IXXAT USB-to-CAN compact Manual de usuario

Hardware Manual

USB-to-CAN V2

compact

embedded

automotive

professional

USB CAN Interface

IXXAT Automation GmbH

Leibnizstr. 15

88250 Weingarten

Germany

Tel.: +49 751 56146-0

Fax: +49 751 56146-29

Internet: www.ixxat.com

E-Mail: info@ixxat.com

Support

In case of unsolvable problems with this product or other IXXAT products

please contact IXXAT in written form:

Fax: +49 751 56146-29

E-Mail: support@ixxat.de

Further international support contacts can be found on our webpage

www.ixxat.com

Duplication (copying, printing, microfilm or other forms) and the electronic

distribution of this docu

ment is only allowed with explicit permission of

IXXAT Automation GmbH. IXXAT Automation GmbH reserves the right to

change technical data without prior announcement. The general business

conditions and the regulations of the license agreement do apply. All

rights are reserved.

Registered trademarks

All trademarks mentioned in this document and where applicable third

party registered are absolutely subject to the conditions of each valid

label right and the rights of particular registered proprietor. The absence

of identification of a trademark does not automatically mean that it is not

protected by trademark law.

Document number: 4.01.0280.20000

Version: 1.0

Content

1Introduction....................................................................................5

2Installation......................................................................................6

2.1 Software installation...............................................................6

2.2 Hardware installation..............................................................6

2.2.1 USB-to-CANV2 compact / professional / automotive................6

2.2.2 USB-to-CANV2 embedded........................................................6

3Connectors and displays ..............................................................7

3.1 USB connector........................................................................7

3.2 Fieldbus connector.................................................................7

3.2.1 USB-to-CANV2 compact...........................................................7

3.2.2 USB-to-CANV2 professional .....................................................8

3.2.3 USB-to-CANV2 automotive.......................................................8

3.3 Displays...................................................................................9

3.3.1 USB LED..................................................................................9

3.3.2 CAN LED..................................................................................9

3.3.3 CAN1 LS LED........................................................................10

3.3.4 LIN LED..................................................................................10

4Notes.............................................................................................11

4.1 CAN bus termination............................................................11

4.2 LIN interface..........................................................................11

4.3 USB-to-CANV2 embedded cable wire assignment ..............11

5Appendix ......................................................................................12

5.1 Technical data.......................................................................12

5.2 Support..................................................................................13

5.3 Returning hardware..............................................................13

5.4 FCC Compliance...................................................................13

5.5 Disposing of old equipment.................................................13

5.6 Information on EMC..............................................................14

5.7 EC Declaration of Conformity..............................................14

Introduction

1 Introduction

By purchasing the IXXAT USB-to-CANV2 interface, you decided for a high-

quality electronic component developed and manufactured according to the

latest technological standards.

This manual describes the USB-to-CANV2 compact, USB-to-CANV2 embedded,

USB-to-CANV2 professional as well as the USB-to-CANV2 automotive CAN in-

terface.

In the further description these interfaces are referred as CAN-interface.

The properties of the CAN interfaces are:

USB-to-CANV2 compact / embedded

USB 2.0 Hi-Speed (480MBit/s)

one CAN-High-Speed channel according ISO11898-2

optional galvanic CAN bus isolation

fieldbus connection:

ocompact: Sub-D9M or RJ45

oembedded: Sub-D9M

USB-to-CAN V2 professional

USB 2.0 Hi-Speed (480MBit/s)

two CAN-High-Speed channels according ISO11898-2

galvanic CAN bus isolation (both CAN channels are on the same potential)

fieldbus connection: 2 x RJ45

equipped with two cable adapter RJ45 to Sub-D9M

USB-to-CAN V2 automotive

USB 2.0 Hi-Speed (480MBit/s)

two CAN-High-Speed channels according ISO11898-2, CAN1 can be

switched between high- and low-speed (ISO 11898-3) via software.

one LIN-Interface V1.3, Master/Slave-Mode switchable via software.

Please refer to the instructions in chapter 4.2

galvanic fieldbus isolation (all field bus channels are on the same potential)

fieldbus connection: 2 x RJ45

equipped with two cable adapter RJ45 to Sub-D9M

Installation

2 Installation

2.1 Software installation

To operate the interface a driver has to be installed first. For Windows this

driver is part of the VCI (Virtual CAN Interface) V3, which can be downloaded

for free on the IXXAT webpage http://www.ixxat.com.

For installation of the VCI V3 driver on Windows comuters, please refer to the

VCI installation manual.

IXXAT also offers the ECI driver for Linux and real-time operating systems for

many CAN interfaces. Information on supported operating systems and inter-

faces is available on the IXXAT webpage http://www.ixxat.com.

2.2 Hardware installation

Before connecting the CAN interface to the USB socket on your PC, you

should install the software driver first(see previous section).

2.2.1 USB-to-CANV2 compact / professional / automotive

The CAN-Interface can be connected on the fly (hot plug support).

2.2.2 USB-to-CANV2 embedded

For all work on the PC and interface, you must be statically discharged. Work

must be carried out on an earthed, anti-static work mat.

Take the following steps in sequence:

(1) Switch off the PC and unplug the power cord.

(2) Open the PC according to the instructions of the PC manufacturer

and find a suitable slot. The cable for the internal USB connection is de-

signed according to standard USB plugs (see chapter 4.3). Please note

the polarity and the occupancy of the pin connector in your PC. Do not

use force when plugging in.

(3) Make sure that the interface sits tightly in the PC.

(4) Close the PC; the hardware installation is now complete.

Connectors and displays

3 Connectors and displays

3.1 USB connector

The shield of the USB cable is connected to ground using a 100nF capacitor

and therefore also connected to ground of the USB plug.

It is recommended, that the interface is directly connected to PC USB ports or

to self powered USB hubs to ensure sufficient power supply.

USB-to-CANV2 compact / professional / automotive

The USB-cable has a plug type "A". The assignment corresponds to the

USB 2.0 standard.

USB-to-CANV2 embedded

The USB-cable has a 5-pin female connector. The assignment corre-

sponds to PC standard for internal USB devices (see chapter 4.3).

3.2 Fieldbus connector

The assignment of the fieldbus connectors (Sub-D9 and RJ45) is in accord-

ance to CiA 303-1.

The shield of the CAN connector is connected to CAN ground via a 1 MΩ re-

sistor and a 10 nF capacitor. The shields of the CAN connectors of the var-

iants USB-to-CANV2 professional and USB-to-CANV2 automotive are connect-

ed directly together.

For non galvanic decoupled CAN interfaces, fieldbus ground and PC ground

are at the same potential.

For best noise immunity, the shields of the CAN cables must directly connect-

ed to ground.

The pin assignment of the connectors CAN interfaces are shown below.

3.2.1 USB-to-CANV2 compact

Pin No.

Signal

Sub-D9

RJ45

CAN-High

CAN-Low

GND

3,6

3, 7

Connectors and displays

3.2.2 USB-to-CANV2 professional

RJ45, Pin No.

Adapter cable

1.01.0074.01000

Signal

CAN 1

CAN 2

Sub-D9M, Pin No.

CAN-High

CAN-Low

GND

3,7

3, 7

3, 6

Two RJ45 to Sub-D9M adapter cable will be delivered with the USB-to-CANV2

professional. The cable can be ordered separately too using order number

1.04.0074.0100.

3.2.3 USB-to-CANV2 automotive

RJ45, Pin No.

Adapter cable

1.01.0074.01000

Signal

CAN 1

CAN 2

Sub-D9M, Pin No.

CAN-High

CAN-Low

GND

3,7

3, 7

3, 6

CAN-High LS

CAN-Low LS

LIN

VBATLIN1

Two RJ45 to Sub-D9M adapter cable will be delivered with the USB-to-CANV2

automotive. The cable can be ordered separately too using order number

1.04.0074.0100.

Picture 3-1: adapter cable RJ45 / Sub-D9M 1.04.0074.01000

1see chapter 4.2

Connectors and displays

3.3 Displays

The CAN-Interfaces have LED´s that shows the current communication status

of USB and fieldbus activities and are labeled with the appropriate name.

3.3.1 USB LED

Light

pattern

Description

Causes / Hints

off

No communication via USB

•Device not properly initialized, maybe

the USB port can´t provide enough

power.

•

Device not connected to USB port

green

USB communication pos-

sible

•Device ready for action

red flash

State change

power saving



active

•Change power state

3.3.2 CAN LED

Light

pattern

Description

Causes / Hints

off

No CAN communication

•No CAN communication.

•

Device not connected to CAN

green/

green

flash

CAN communication

•With each CAN message the LED is

triggered

red blink-

ing

CAN communication,

CAN controller in error

state

•The CAN controller is in "Error Warning"

of "Error passive" state. CAN communi-

cation is further possible.

red Bus Off •The CAN controller is in "Bus Off" state.

No CAN communication possible

Connectors and displays

3.3.3 CAN1 LS LED

CAN-Low Speed functionality according to ISO11898-3 is only available on

USB-to-CANV2 automotive.

Light

pattern

Description

Causes / Hints

off

CAN High-Speed

transceiver active

•CAN high speed interface is activated

orange CAN low speed (fault

tolerant) transceiver active

•CAN low speed interface activated

The communication status is shown on CAN1-LED (see chapter 3.3.2)

3.3.4 LIN LED

LIN functionality is only available on USB-to-CANV2 automotive.

Light

pattern

Description

Causes / Hints

off

No LIN

communication •No LIN communication on the LIN bus

•

Device not connected LIN bus

green/gre

en flash

LIN communication

•With each LIN message the LED is trig-

gered

red/red

flash

LIN communication with

errors

•On transmission or reception of a LIN

message an error was detected

Otros manuales para USB-to-CAN compact

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Interfaz USB de IXXAT

IXXAT

IXXAT USB-to-CAN V2 Manual de usuario

Manuales populares de Interfaz USB de otras marcas

PASCO

PASCO SCIENCEWORKSHOP 750 Manual de usuario

Phonic

Phonic FIREFLY 302 USB Manual de usuario

OHAUS

OHAUS Scout STX Series Manual de usuario

Denon

Denon DN-HC4500 - DJ Mixer USB Controller Manual de usuario

Lutron Electronics

Lutron Electronics Stanza SZ-CI-USB-CPN5138 Manual de usuario

Paradox

Paradox PMC5-TI00 Manual de usuario

System Sensor

System Sensor M200WC-RF Guía

Philips

Philips PDIUSBD12 Manual de operación

KNX

KNX Module IC-USB-S.1 Manual de usuario

Velleman

Velleman KSR10/USB Manual de usuario

NIEUWKOOP

NIEUWKOOP RG7100 Guía de instalación

Alldaq

Alldaq ADQ-USB 2.0-ISO Manual de usuario

Thorsis Technologies

Thorsis Technologies isDNet USB Manual de usuario

Thorsis Technologies

Thorsis Technologies isHRT USB Manual de usuario

microHAM

microHAM DigiKeyer Manual de usuario

Apogee

Apogee Jam X Manual de usuario

RigExpert

RigExpert TI-3000 Manual de usuario

microHAM

microHAM USB Interface II Manual de usuario
