USER MANUAL
J-Tech Digital®ProAV®
HDMI2.0 8X8 matrix with IP RS232 Coaxial
JTD-ID:279
RoHS
2
Operating Instruction
Thank you for purchasing this product. For optimum performance and
safety, please read these instructions carefully before connecting,
operating or adjusting this product. Please keep this manual for future
reference.
SURGE PROTECTION DEVICE RECOMMENDED
This product contains sensitive electrical components that may be
damaged by electrical spikes, surges, electric shock, lightning strikes,
etc. Use of surge protection systems is highly recommended in order to
protect and extend the life of your equipment.
3
Operating Instruction
Table of Contents
1. Features.....................................................................................4
2. Package Contents.....................................................................4
3. Specifications............................................................................4
4. Panel Descriptions....................................................................5
5. Connecting and Operating.......................................................7
6. Application Diagrams...............................................................7
7. Remote Control Description.....................................................8
8. RS232 Pin
A
ssignment.............................................................8
9. RS232 Control............................................................................9
9.1 Software Control.......................................................................9
9.2 Command Control...................................................................12
10. Web Control...........................................................................15
Warranty Policy............................................................................17
4
Operating Instruction
Dear Customer
Thank you for purchasing this product. For optimum performance and safety, please read
these instructions carefully before connecting, operating or adjusting this product. Please
keep this manual for future reference.
1. Features
HDMI 2.0 version (Support 4K@60Hz YUV4:4:4)
Support 3D
Bandwidth upto 18Gbps
HDCP2.2 input ,HDCP2.2 output
HDCP1.4 input, HDCP1.4 output
Support HDR10
8xHDMI Input, 8xHDMI output with 8xSPDIF Audio
Any one of the 8 Ultra HD sources to any one of the 8 Ultra HD displays
Support Panel Button, Local IR, RS232 Control with command, IP Control, Web GUI
Control
Support Dolby True HD and DTS-HD master audio
1U rack design, easy installment
Unit size: L440XW220XH44.5mm
2. Package Contents
1). 1x HDMI Matrix
2). 1x 12V DC power supply
3). 1x Remote control
4). 1x IR Ext RX Cable
5). 1x mounting kit
6). 1x CD for control software & user manual
3. Specifications
Bandwidth 18 Gbps
Resolution
480p@60hz,576P@50hz,720P@60hz,
1080P@24hz,1080P@50hz,1080P@60hz,4K@24hz,4K@30hz,
4K@60hz YUV4:2:0, 4K@ 60hz YUV4:4:4
Video Input Connectors 8xHDMI Type A, 19-pin, female
Video Output Connectors 8xHDMI Type A, 19-pin, female
RS-232 serial port DB9, female
Ethernet port (IP control) RJ45, female
IR Ext port 1x3.5mm stereo jack
Rack-Mountable Rack ears included
Dimensions(WxHxD) L440XW220XH44.5mm
Net Weight 2.8kg
Operating Temperature -4°F to 140°F (-20°C to 60°C)
Storage Temperature -40°F to 158°F (-40°C to 70°C)
Power consumption 19W(Max)
5
Operating Instruction
4. Panel Descriptions
①IR receive window.
②Input button IN1~8: choose the desired input port from ports 1~8.
③Output button OUT1~8: choose the desired output port from ports 1~8.
①IP control.
②RS232 for control.
③For IR external receiver cable.
④SPDIF Audio output.
⑤DC power input.
⑥HDMI input port.
⑦HDMI output port.
6
Operating Instruction
Check the EDID Information by Panel button
Press “In4”for 3 seconds ,then press “In1”or “Out1” to check the EDID information for
each HDMI input.
Press “In5” for 3 seconds, then press “In1” or “Out1” to check the device name , IP
address and DHCP status.
7
Operating Instruction
5. Connecting and Operating
1. Connect source devices to input ports of the matrix
2. Connect HDMI output ports to TV or other HDMI sink devices.
3. Optional: connect RS232 cable from PC RS232 port.
4. Optional: connect an Ethernet cable from the TCP/IP port on the matrix to a local area
network.
5. Connect 12V POWER supply to DC power socket.
6. Power on the matrix, HDMI sources and displays.
6. Application Diagram
8
Operating Instruction
7. Remote Control Description
1Standby Mode.
②OUTPUT-X select INPUT-Y:
Press OUTPUT-X (X means 1 to 8 of outputs)
Press INPUT-Y (Y means 1 to 8 of inputs)
③All outputs select INPUT-Y:
Press ALL button in zone OUTPUT
Press INPUT-Y button (Y means 1 to 8 of inputs),
then INPUT-Y switched to ALL OUTPUTS.
④Cancel Button: Cancel the switching operation
⑤PTP button: Mirror all inputs and outputs
(Ex. Input 1 to output 1, input 2 to output 2, etc):
Press PTP button in Zone OUTPUT.
8. RS232 Pin Assignment
Matrix Remote Control Console
PIN Assignment PIN Assignment
1NC 1 NC
2Tx 2 Rx
3Rx 3 Tx
4NC 4 NC
5 GND 5 GND
6NC 6 NC
7NC 7 NC
8NC 8 NC
9NC 9 NC
Baud Rate: 115200 bps
Data Bits: 8 bit Parity: None Stop Bit: 1 bit
Flow Control: None
9
Operating Instruction
9. RS232 Control
9.1 Software control
Connect the 8x8 Matrix to PC with a RS232 cable, open the software on your PC. On the
COM Setting session, select the COM port according to your PC and click Connect to get
connected.
On this COM setting session, you can also change the Device name, Device name
support up to 16 characters. Save or edit your status by clicking the Edit button.
Come to Port Set session to select or switch your input sources for each output, We can
read the current status by clicking the “Status” button, or Clear our historical operating
record by clicking “Clear” button. The right down blank shows the operating history.
Picture 1
10
Operating Instruction
The EDID session helps us to Read and Configure EDID for each input, such as HDR, 3D,
Data rates and Audio channel.
Picture 2
The IP configure session helps to read and configure the IP address and MAC of the
Matrix. Check DHCP if you want the router assign an automatic IP for the Matrix.
Picture 3
