LED Lighting………………………...................... (4)-20 LED Small Light

Synthetic Cabinet Colours……………………….

Smoked Ebony, Modern Hardwood, Brushed Gray

Acrylic Colours………………………………………. Silver Pearl, Porcelain, Platinum

Headrests……………………………………………….

N/A

Waterfalls………………………………………………. Cascading Laminar Waterfall

Electrical Requirements………………………….

North America (60 Hz): 240 V,

AMP

GFCI

RATED:

AMPs

Europe (50 Hz):230V, 40A or suitably rated circuit breaker to comply with local

lectrical codes.

GFCI RATED:40 AMPs.

RCD breakers with MC.

Warranty………………………………………………. 10/5/3 Year limited

Options/ Special Features………….............. 1) Fitness and Fun:



Aqua Rowing Kit





Jacuzzi Powertone Fitness Kit





48'' Stainless Steel Exercise Bar (Left Side Only)



)Covers



PROLASTTM Five Section Cover



Summer Cover with Tie Downs





Delete Entire Hardcover



Rollaway Cover (Need to Delete Hard Cover)





Bracket for Rollaway Cover



3)Steps:

 5 Tier Aqua Step

4)Cabinet:

 Replace Cabinet add Solid State frame

5)Other Popular Upgrades & Options:

 Auxiliary Heating System By-pass Loop

 GFCI 

 Additional 3KW Heater

Specification

JACUZZI

–

POWER

PRO

Revision 12/12/22

Seat Depth

A = 26.42" (67.10cm) C = 28.44" (72.23cm)

B = 20.76" (52.73cm) D = 21.88" (55.57cm)

LISTED DIMENSIONS REPRESENT DISTANCE FROM THE TOP

OF ACRYLIC TO LOWEST POINT IN THE SEAT. TOLERANCE

±1/16’’ (0.158CM)

ACP

Air controller Pump

BJ- Buoyancy Jet

CHF

Cascading Hydro Falls

Diverter1 : Turn LEFT

to DIVERTER 2, Turn

RIGHT to seat BJ

Massage Selector/Air Control Diagram

ACP 1: Opens/Closes;

Air inlet to all jets in the

seat A, B

Diveter2: Turn jets

ON/OFF in seats A, B,

C, D.

CHF: To turn ON/OFF

Cascading Hydro fall

ACP 3: Opens/Closes;

Air inlet to seats C, D.

ACP 4: Opens/Closes;

Air inlet to all BJ

(Buoyancy jet)

JACUZZI

–

POWER

PRO

Revision 12/12/22

NOTE:

Dimensional tolerances are as follows due to variations in manufacturing:

Length / Width / Height(s): +/- 3/8"

Height Variance (side to side): +/-1/4"

IMPORTANT! Always measure each

swim spa for exact dimensions BEFORE

designing its foundational support

and/or decking

STOP

Dimensions

JACUZZI

–

POWER

PRO

Revision 12/12/22

Year: 2023

Model: Jacuzzi – J19 Power Pro

Size: 220''X 93'' X 53'' / (569 cm X 236 cm X 134 cm)

Series: Jacuzzi Power Pro Series

Main Keypad: BP 2100 TRAPEZOID MAIN SWIM SPA Keypad (7005085)

Spa Pack and

Heater:

5.5 & 3

KW 240 V (NA),

3 &

3 KW 230V (

)

Controller ST2/ST2- ST2C & HPSSW20P NA (60 Hz)

Controller ST2/ST2- ST2C & HPSSW21P EU (50 Hz)

Pump #1:

North America (60 Hz):

SP, 4 HP, AMPs

–

/1.0

(

05155

)

Europe (50 Hz): 2- SP, 3 HP, AMPs – 10.0/3.0 (6510041)

Pump #2:

North America (60 Hz):

SP,

3.5

HP, AMPs

–

1.4/3.3

(65051

)

Europe (50 Hz): 2- SP, 3 HP, AMPs – 10.2/2.0 (6510047)

Pump #3:

North America (60 Hz):

SP,

3.5

HP, AMPs

–

1.4/3.3

(65051

)

Europe (50 Hz): 2- SP, 3 HP, AMPs – 10.2/2.0 (6510047)

Pump #4:

North America (60 Hz):

SP,

3.5

HP, AMPs

–

1.4/3.3

(65051

)

Europe (50 Hz): 2- SP, 3 HP, AMPs – 10.2/2.0 (6510047)

Circulation Pump: N/A

Therapy Jets:

(4)

SMT MICRO JET ASSEMBLY

(

6015065),

(8)- POWER PRO FX JET ASSMEBLY (6030063),

(6)- FXS SPINNER JET ASSEMBLY (6020079),

(8)- POWER PRO RX3 JET ASSMEBLY (6030076),

(2)- FX2 VORTEX III JET ASSEMBLY (6030078),

(2)- MONSOON (WHIRLPOOL) JET (6035065),

(3)- POWERSTORM (OVAL) JET (6035073).

Air Controls: (3) - Jacuzzi Air Control (4525117)

Diverters: (2) - Jacuzzi 2'' Water Diverter (4525113)

Filters: (2) - 50 SQ. FT Filter (4520033)
