 J3000™ 16

 J3000™ 19

 J4000™ 16

 J4000™ 19

JACUZZI SWIMSPA COLLECTION

OWNER’S MANUAL

1005219 Revision A

Aenon New Swim Spa Owner!

Congratulaons on the purchase of your new Jacuzzi™ swim spa! The following is a list of au-

tomated funcons performed by your swim spa. These funcons are listed below in an

aempt to suppress any operaonal concerns you may have during the ﬁrst 24 hours of own-

ership! Also listed below are important maintenance recommendaons you should observe

on a regular basis to protect your new investment.

Maintain Healthy Swim Spa Water

Always maintain your swim spa’s water chemistry within the following parameters:

With CLEARRAY® Without CLEARRAY®

pH 7.4—7.6 7.4—7.6

Free chlorine No less than 1.0 ppm 3.0—4.0 ppm

Free bromine No less than 2.0 ppm 2.0—4.0 ppm

Total Alkalinity 100—150 ppm 100—150 ppm

Calcium Hardness 150—250 ppm 150—250 ppm

IMPORTANT: CLEARRAY® Water Puriﬁcaon System is factory installed. If the CLEARRAY®

system is altered or is not operang eﬃciently then follow the “without CLEARRAY® water

chemistry parameters as deﬁned by the Associaon of Pool and Spa Professionals. CLEARRAY®

requires an annual bulb replacement to properly sanize your water.

TO DECREASE RISK OF INFECTION OR DISEASE! Always maintain your spa

ﬁlter as outlined below to ensure healthy spa water.

Required Filter Maintenance

Your new swim spa is equipped with an advanced water ﬁltraon system that provides unsur-

passed water quality! To ensure maximum water quality at all mes, you should clean the

skimming ﬁlter cartridge every 3 months, or as necessary.

Required Water Replacement

You should replace the swim spa’s water every 3 months. The frequency depends on a num-

ber of variables including frequency of use, number of users and aenon paid to water qual-

ity maintenance. You will know it is me for a change when you cannot control sudsing

or you can no longer get the normal feel or sparkle to the water, even though the key water

balance measurements are within the proper parameters.

Table of Contents

1.0 Important Swim Spa Owner Informaon 5

2.0 FCC Noce 5

2.1 Industry Canada (IC) Informaon 6

3.0 Important Safety Instrucons for all Swim Spa Owners 6

3.1 Entrapment Risk 10

3.2 Hyperthermia 12

3.3 Important Safety Instrucons 13

4.0 Choosing a Locaon 13

4.1 Outdoor Locaon 14

4.2 Indoor Locaon 15

5.0 General Electrical Safety Instrucons 16

6.0 Electrical Installaon Instrucons (230 Volt Service) 16

7.0 Power Requirements 20

8.0 Swim Spa Fill Up Procedure 20

9.0 Spa Features 26

9.1 J3000™ 16/19 Power Acve Swim Spa Features 26

9.2 J4000™ 16/19 Power Pro Swim Spa Features 27

10.0 Swim Spa Operaon 28

10.1 Main Screen 28

10.2 Navigaon 30

10.3 The Spa Screen 30

10.4 The Sengs Screen 33

10.5 Spa Behaviour 36

10.6 Time of Day 37

10.7 Adjusng Filtraon 38

10.8 Light Cycle Opon 39

10.9 Restricng Operaon 40

11.0 Pro X Current Control 41

11.1 Manual Workout Mode 41

11.2 Timed Workout Mode 41

11.3 Workout Program Mode 42

12.0 Swim Spa Maintenance 44

12.1 Cleaning the Filter Cartridges 44

12.2 Draining and Reﬁlling 45

12.3 Cleaning the Swim Spa Interior 46

12.4 Pillow Care 46

12.5 Maintaining the Synthec Cabinet 47

12.6 Cleaning the Control Panel 47

12.7 Cover Care and Maintenance 47

12.8 Winterizing 48

12.9 Starng Your Swim Spa in Cold Weather 49

13.0 Water Quality Maintenance 49

13.1 pH Control 50

13.2 Sanizing 50

13.3 Other Addives 51

13.4 CLEARRAY® (Ultraviolet) Water Puriﬁcaon System 51

14.0 Error / Display Messages 51

15.0 Troubleshoong Procedures 54

16.0 Typical Swim Spa Wiring Diagrams 56

17.0 Circuit Board Wiring Diagrams 57

1.0 Important Spa Owner Informaon

Your Jacuzzi® Swim Spa is constructed to the highest standards and is capable of providing

many years of trouble-free use. However, because heat retenve materials are ulized to in-

sulate the swim spa for eﬃcient operaon, an uncovered swim spa surface and wall ﬁngs

directly exposed to sunlight and high temperatures for an extended period aresubject to per-

manent damage or discoloraon. Damage caused by exposing the swim spa to this abuse is

not covered under warranty. We recommend that you always keep the swim spa full of water

when it is exposed to direct sunlight and that you keep the Jacuzzi® insulang cover in place

at all mes when the swim spa is not in use. Read and carefully follow the requirements for

your swim spa’s support base found in Secon 4.0 tled, “Choosing a Locaon”.

Jacuzzi® swim spas constantly strives to oﬀer the ﬁnest swim spas available, therefore,

modiﬁcaons and enhancements may be made which aﬀect the speciﬁcaons, illustraons

and/or instrucons contained herein.

2.0 FCC Noce

This device complies with part 15 of the FCC Rules. Operaon is subject to the following two

condions: (1) This device may not cause harmful interference, and (2) this device must ac-

cept any interference received, including interference that may cause undesired operaon.

This equipment has been tested and found to comply with the limits for a Class B Digital De-

vice, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable

protecon against harmful interference in a residenal installaon. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instrucons, may cause harmful interference to radio communicaons. However, there is

no guarantee that interference will not occur in a parcular installaon. If this equipment

does cause harmful interference to radio or television recepon, which can be determined by

turning the equipment oﬀ and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

1. Rearrange or relocate the receiving antenna;

2. Increase the separaon between the equipment and receiver;

3. Connect the equipment into an outlet on a circuit diﬀerent from the circuit connected;

4. Consult the dealer or an experienced radio/TV technician for help. (Changes or modiﬁca-

ons not expressly approved by the party responsible for FCC compliance could void the

user’s authority to operatethis equipment.)

2.1 Industry Canada (IC) Informaon

The installer of this radio equipment must ensure that the antenna is located or pointed such

that it does not emit RF ﬁeld in excess of Health Canada limits for general populaon; consult

Safety Code 6, obtainable from Health Canada’s website: www.hc-sc.gc.ca.

3.0 Important Safety Instrucons for all Swim Spa Owners.

READ AND FOLLOW ALL INSTRUCTIONS CAREFULLY!

This swim spa was manufactured to meet the standards and speciﬁcaons outlined in the

“Virginia Graeme Baker Pool and Spa Safety Act” (VGB Safety Act). When installing and using

this swim spa, basic safety precauons should always be followed, including:

DANGER: RISK OF SEVERE INJURY OR DROWNING!

 Extreme cauon must be exercised to prevent unauthorized access by children.

 To avoid accidents, ensure that children do not use this spa unless supervised at all

mes. Adult supervision is a crical safety factor in prevenng children from drowning.

 Use the straps and clip e downs to secure the swim spa cover when not in use. This will

help discourage unsupervised children from entering the swim spa. Keep the cover se-

cure in high wind condions.

 There is no representaon that the cover, clip e downs, or actual locks will prevent ac-

cess to the swim spa.

 Keep hair, loose arcles of clothing or hanging jewelry away from sucon ﬁngs, ro-

tang jets or other moving components to avoid entrapment that could lead to drowning

or severe injury.

 Never use the swim spa unless all the sucon guards, ﬁlter, ﬁlter lid, or skimmer assem-

bly are installed to prevent body and/or hair entrapment.

 Never operate or use the spa if the ﬁlter, ﬁlter lid, or skimmer assembly are broken or

any part of the skimmer assembly is missing. Please contact your dealer or nearest ser-

vice center for service.

 The sucon ﬁngs and sucon covers in this swim spa are sized to match the speciﬁc

water ﬂow created by the pump(s). If it is necessary to replace the sucon ﬁngs, suc-

on covers or pump(s), be sure that the ﬂow rates are compable and are in compliance

with the VGB Safety Act.

 Never replace a sucon ﬁng or sucon cover with one rated less than the ﬂow rate

marked on the original sucon ﬁng. Using improper sucon ﬁngs or sucon covers

can create a body or hair sucon entrapment hazard that may lead to drowning or se-

vere injury.

DANGER: RISK OF SEVERE INJURY FROM ELECTRIC SHOCK OR DEATH FROM

ELECTROCUTION!

 Install the swim spa at least 5 feet (1.5m), from all metal surfaces. As an alternave, a

swim spa may be installed within 5 feet of metal surfaces if each metal surface is perma-

nently connected (bonded) by a minimum No. 8 AWG (8.4 mm2) solid copper conductor

aached to the wire connector on the grounding lug, inside the equipment compart-

menton the equipment box.

 A grounding wire connector is provided on this unit to connect a minimum No. 8 AWG

(8.4 mm2) solid copper conductor between this unit and any metal equipment, metal en-

closures of electrical equipment, metal water pipe, or conduit within 5 feet (1.5m) of the

unit.

 Never permit any electrical appliance, such as a light, telephone, radio, television, etc.

within 5 feet (1.5m) of a swim spa unless such appliances are built-in by the manufactur-

er.

 Never bring any electrical appliances into or near the swim spa.

 Never operate any electrical appliance from inside the swim spa or when you are wet.

 The electrical supply for this product must include a suitably rated switch or circuit

breaker to open all ungrounded supply conductors to comply with Secon 422-20 of the

Naonal Electric Code/USA. ANSI/NFPA 70. The disconnecng means must be readily ac-

cessible and visible to the swim spa occupant but installed at least 5 feet (1.5m) from the

swim spa.

 The electrical circuit supplied for the swim spa must include a suitable ground fault cir-

cuit interrupter (GFCI) as required by NEC Arcle 680-42.

WARNING: RISK OF SEVERE INJURY OR DEATH!

 Extreme cauon must be exercised to prevent diving or jumping into the swim spa or

slipping and falling, which could result in unconsciousness, drowning, or serious injury.

Remember that wet surfaces can be very slippery.

 Never stand, walk or sit on the top railing of the swim spa.

WARNING: RISK OF HYPERTHERMIA (OVER-HEATING) CAUSING SEVERE INJU-

RY, BURNS, WELTS OR DEATH!

 Water temperature in excess of 104oF (40oC) may be injurious to your health.

 Refer to Secon 3.2 Hyperthermia for speciﬁc causes and symptoms of this condion.

 The water in the swim spa should never exceed 104oF (40oC). Water temperatures be-

tween 100oF (38oC) and 104oF (40oC) are considered safe for a healthy adult.

 Lower water temperatures are recommended for young children (children are especially

sensive to hot water) and when swim spa use may exceed 10 minutes.

 The Consumer Products Safety Commission/USA has stated that the water temperature

in a swim spa should not exceed 104oF (40oC).

 Always test the swim spa water temperature before entering the swim spa. The user

should measure the water temperature with an accurate thermometer since the toler-

ance of water temperature-regulang devices may vary as much as +/- 5oF (2oC).

WARNING: RISK OF SEVERE INJURY OR DEATH!

 Since excessive water temperatures have a high potenal for causing fetal damage dur-

ing the early months of pregnancy, if pregnant or possibly pregnant, consult your physi-

cian before using a swim spa.

 Pregnant or possibly pregnant women should limit swim spa water temperatures to

100oF (38oC).

 Persons suﬀering from obesity or a medical history of heart disease, low or high blood

pressure, circulatory system problems, diabetes, infecous diseases or immune deﬁcien-

cy syndromes should consult a physician before using a spa.

 If you experience breathing diﬃcules in associaon with using or operang your swim

spa, disconnue use and consult your physician.

 Persons using medicaon should consult a physician before using a swim spa since some

medicaon may induce drowsiness, while other medicaon may aﬀect heart rate, blood

pressure and circulaon.

 Persons suﬀering from any condion requiring medical treatment, the elderly, or infants

should consult with a physician before using a swim spa.

 The use of alcohol, drugs, or medicaon before or during swim spa use may lead to un-

consciousness with the possibility of drowning.

WARNING: RISK OF SEVERE INJURY OR DEATH!

 Prolonged immersion in a swim spa may be injurious to your health.

 Observe a reasonable me limit when using the swim spa. Exposures at higher tempera-

tures can cause high body temperature (over-heang). Symptoms may include dizziness,

nausea, fainng, drowsiness, and reduced awareness. These eﬀects could possibly result

in drowning or serious injury.

 Never use a swim spa immediately following strenuous exercise. Enter and exit the swim

spa slowly. Wet surfaces can be slippery.

WARNING: TO DECREASE RISK OF INFECTION OR DISEASE!

 To reduce the risk of contracng a waterborne illness (e.g. an infecon, bacteria or virus)

and/or respiratory ailments, maintain water chemistry within the parameters listed on

the inside cover of this manual andconsult with a licensed engineer regarding proper

venlaon if installed indoors or in an enclosed area.

 People with infecous diseases should not use a swim spa to avoid water contaminaon,

which could result in spreading infecons to others.

 Always shower before and aer using your swim spa. Maintain water chemistry in ac-

cordance with manufacturer’s instrucons. Failure to do so may result in contracng a

waterborne illness (e.g. an infecon, bacteria or virus)

WARNING: In addion to maintenance of ﬁlters and water chemistry, proper

venlaon is recommended to reduce the risk of contracng a waterborne illness (e.g. an in-

fecon, bacteria or virus) and/or respiratory ailments that could be present in the air or water.

Consult a licensed architect or building contractor to determine your speciﬁc needs if in-

stalling your swim spa indoors.

CAUTION: TO DECREASE RISK OF PRODUCT DAMAGE

 Maintain water chemistry in accordance with manufacturer’s instrucons.

 Proper chemical maintenance of swim spa water is necessary to maintain safe water and

prevent possible damage to swim spa components.

WARNING: RISK OF SEVERE INJURY OR DEATH!

The appliance is not intended for use by persons (including children) with reduced physical,

sensory or mental capabilies, or lack of experience or knowledge, unless they have been giv-

en supervision or instrucon concerning use of the appliance by a person responsible for their

safety.

NOTE: This swim spa is not intended nor designed to be used in commercial or public ap-

plicaons. The buyer shall determine whether there are any code restricons on the use or

installaon of this swim spa since local code requirements vary from one locality to another.

3.1 Entrapment Risk

The Consumer Products SafetyCommission/USA has reported that users of pools and spas

have become entrapped (stuck) to drain and/or sucon ﬁngs causing death, drowning, or

serious injury (see diagram below). This swim spa was manufactured to meet the standards

and speciﬁcaons outlined in the “Virginia Graeme Baker Pool and Spa Safety Act” (VGB Safe-

ty Act). Entrapment risk can be minimized if proper precauons are taken.

DANGER: RISK OF PERSONAL INJURY OR DEATH!

Never operate the swim spa if a sucon ﬁng, sucon cover, ﬁlter, ﬁlter lid or

skimmer assembly is broken, damaged or missing.

Note: Sucon covers must be replaced every 5 years.

Este manual sirve para los siguientes modelos

Otros manuales de Jacuzzi de Jacuzzi

Jacuzzi

Jacuzzi J-400 Series Manual de usuario

Jacuzzi

Jacuzzi DELFINO Manual de usuario

Jacuzzi

Jacuzzi Andros Manual de usuario

Jacuzzi

Jacuzzi Platinum 2001 Manual de usuario

Jacuzzi

Jacuzzi PROJECTA lagoon 170x70 Manual de usuario

Jacuzzi

Jacuzzi SPA MAXI UNIQUE Manual de usuario

Jacuzzi

Jacuzzi Real EH85 Manual de usuario

Jacuzzi

Jacuzzi J-Sha Mi Manual de usuario

Jacuzzi

Jacuzzi HE96000 Manual de usuario

Jacuzzi

Jacuzzi Experience SIENNA Manual de usuario

Jacuzzi

Jacuzzi Delos Manual de usuario

Jacuzzi

Jacuzzi experience Virginia Manual de usuario

Jacuzzi

Jacuzzi Platinum Series Manual de usuario

Jacuzzi

Jacuzzi Profile Manual de usuario

Jacuzzi

Jacuzzi BELLAVISTA 5 Manual de usuario

Jacuzzi

Jacuzzi J-200 Series Manual de usuario

Jacuzzi

Jacuzzi NOVA 536 Manual de usuario

Jacuzzi

Jacuzzi CAPELLA 60 Manual de usuario

Jacuzzi

Jacuzzi Bellavista 6 Manual de usuario

Jacuzzi

Jacuzzi Tirage Plus PORTABLE WHIRLPOOL SPA Manual de usuario

Jacuzzi

Jacuzzi BELLAVISTA 5 Manual de usuario

Jacuzzi

Jacuzzi J-200 Series Manual de usuario

Jacuzzi

Jacuzzi J-145 Manual de usuario

Jacuzzi

Jacuzzi Luxury/Designer Bath Series K339000X Instrucciones de instalación

Manuales populares de Jacuzzi de otras marcas

Bestway

Bestway Lay-Z-Spa 54189 Manual de usuario

Morphy Richards

Morphy Richards Essentials PC4006 Manual de usuario

Softub

Softub PRESTIGE Manual de usuario

JNJ SPAS

JNJ SPAS SPA-318 Manual de instalación

KIRAMI

KIRAMI Comfort Family Manual de usuario

QCA Spa

QCA Spa VS501 PAK (VL260 TOPSIDE) Manual de usuario

HoMedics

HoMedics FB-655HJ-GB Manual de usuario

Everyday Hot Tubs

Everyday Hot Tubs 530 Manual de usuario

anko

anko SS-601A Manual de usuario

Pooli

Pooli OS030979B Manual de usuario

ab Solares Smart Spa Manual de usuario

CalderaSpas

CalderaSpas CalderaSpas Utopia Series Manual de usuario

Outsunny

Outsunny 848-047V70 Manual de usuario

Aquatic

Aquatic INFINITY 1 Manual de usuario

Master Spas

Master Spas MP Force Manual de usuario

Asteria

Asteria 5630 Manual de usuario


Image IMSB61610, IMSG61610 Manual de usuario

ViSAGE

ViSAGE FM-588D Manual de usuario
