OWNER’S MANUAL

MasterSpaParts.com

1DO NOT DIVE.

MASTER SPAS OWNER’S MANUAL

Welcome To Ultimate Relaxation!

Thank you for choosing your new swim spa built by Master Spas. Please read the entire Owner’s

Manual before installing and using your swim spa. The goal of this manual is to provide you with

safety and operational information plus some tips that will help you enjoy your swim spa to its fullest.

At the time of print, this manual is accurate in its information. Master Spas reserves the right

to change or improve its product without prior notice. To check on updates or for other informa-

tion, please visit www.masterspas.com and follow the links to the customer support section.

Record Of Ownership

Name��

Address��

City �� State �� Zip ��

Phone # (��)��-�� Date Purchased �� /�� /��

Model �� Serial #��

Dealer Name ��

Service Tech Rep ��

Serial Number Location

The serial number for your swim spa is located near the filter area, on the spa system pack, or on

the listing plate on the skirting. It will start with “H” followed by a 6 digit number. Ex. H151234

Please be sure to register your swim spa so we can efficiently assist with any questions you may

have. Until your swim spa has been registered, Master Spas Inc. will not have record of your owner-

ship. To register your swim spa, visit www.MasterSpas.com and access our “Customer Support” link

on the page. This area will offer online registration capability along with other support information.

MasterSpaParts.com

2DO NOT DIVE. 2

TABLE OF CONTENTS

Record of Ownership.............................................................................................................. 1

Table of Contents................................................................................................................... 2

Safety Instructions ............................................................................................................ 3-10

Glossary of Swim Spa Terminology.................................................................................. 11-13

Site Preparation / General Guidelines .............................................................................. 14-15

Installation Instructions........................................................................................................ 16

The Advantages of Eco Pur Filtration.................................................................................... 17

Water Chemistry Terms You Should Know ....................................................................... 18-19

Why Are Chemicals Important in a Swim Spa........................................................................ 20

Water Maintenance......................................................................................................... 21-24

Start-Up........................................................................................................................ 21

Schedule.................................................................................................................. 22-23

Troubleshooting Guide.................................................................................................. 24

Regular Maintenance Procedures..................................................................................... 25-29

Swim Spa Troubleshooting Guide .................................................................................... 30-31

Winterizing & Storing Your Swim Spa ................................................................................... 32

Swim Spa Care & Maintenance Record............................................................................. 33-34

Electrical Requirements................................................................................................... 35-40

Configuration 3........................................................................................................ 35-36

Configuration 5........................................................................................................ 37-38

Configuration 7........................................................................................................ 39-40

Model Specifications ............................................................................................................ 41

Spa Controls ................................................................................................................... 42-58

Propulsion System Controls ............................................................................................. 59-69

Propulsion System Technical Information.............................................................................. 70

Deluxe Fusion Air Stereo Option (if equipped) ................................................................. 71-73

Deluxe Fusion BT Stereo Option (if equipped) .................................................................. 74-82

Mast3rPur (if equipped) .................................................................................................. 83-85

MasterSpaParts.com

3DO NOT DIVE.

100DO NOT DIVE.

SAFETY INSTRUCTIONS

SAVE THESE INSTRUCTIONS

Included with your new spa is a safety sign. The sign is for you and your guest’s protection

and is suitable for outdoor use in wet locations. The sign should be placed in a location visible

to all users of the spa.

Please take time to point out the physical location of the safety sign and the importance of

the safety precautions displayed on the safety sign to all of your guests. Remember, your safety

and the safety of anyone who enjoys the use of your spa is our utmost concern.

The sign should be mounted with screws or another type of permanent fastener. Additional

or replacement signs can be obtained from your dealer or direct from the factory.

INTRODUCTION

It’s time to relax! You now have your very own portable spa by Master Spas, Inc. By fully under-

standing the operation of each of the features of your new Master Spa, you will be assured of

many years of hassle-free, hot water therapy and fun.

Your safety is of paramount importance to the MasterSpas family. We urge you to read and

become thoroughly familiar with all safety aspects addressed in this manual.

Through reading and totally understanding the important information in your owner’s manual, you

will realize that you now own THE ULTIMATE RELAXATION MACHINE!

MasterSpaParts.com

4DO NOT DIVE.

101DO NOT DIVE.

SAFETY INSTRUCTIONS

IMPORTANT SAFETY INSTRUCTIONS

When installing and using this electrical equipment, basic safety precautions should

be observed including the following:

READ AND FOLLOW ALL

INSTRUCTIONS

WARNING – To reduce the risk of injury, do not permit children to use this product

unless they are closely supervised at all times.

A wire conductor is provided on this unit to connect a minimum 6 AWG

(13.302mm2) solid copper conductor between this unit and any metal equipment,

metal enclosures of electrical equipment, metal water pipe, or conduit within 5 feet

(1.5m) of the unit

(For cord-connected/convertible units)

DANGER – Risk of injury.

a) Replace damaged cord immediately.

b) Do not bury cord.

c) Connect to a grounded, grounding type receptacle only.

(For units intended for indoor use only)

WARNING – For indoor use only. This unit is not intended for outdoor use.

(For units intended for outdoor use only)

WARNING – For outdoor use only. This unit is not intended for indoor use.

MasterSpaParts.com

5DO NOT DIVE.

102DO NOT DIVE.

SAFETY INSTRUCTIONS

IMPORTANT SAFETY

INSTRUCTIONS (CONT.)

(For units with GFCI)

WARNING – This product is provided with a ground-fault circuit interrupter

located on the front panel of selected swim spas and on the power cord of

120 volt convertible spas. The GFCI must be tested before each use. With the

product operating, open the service door. When the product stops operating,

this merely indicates that the door is equipped with an electrical interlock.

Next, push the test button on the GFCI and close the service door. The prod-

uct should not operate. Now open the service door, push the reset button

on the GFCI and close the service door. The product should now operate

normally. When the product fails to operate in this manner, there is a ground

current flowing indicating the possibility of an electric shock. Disconnect the

power until the fault has been identified and corrected.

DANGER – Risk of Accidental Drowning. Extreme caution must be exercised to pre-

vent unauthorized access by children. To avoid accidents, ensure that children can-

not use this spa unless they are supervised at all times.

DANGER – Risk of Injury. The suction fittings in this spa are sized to match the spe-

cific water flow created by the pump. Should the need arise to replace the suction

fittings or the pump, be sure that the flow rates are compatible.

Never operate spa if the suction fittings are broken or missing. Never replace a suc-

tion fitting with one rated less than the flow rate marked on the original suction

fitting.

DANGER – Risk of Electric Shock. Install at least 5 feet (1.5m) from all metal sur-

faces. As an alternative, a spa may be installed within 5 feet of metal surfaces if

each metal surface is permanently connected by a minimum 8AWG (8.4mm2) solid

copper conductor to the wire connector on the terminal box that is provided for

this purpose.

DANGER – Risk of Electric Shock. Do not permit any electric appliance, such as a

light, telephone, radio, or television, within 5 feet (1.5 m) of a spa.

WARNING – To reduce the risk of injury:

a) The water in a spa should never exceed 40˚C (104˚F). Water temperatures

between 38˚C (100˚F) and 40˚C are considered safe for a healthy adult.

Lower water temperatures are recommended for young children and when

spa use exceeds 10 minutes.

MasterSpaParts.com

6DO NOT DIVE.

103DO NOT DIVE.

SAFETY INSTRUCTIONS

IMPORTANT SAFETY

INSTRUCTIONS (CONT.)

b) Since excessive water temperatures have a high potential for causing fetal

damage during the early months of pregnancy, pregnant or possibly preg-

nant women should limit spa water temperatures to 38˚C (100˚F).

c) Before entering a spa, the user should measure the water temperature

since the tolerance of water temperature- regulating devices varies.

d) The use of alcohol, drugs, or medication before or during spa use may lead

to unconsciousness with the possibility of drowning.

e) Obese persons and persons with a history of heart disease, low or high

blood pressure, circulatory system problems, or diabetes should consult a

physician before using a spa.

f) Persons using medication should consult a physician before using a spa

since some medication may induce drowsiness while other medication may

affect heart rate, blood pressure, and circulation.

(For spas with a gas heater)

WARNING – Risk of Suffocation. This spa is equipped with a gas heater and

is intended for outdoor use only unless proper ventilation can be provided for

an indoor installation.

HYPERTHERMIA

Hyperthermia occurs when the internal temperature of the body reaches a

level several degrees above the normal body temperature of 98.6° F.

THE SYMPTOMS OF HYPERTHERMIA INCLUDE:

• Dizziness • Fainting • Drowsiness • Lethargy

• Increase in Internal Body Temperature

THE EFFECTS OF HYPERTHERMIA INCLUDE:

Unawareness of Impending Hazard • Failure to Perceive Heat • Failure to

Recognize the Need to Exit Spa • Physical Inability to Exit Spa • Fetal Damage

in Pregnant Women • Unconsciousness Resulting in a Danger of Drowning

MasterSpaParts.com

7DO NOT DIVE.

104DO NOT DIVE.

SAFETY INSTRUCTIONS

IMPORTANT SAFETY

INSTRUCTIONS (CONT.)

DANGER – To reduce the risk of injury to persons, do not remove the suction

grate. Suction through drains and skimmers is powerful when the jets in the spa

are in use. Damaged covers can be hazardous to small children and adults with

long hair. Should any part of the body be drawn into these fittings, turn off the

spa immediately. As a precaution, long hair should not be allowed to float in the spa.

WARNING – Install the spa so that water can be easily drained out of the compart-

ment containing electrical components so as not to damage equipment. When

installing the spa make sure to allow for an adequate drainage system to deal with

any overflow water. Please allow for at least 3 feet of clearance around the perim-

eter of the spa to provide enough room to access for servicing. Contact your local

dealer for their specific requirements.

WARNING – The spa should be covered with an approved locking cover when not

in use, to prevent unauthorized entry and injuries.

WARNING – People with infections, sores or the like should not use the spa. Warm

and hot water temperatures may allow the growth of infectious bacteria if not

properly disinfected.

CAUTION – Safe temperatures for swimming or aquatic exercise is around 80˚F.

CAUTION – Risk of Electrical Shock. Do not leave audio compartment open.

Audio CD controls are not to be operated while inside the spa.

CAUTION – Replace components only with identical components.

WARNING – Risk of Electric Shock. Do not connect any auxiliary components (for

example, additional speakers, headphones, additional audio/ video components

etc.)

to the system. These units are not provided with an outdoor antenna.

Do not service this product yourself as opening or removing covers may expose

you to dangerous voltage or other hazards. Refer all servicing to qualified service

personnel.

If the power supply cord(s) are damaged, water is entering the speaker, audio

compartment, or any other component in the electrical equipment compartment

area, the protective shield is showing signs of deterioration, or there are signs of

other potentially hazardous damage to the unit, turn off the circuit breaker from

the wall and refer servicing to qualified personnel.

MasterSpaParts.com

8DO NOT DIVE.

105DO NOT DIVE.

SAFETY INSTRUCTIONS

IMPORTANT SAFETY

INSTRUCTIONS (CONT.)

The unit should be subjected to periodic routine maintenance once every quarter to

make sure that the it is operating properly.

DANGER – Risk of Electric Shock. A green colored terminal or a terminal marked G,

GR, Ground, Grounding or the symbol shown in Figure 14.1 of UL 1563 is located

inside the supply terminal box or compartment. To reduce the risk of electric shock,

this terminal must be connected to the grounding means provided in the electric

supply service panel with a continuous copper wire equivalent in size to the circuit

conductors supplying this equipment.

At least two lugs marked “Bonding Lugs” are provided on the external surface

or on the inside of the supply terminal box or compartment. To reduce the risk

of electric shock, connect the local common bonding grid in the area of the spa

to these terminals with an insulated or bare copper conductor not smaller than

8AWG.

All field installed metal components such as rails, ladders, drains, or other similar

hardware within 3m of the spa shall be bonded to the equipment grounding bus

with copper conductors not smaller than 8AWG.

SAVE THESE INSTRUCTIONS

MasterSpaParts.com

Otros manuales para MP Force

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Jacuzzi de Master Spas

Master Spas

Master Spas INT GS BAR HARBOR LE Manual de usuario

Master Spas

Master Spas jet Away Manual de usuario

Master Spas

Master Spas LEGEND LSX700 Manual de usuario

Master Spas

Master Spas GS Manual de usuario

Master Spas

Master Spas TWILIGHT Series Manual de usuario

Master Spas

Master Spas Spas 2008 Manual de usuario

Master Spas

Master Spas Down east Manual de usuario

Master Spas

Master Spas INT EVO COMPACT Manual de usuario

Master Spas

Master Spas MP Swim Spa Manual de usuario

Master Spas

Master Spas LEGACY Manual de usuario

Master Spas

Master Spas legacy whirlpool Manual de usuario

Master Spas

Master Spas H2X Challenger Manual de usuario

Master Spas

Master Spas H2X Challenger Manual de usuario

Master Spas

Master Spas MICHAEL PHELPS CHILLY GOAT COLD TUB Manual de usuario

Master Spas

Master Spas Master Spas Series Manual de usuario

Master Spas

Master Spas LS 850 Manual de usuario

Master Spas

Master Spas LEGEND XTREME SERIES Manual de usuario

Master Spas

Master Spas Trainer 12 Manual de usuario

Master Spas

Master Spas 2008 Manual de usuario

Master Spas

Master Spas 2014 H2x Manual de usuario

Master Spas

Master Spas MICHAEL PHELPS CHILLY GOA COLD TUB VALARIS Manual de usuario

Master Spas

Master Spas SEATTLE Manual de usuario

Master Spas

Master Spas MASTER SPAS LEGACY 2012 Manual de usuario

Master Spas

Master Spas Michael Phelps Signature Swim Spas Manual de usuario

Manuales populares de Jacuzzi de otras marcas

Bestway

Bestway Lay-Z-Spa 54189 Manual de usuario

Jacuzzi

Jacuzzi ARGA ARG101C0110 Manual de lista de piezas

Morphy Richards

Morphy Richards Essentials PC4006 Manual de usuario

Softub

Softub PRESTIGE Manual de usuario

JNJ SPAS

JNJ SPAS SPA-318 Manual de instalación

KIRAMI

KIRAMI Comfort Family Manual de usuario

QCA Spa

QCA Spa VS501 PAK (VL260 TOPSIDE) Manual de usuario

HoMedics

HoMedics FB-655HJ-GB Manual de usuario

Everyday Hot Tubs

Everyday Hot Tubs 530 Manual de usuario

anko

anko SS-601A Manual de usuario

Jacuzzi

Jacuzzi Duetta 6042 Manual de usuario

Pooli

Pooli OS030979B Manual de usuario

Jacuzzi

Jacuzzi alimia Manual de usuario

ab Solares Smart Spa Manual de usuario

CalderaSpas

CalderaSpas CalderaSpas Utopia Series Manual de usuario

Outsunny

Outsunny 848-047V70 Manual de usuario

Aquatic

Aquatic INFINITY 1 Manual de usuario

Asteria

Asteria 5630 Manual de usuario
