Operating Instructions
USER MANUAL
J-Tech Digital® 18G HDMI Extender with udio Breakout
Model: JTECH-EXBT460
JTD-ID: 460
2
Statement
Thanks for choosing this product, please read this user manual carefully before using
this product. The functions described in this version are updated till January, 2019. In
the constant effort to improve our product, e reserve the right to make functions or
parameters changes ithout notice or obligation.
Safety Precaution
⚫
Do not dismantle the housing or modify the module to avoid electrical shock or burn.
⚫
Using supplies not meeting the products' specifications may cause damage,
deterioration or malfunction.
⚫
Do not expose the unit to rain, moisture or install this product near ater.
⚫
Install the device in a place ith fine ventilation.
⚫
Do not t ist or pull by force ends of the optical cable. It can cause malfunction.
⚫
Do not use liquid or aerosol cleaners to clean this unit.
⚫
Al ays unplug the po er to the device before cleaning.
⚫
Unplug the po er hen not used for a long period of time.
⚫
Refer all servicing to qualified service personnel.
After-sales Service
We provide limited arranty for the product ithin three years.
Packing List
⚫
1x JTECH-EXBT460 Transmitter ⚫
1x JTECH-EXBT460 Receiver
⚫
2x TX Mounting Ears ith 4 Scre s ⚫
2x RX Mounting Ears ith 4 Scre s
⚫
4x TX Plastic Cushions ⚫
4x RX Plastic Cushions
⚫
1x 3-pin Terminal Block ⚫
1x RS232 Cable (3-pin to DB9)
⚫
1x Po er Adapter (24V DC 1.25A) ⚫
1x User Manual
Note: Please contact your distributor immediately if any damage or defect in the
components is found.
3
Product Introduction
Thanks for choosing the JTECH-EXBT460 HDMI 2.0 Extender, hich consists of a
transmitter and a receiver. It can extend 4K video to distance up to 131 feet (40 meters)
and 1080P video to distances up to 230 feet (70 meters) over a single CATx cable. It
supports audio de-embedded and ARC. It also supports bidirectional IR and RS232
pass-through to control source or display device remotely. PoC feature allo s the
transmitter and the receiver can be po ered from each other and only one po er
adapter is needed in system. Besides passing EDID information from the display, there
are multiple built-in EDID settings can be selected by the 4-pin DIP s itch on the front
panel of transmitter. Moreover, the extender supports convenient firm are upgrade
through Micro-USB port.
Features
⚫
Supports HDMI 2.0 and the HDMI video resolution up to 4K@60Hz 4:4:4 HDR.
⚫
HDMI input supports HDCP 2.2 and the output support HDCP Active or HDCP
Passive mode.
⚫
Extends 4K signals to distances up to 131 feet (40 meters) and 1080P signals to
distances up to 230 feet (70 meters) over a single CATx cable.
⚫
Supports video resolution up-scaling, the 1080P input can be automatically
upgraded to 4K output.
⚫
SPDIF out on receiver for source audio de-embedding.
⚫
18Gbps high band idth.
⚫
Advanced EDID management: multiple built-in EDID settings can be selected.
⚫
Test pattern provides a built-in 4K/1080P image for troubleshooting.
⚫
Bidirectional IR, RS232 and 24V PoC.
⚫
Supports ARC.
⚫
Supports CEC pass-through.
⚫
Provides LEDs to indicate the current operating status.
⚫
Firm are upgrade by Micro-USB port.
4
Transmitter Panel Description
① Power LED The LED illuminates red hen po er is applied.
② Test Pattern Press the button ith paper clip or other sharp tool to enable the
test pattern, and the left LED illuminates blue, the product generates an image of
1080P/60Hz color bar to output; Press this button again, the left LED blinks blue
at an interval of 500ms, the product generates an image of 4K/60Hz 4:4:4 color
bar to output. Press and hold this button for three seconds again can exit the Test
Pattern mode.
③ 1080P → 4K Press the button ith paper clip or other sharp tool to enable 1080P
to 4K up-scaling, and then the left LED illuminates blue. Press it again to exit.
④ EDID 4-pin DIP s itch for EDID setting and HDCP mode selection. Please refer
to the EDID Management for more details.
⑤ FW Micro-USB port for firm are upgrade and user-defined EDID upload.
⑥ HDMI In Type-A female HDMI input port to connect a HDMI source.
⑦ ARC Audio Out Toslink connector to connect speaker or amplifier for ARC audio
output.
⑧ IR In 3.5mm jack to connect the IR receiver for IR pass-through.
⑨ IR Out 3.5mm jack to connect the IR emitter for IR pass-through.
⑩ RS232 3-pin terminal block to connect the RS232 control device (e.g. PC) or a
third-party device to be controlled.
⑪ HDBT Out RJ45 port to connect the HDBT input port of receiver by CATx
Ethernet cable. The LINK LED illuminates orange hen there is a valid HDBaseT
link bet een the transmitter and the receiver. The HDCP LED illuminates green
hen the video contains HDCP content.
⑫ DC 24V DC connector for the po er adapter connection.
Tx Rx
LINKHDCP
123 4 56789 10 11 12
H D B T O u t
HDMI In IR O u tIR In
ARC Audio Out
5
Receiver Panel Description
① Power LED The LED illuminates red hen po er is applied.
② ARC Mode Press the button ith paper clip or other sharp tool to enable the
ARC mode, and then the left LED illuminates blue. Press it again to exit the ARC
mode and the LED is off.
③ ARC Audio In Toslink connector to connect ARC audio source device (e.g.TV).
④ FW Micro-USB port for firm are upgrade.
⑤ HDMI Out Type-A female HDMI output port to connect HDMI display (e.g.TV).
⑥ Audio Breakout If the ARC mode is OFF, the Toslink connector is connected to
speaker or amplifier for HDMI source audio de-embedding. Note that if the ARC
mode is ON, this port has no audio output.
⑦ IR In 3.5mm jack to connect the IR receiver for IR pass-through.
⑧ IR Out 3.5mm jack to connect the IR emitter for IR pass-through.
⑨ RS232 3-pin terminal block to connect the RS232 control device (e.g. PC) or a
third-party device to be controlled.
⑩ HDBT In RJ45 port to connect the HDBT output port of transmitter by CATx
Ethernet cable. The LINK LED illuminates orange hen there is a valid HDBaseT
link bet een the transmitter and the receiver. The HDCP LED illuminates green
hen the video contains HDCP content.
⑪ DC 24V DC connector for the po er adapter connection.
123456 7 89 1110
6
DIP Switch Operation
EDID Management
The Extended Display Identification Data (EDID) is used by the source device to
match its video resolution ith the connected display. By default, the source device
obtains its EDID from the first connected display. Mean hile, since the displays ith
different capabilities are connected to the extender, the DIP s itch on the front panel
of transmitter can be used to set the EDID to a fixed value to ensure the compatibility
in video resolution.
The s itch represents “0” hen in the lo er (OFF) position, and it represents “1” hile
putting the s itch in the upper (ON) position.
S itch 1~3 are used for EDID setting. The DIP s itch status and its corresponding
setting are sho n at the back of the product.
Switch Status Video Resolution Audio Format
000 Pass Through
001 1080P 2CH
010 3840x2160@30Hz 2CH
011 3840x2160@30Hz Multi-CH
100 3840x2160@60Hz 2CH
101 3840x2160@60Hz Multi-CH
1 2 3
EDID Setting
Default
1 2 3 4
ON
OFF
1
0
ON
OFF
4
HDCP Active
HDCP Passive
Pass Through
1080p 2CH
4K/30Hz Multi-CH
ON
OFF
1 2 3
ON
OFF
1 2 3
ON
OFF
1 2 3
ON
OFF
1 2 3
4K/30Hz 2CH
ON
OFF
1 2 3
ON
OFF
1 2 3
ON
OFF
1 2 3
4K/60Hz 2CH
4K/60Hz Multi-CH
4K/60Hz HDR Multi-CH
ON
OFF
1 2 3
User Defined
7
110 3840x2160@60Hz HDR
Multi-CH (Supports PCM
2CH, PCM5.1, Dolby
Digital 5.1,DTS 2CH)
111 User-defined EDID (Upload the EDID by Micro-USB port)
Note:
⚫
2CH: Supports LPCM 2CH.
⚫
Multi-CH: Supports LPCM 8CH Dolby TrueHD DTS-HD Dolby Digital5.1 DTS
5.1 Dolby Digital Plus.
⚫
User-defined EDID Setting
Except directly invoking the built-in EDID, the specific EDID can be customized by
follo ing the belo operation process.
1) Rename the user-defined EDID according the follo ing format.
EC_xx_xxxxx_xxxx_xxx.bin
⚫
EC: Fixed value
⚫
xx: EDID ID. It is “15”.
⚫
xxxxx: Video resolution.
⚫
xxxx: Refresh rate.
⚫
xxx: Audio format.
Example: EC_15_3840x2160_60Hz_ Dolby.bin
2) Connect the FW port of transmitter to the PC ith USB cable, and then po er on
the transmitter, the PC ill automatically detect a virtual disk named of
“BOOTDISK”.
3) Double-click to open the disk, a file named of “READY.TXT” ill be sho ed.
4) Copy the user-defined EDID (such as EC_15_3840x2160_60Hz_Dolby.bin) to
the “BOOTDISK” disk.
5) Reopen the disk to check the filename “READY.TXT” hether automatically
becomes “SUCCESS.TXT”, if yes, the user-defined EDID as imported into the
transmitter and saved as its corresponding EDID ID successfully.
6) Remove the USB cable, and then reboot the transmitter.
7) No the ne EDID can be invoked by setting the DIP s itch status to “111”.
8
HDCP Mode
Put the s itch 4 on the “ON” position to select HDCP Active mode, or on the “OFF”
position for HDCP Passive mode.
Switch Status Mode HDCP
OFF (0) Passive
(Default)
Automatically follo s the HDCP version of source
device.
ON (1) Active
⚫
If the input video has HDCP content, the HDCP
version of HDMI output is HDCP 1.4 for broader
video solution.
⚫
If the input video has no HDCP content, the HDMI
output has no HDCP too.
ARC Mode
The front panel of receiver provides a buttons to enable or disable ARC mode, as
belo figure sho s:
Press the button ith paper clip or other sharp tool to enable the ARC mode, and then
the left LED illuminates blue. Press it again to exit the ARC mode and the LED is off.
ARC Mode Display (e.g.TV) Audio Transmission Path
ON
ARC is supported
The TV audio is transmitted from the TV back
to the receiver via HDMI cable, and then it
ill be output by the ARC Audio Out port of
transmitter.
ARC is not supported
Connect the TV to the ARC Audio In port of
receiver ith an audio cable. The TV audio is
transmitted from the TV back to the receiver
via the audio cable, and then it ill be output
by the ARC Audio Out port of transmitter.
Note that if the ARC mode is ON the Audio
Breakout port of receiver has no audio
output.
9
OFF /
The TV audio can’t be back to the ARC
Audio Out port of transmitter. The Audio
Breakout port of receiver is connected to
speaker or amplifier for HDMI source audio
de-embedding.
System Connection
The follo ing diagram illustrates the typical input and output connection of the
extender:
1 2 3 4
Tx Rx
LINKHDCP
Tx Rx
LINKHDCP
Speaker Laptop Remote HDTVSpeaker
HDMI:
HDBaseT:
Audio:
IR:
RS232:
ARC
ARC
Tx Rx
ARC
IR
Receiver
PoC
4K 40m 1080P 70m
,
IR
Emitter
10
Technical Specification
Transmitter Receiver
Video
Input (1) HDMI (1) HDBT
Input Connector (1) Type-A female HDMI (1) RJ45
Input Resolution
Up to 4Kx2K@60Hz 4:4:4 8bit
HDR10
Up to 4Kx2K@60Hz 4:2:0
Output (1) HDBT Out (1) HDMI
Output Connector (1) RJ45 (1) Type-A female HDMI
Output Resolution Up to 4Kx2K@60Hz 4:2:0
Up to 4Kx2K@60Hz 4:4:4 8bit
HDR10
Audio
Input - (1) ARC Audio In
Input Connector - (1) Toslink Connector
Output (1) ARC Audio Out (1) Audio Breakout
Output Connector (1) Toslink connector (1) Toslink connector
Audio Format Supports PCM, Dolby Digital, Dolby True-HD, DTS and DTS-HD.
Frequency Response 20Hz – 20KHz, ±3dB
Max Output Level
2.0Vrms ± 0.5dB. 2V = 16dB headroom above -10dBV (316mV)
nominal consumer line level signal
THD+N
< 0.05% (-80dB), 20Hz – 20KHz band idth, 1KHz sine at 0dBFS level
(or max level)
SNR > 85dB, 20Hz-20 kHz band idth
Crosstalk Isolation > 70dB, 10KHz sine at 0dBFS level (or max level before clipping)
L-R Level Deviation < 0.3dB, 1KHz sine at 0dBFS level (or max level before clipping)
Frequency Response
Deviation
< ± 0.5dB 20Hz - 20KHz
Output Load Capability 1KΩ and higher (Supports 10x paralleled 10KΩ loads)
Stereo Channel
Separation
>70dB@1KHz
Control
Control Part
(1) Test Pattern button,
(1)1080P → 4K button,
(1) EDID 4-pin DIP s itch,
(1) FW, (1) IR In, (1) IR Out,
(1) RS232
(1) ARC Mode button, (1) FW,
(1) IR In, (1) IR Out, (1) RS232
Control Connector
(1) Micro-USB port,
(2) 3.5mm jacks,
(1) Micro-USB port,
(2) 3.5mm jacks,
Tabla de contenidos
Otros manuales de Extensor de J-Tech Digital
J-Tech Digital
J-Tech Digital JTECH-4K88-EX2 Manual de usuario
J-Tech Digital
J-Tech Digital JTD-1651 Manual de usuario
J-Tech Digital
J-Tech Digital JTECH-AET1000 Manual de usuario
J-Tech Digital
J-Tech Digital JTECH-HDBT73 Manual de usuario
J-Tech Digital
J-Tech Digital JTECH-ex2 Manual de usuario
J-Tech Digital
J-Tech Digital JTD-2980 Manual de usuario
J-Tech Digital
J-Tech Digital JTD-2860 Manual de usuario
J-Tech Digital
J-Tech Digital JTECH-VW-4KPR Manual de usuario
J-Tech Digital
J-Tech Digital ARC-HDEX40ARC Manual de usuario
J-Tech Digital
J-Tech Digital JTD-416 Manual de usuario
J-Tech Digital
J-Tech Digital JTECH-WEX-22 Manual de usuario
J-Tech Digital
J-Tech Digital JTD-1263 Manual de usuario
J-Tech Digital
J-Tech Digital JTD-3023 Manual de usuario
J-Tech Digital
J-Tech Digital JTECH-VW09 Manual de usuario
J-Tech Digital
J-Tech Digital JTD-DVI-EX-196 Manual de usuario
J-Tech Digital
J-Tech Digital JTECH-WEX20 Manual de usuario
J-Tech Digital
J-Tech Digital JTD-1729 Manual de usuario
J-Tech Digital
J-Tech Digital NA-EX01R Manual de usuario
J-Tech Digital
J-Tech Digital JTD-2994 Manual de usuario
J-Tech Digital
J-Tech Digital JTDHDEX-1 Manual de usuario
