Jacuzzi POWERACTIVE 2.1 Manual de usuario

PowerActiveTM Swim Spa

PowerProTM Swim Spa

PowerActiveTM Swim Spa 50A

240VAC

60A

60Hz

NORTH AMERICAN MODELS (60 Hz)

PowerProTM Swim Spa

230 VOLT 50 HZ THREE PHASE RCD WIRING

230 VOLT 50 HZ SINGLE PHASE RCD WIRING

230 VOLT 50 HZ DUAL PHASE RCD WIRING

240 VOLT 60 HZ THREE PHASE GFCI WIRING

240 VOLT 60 HZ SINGLE PHASE GFCI WIRING

240 VOLT 60 HZ DUAL PHASE GFCI WIRING

Sono Tube** with

re-bar and poured

concrete in

cavity space

Sono Tube** with

re-bar and

poured concrete

in cavity space

Minimum 4”* thick concrete slab

with reinforced wire mesh

Minimum 8-10”* of crushed stone (.75 to1” stone size)

Ground

level

Ground

level

(4.72 m) 472 cm. (186 inches) Length of the Jacuzzi

PowerActive

Swim Spa

134 cm. (52.75 inches)

Height of the 16ft. / 4.72m Jacuzzi

PowerActive

Swim Spa

11.43 cm

(4.5 inches)

Electrical Conduit

Concrete Pad

(4.72 m) 472 cm. (186 inches) Length of the

Jacuzzi®PowerActiveTM Swim Spa

(2.36 m) 236 cm. (93 inches)

Width of the Jacuzzi®PowerActiveTM Swim Spa

24 inches (60.96 cm)24 inches (60.96 cm)24 inches (60.96 cm)24 inches (60.96 cm)24 inches (60.96 cm)24 inches (60.96 cm)24 inches (60.96 cm)24 inches (60.96 cm)

16 inches

(40.64 cm)

16 inches

(40.64 cm)

16 inches

(40.64 cm)

16 inches

(40.64 cm)

16 inches

(40.64 cm)

16 inches

(40.64 cm)

16 inches

(40.64 cm)

16 inches

(40.64 cm)

Hollow concrete block with re-bar and

poured concrete in cavity space

Sump Pump

with Float

French Drain or

Gravel Drain

Pit access

or Service Area

3ft.*

(91.44 cm)

Wide Service Area

3ft.*

(91.44 cm)

Wide Service Area

2ft.

(60.96 cm)

Wide Crawl Way

2ft.

(60.96 cm)

Wide

Crawl Way

2ft.

(60.96 cm)

Wide

Crawl Way

2ft.*

(60.96 cm)

Wide Crawl Way

(4.72 m) 472 cm. (186 inches) Length of the

Jacuzzi

PowerActive

Swim Spa

(2.36 m) 236 cm. (93 inches)

Width of the Jacuzzi

PowerActive

Swim Spa

60.96 cm.

(24 inches) Wide

Crawl Way

60.96 cm.

(24 inches) Wide

Crawl Way

60.96 cm.

(24 inches) Wide

Crawl Way

Steel

Frame

Support

Steel

Frame

Support

Steel

Frame

Support

Steel

Frame

Support

Steel

Frame

Support

Steel

Frame

Support

60.96 cm.

(24 inches) Wide

Crawl Way

(2.36 m) 236 cm. (93 inches)

Width of the Jacuzzi®PowerActiveTM Swim Spa

(2.36 m) 236 cm. (93 inches)

Width of the Jacuzzi®PowerActiveTM Swim Spa

Ground

Level

Ground Level

(1.34 m)134 cm. (52.75 inches)

Height of the Jacuzzi®

PowerActiveTM Swim Spa

(1.34 m)134 cm. (52.75 inches)

Height of the Jacuzzi®

PowerActiveTM Swim Spa

Minimum 10.16 cm (4 inches) thick concrete slab

with reinforced wire mesh

Minimum 20.3 cm - 25.4 cm (8-10 inches) of crushed stone

1.8542 cm. to 2.54 cm. (.75 to 1 inch) stone size

Minimum 10.16 cm (4 inches) thick concrete slab

with reinforced wire mesh

Minimum 20.3 cm - 25.4 cm (8-10 inches) of crushed stone

1.8542 cm. to 2.54 cm. (.75 to 1 inch) stone size

11.43 cm

(4.5 inches)

11.43 cm

(4.5 inches)

60.96 cm.

(24 inches) Wide

Crawl Way

60.96 cm.

(24 inches) Wide

Crawl Way

60.96 cm.

(24 inches) Wide

Crawl Way

Steel

Frame

Support

Steel

Frame

Support

Steel

Frame

Support

Steel

Frame

Support

Steel

Frame

Support

Steel

Frame

Support

60.96 cm.

(24 inches) Wide

Crawl Way

(2.36 m) 236 cm. (93 inches)

Width of the Jacuzzi®PowerActiveTM Swim Spa

(2.36 m) 236 cm. (93 inches)

Width of the Jacuzzi®PowerActiveTM Swim Spa

Ground

Level

Ground Level

(1.34 m)134 cm. (52.75 inches)

Height of the Jacuzzi®

PowerActiveTM Swim Spa

(1.34 m)134 cm. (52.75 inches)

Height of the Jacuzzi®

PowerActiveTM Swim Spa

Minimum 10.16 cm (4 inches) thick concrete slab

with reinforced wire mesh

Minimum 20.3 cm - 25.4 cm (8-10 inches) of crushed stone

1.8542 cm. to 2.54 cm. (.75 to 1 inch) stone size

Minimum 10.16 cm (4 inches) thick concrete slab

with reinforced wire mesh

Minimum 20.3 cm - 25.4 cm (8-10 inches) of crushed stone

1.8542 cm. to 2.54 cm. (.75 to 1 inch) stone size

11.43 cm

(4.5 inches)

11.43 cm

(4.5 inches)

Steel Frame

Support Structure

Steel Frame

Support Structure

Steel Frame

Support Structure

Steel Frame

Support Structure

Steel Frame

Support Structure

Steel Frame

Support Structure

2ft.*

(60.96 cm)

Wide

Crawl Way

3ft.*

(91.44 cm)

Wide Service Area

French Drain

or Gravel Drain

Sono Tube** with re-bar

andpoured concrete

in cavity space

Sono Tube** with re-bar and

poured concrete in cavity space

Hollow concrete block with re-bar and

poured concrete in cavity space

Hollow concrete block with re-bar

and poured concrete in cavity space

Raised Equipment

Plateform

Minimum 4”* thick concrete slab

with reinforced wire mesh

Minimum 8-10”* of crushed

stone (.75 to1” stone size)

Ground

level

Ground

level

Sump Pump with Float

behind French Drain

NOTE:

Support posts for the

Access Hatch sit between

the French Drain and

Sump Pump

(4.72 m) 472 cm. (186 inches) Length of the

Jacuzzi®PowerActiveTM Swim Spa

134 cm. (52.75 inches)

Height of the

Jacuzzi®PowerActiveTM Swim Spa

11.43 cm

(4.5 inches)
