Itec C31METALG3HUB Manual de usuario

P/N: C31METALG3HUB

User guide • Gebrauchsanweisung • Mode d’emploi

Manual de instrucciones • Manuale • Uživatelská příručka

Instrukcje obsługi • Užívateľská príručka • Vartotojo vadovas

Handleiding

USB-C HUB 3 PORT

+ GIGABIT ETHERNET ADAPTER

Quick Start / USB-C HUB 3 Port + Gigabit Ethernet Adapter

EN Please read the entire instruction manual carefully. Detailed

manual is available on our website www.i-tec.cz/en/ in the tab

„Manuals, drivers“. In case of any issues, please contact our technical

support at: [email protected]

DE Bitte lesen Sie das gesamte Handbuch sorgfältig durch. Die

ausführliche Gebrauchsanweisung ist auch auf unserer Webseite

www.i-tec.cz/de/ unter „Benutzerhandbücher, Treiber“ bei diesem

Produkt zu finden.

Wenn Sie Probleme haben, kontaktieren Sie bitte

unser Support-Team unter: support@itecproduct.com

FR Veuillez lire attentivement le manuel dans son intégralité. Un

manuel détaillé est disponible sur notre site www.i-tec.cz/fr/ sous

l'onglet "Manuels, pilotes". Si vous avez des problèmes, veuillez

contacter notre équipe support à [email protected]

ES Por favor, lea atentamente todo el manual. El manual detallado

está disponible en nuestro sitio web, www.i-tec.cz/es/ bajo la

pestaña "Manuales y controladores" de este producto. Si tiene algún

problema, póngase en contacto con nuestro equipo de soporte en

[email protected]

IT Leggere attentamente tutto il Libretto d’uso. Il Libretto d’uso è a

disposizione anche sulla scheda “Manuali e strumenti” del nostro

sito web: www.i-tec.cz/it/. In caso di problemi rivolgersi al supporto

tecnico: [email protected]

CZ Prosíme o pečlivé přečtení celého manuálu. Podrobný manuál je

k dispozici na našem webu www.i-tec.cz v záložce „Manuály,

ovladače“ u tohoto produktu. V případě problémů se můžete

obrátit na naši technickou podporu: [email protected]

PL Upewnij się, że uważnie przeczytałeś instrukcji obsługi.

Szczegółowy podręcznik

jest dostępny na naszej stronie

internetowej www.i-tec.cz/pl/ w zakładce "Instrukcje, sterowniki".

W razie jakichkolwiek problemów, skontaktuj się z naszym

serwisem pod adresem: support@itecproduct.com

Quick Start / USB-C HUB 3 Port + Gigabit Ethernet Adapter

SK Prosíme o dôkladné prečítanie celého manuálu. Podrobný manuál

je k dis pozícii tiež na našom webe www.i-tec.cz v záložke „Manuály,

ovladače“ pri tomto produkte. V prípade problémov sa môžete obrátiť

na našu technickú podporu: [email protected]

LT Prašome įdėmiai perskaityti visą vadovą. Išsamų vadovą galite

rasti

mūsų svetainėje www.i-tec.cz/en/ šio produkto skyrelyje

„Manuals,

drivers“. Iškilus problemoms galite susisiekti su mūsų

technine pagalba: [email protected]

NL Wij vragen u vriendelijk om de volledige handleiding zorgvuldig

door te lezen. Een gedetailleerde handleiding van dit product

is beschikbaar op onze website www.i-tec.cz/nl/ onder het

tabblad "Handleidingen en drivers". Mochten er zich problemen

voordoen kunt u contact opnemen met ons supportcenter via

[email protected].

ENGLISH................................................... 08–10

DEUTSCH.................................................. 11–13

FRANÇAIS..................................................14–16

ESPAÑOL...................................................17–19

ITALIANO...................................................20–22

ČESKY........................................................ 23–25

POLSKI...................................................... 26–28

SLOVENSKY.............................................. 29–31

LIETUVOS................................................. 32–34

NEDERLANDS........................................... 35–37

WEEE......................................................... 38–39

Declaration of Conformity........................ 40–41

FCC...................................................................42

USB-C HUB 3 PORT

+ GIGABIT ETHERNET ADAPTER

Quick Start / USB-C HUB 3 Port + Gigabit Ethernet Adapter

(EN)

Cable with USB-C connector

3x USB-A 3.0 port

RJ-45 port

LED indication

(DE)

Kabel mit USB-C Konnektor

3x USB-A 3.0 Port

RJ-45 Port

LED-Kontrolleuchte

(FR)

Câble avec connecteur USB-C

3x USB-A 3.0 port

RJ-45 port

Voyant témoin lumineux LED

(ES)

Cable con conector USB-C

3x puerto USB-A 3.0

Puerto RJ-45

LED diodo

Quick Start / USB-C HUB 3 Port + Gigabit Ethernet Adapter

(IT)

Cavo con connettore USB-C

3 porte USB-A 3.0

Porta RJ-45

Spie LED

(CZ)

Kabel s USB-C konektorem

3x USB-A 3.0 port

RJ-45 port

LED dioda

(PL)

Kabel ze złączem USB-C

3x port USB-A 3.0

Port RJ-45

Dioda LED

(SK)

Kábel s USB-C konektorom

3x USB-A 3.0 port

RJ-45 port

LED dióda

(LT)

Kabelis su jungtimi USB-C

3x USB-A 3.0 prievadas

RJ-45 prievadas

LED dioda

(NL)

Kabel met USB-C-connector

3x USB-A 3.0-poort

RJ-45-poort

LED diode

Quick Start / USB-C HUB 3 Port + Gigabit Ethernet AdapterEN

INTRODUCTION

The HUB offers three USB 3.0 ports. The Gigabit Ethernet port allows

user's computer instantly connect to a 10/100/1000 Mbps network.

SPECIFICATION

• 1x USB 3.1 (Gen. 1) type C connector to connect HUB to laptop /

tablet / PC

• 3x USB-A 3.0 port for connecting USB equipment, backward

compatible with USB 2.0

• 1x Ethernet 10/100/1000Mb/s LAN RJ-45 port with function MDI/

MDIX and self-correction

• Realtek 0411 Chipset – USB 3.0 HUB

• Realtek 8153 Chipset – USB 3.0 to Gigabit Ethernet – supports

standard IEEE 802.3, IEEE 802.3u, IEEE 802.3ab and IEEE 802.3az

(Energy Ecient Ethernet)

• LED indication for Ethernet connection

• Supports Wake-on-LAN

• Operation temperature: 0-40°C

• Storage temperature: -10 to +80°C

• Humidity: up to 85%

• Dimensions: 96 x 30 x 21 mm

• Weight: 63 g

PACKAGE CONTENTS

• i-tec USB-C HUB 3 Port + Gigabit Ethernet Adapter with

integrated cable (28 cm)

• Quick Installation Guide

SYSTEM REQUIREMENTS

Hardware requirements: laptop / tablet / PC with free USB-C port

Operation System: Windows 7 / 8 / 8.1 / 10 32/64 bit, macOS X, Linux,

Android

Note:

Prior to installing the USB-C, make sure that there are (for the USB-C

3.1 controller in the laptop / PC) installed the latest drivers for it. In

case of outdated USB-C drivers problems during installation or use

may occur.

Quick Start / USB-C HUB 3 Port + Gigabit Ethernet Adapter EN

Installing the USB HUB (USB 3.0 ports type A) is automatic from

the system. This HUB will be automatically detected and installed

immediately after connecting to the USB port on your laptop / PC or

PCIe expansion card with internal USB 3.0 host controller.

DRIVER INSTALLATION

Windows Operating System

It is not necessary to install device drivers. The drivers are

automatically installed from the system or Windows Update after

the connection. In case of problems with the installation you can

download the drivers on www.i-tec.cz/en.

Mac Operating System

It is not necessary to install device drivers. The drivers are

automatically installed from macOS X after the connection. In case

of problems with the installation you can download the drivers on

www.i-tec.cz/en

CONNECTION TO A NOTEBOOK / PC

• Connect the USB cable to a USB port on your notebook / PC.

• Then start the automatic installation of USB ports in various

systems – it is recommended to be connected to the Internet for

online download of newer versions of drivers.

• Restart your notebook / PC.

• Connect the adapter to an available network when the

installation procedure is completed.

• Connect one end of the Ethernet cable into the RJ-45 port of the

device and the other end into an active element of your network -

HUB, switch, router (preferably with Gigabit speeds for maximum

speed adapter). If necessary, restart your notebook / PC.

VERIFYING THE DRIVER FOR ETHERNET PORT

To verify the driver of the adapter, follow the steps below to open the

Device Manager on Windows®

Following the path as below to open the device manager

• Windows®10: Start / Device Manager

• Windows®7 / 8 / 8.1: Control Panel / System and Security /

System / Device Manager

Quick Start / USB-C HUB 3 Port + Gigabit Ethernet AdapterEN

• In the Network adapters group, an item named „Realtek USB GBE

Family Controller“.

To verify the driver of the adapter, follow the steps below to open the

Device Manager on mac®

• Please connect the USB to LAN device to macBook / PC.

• Click the System Preferences →Network →USB Gigabit Ethernet

device active on line.

Note: If there is a (question) or (exclamation) mark next to that

item, then the driver is not properly installed. Please delete the item,

unplug the adapter and repeat the installation steps.

SAFETY INSTRUCTIONS

• Do not expose to extreme temperatures and air humidity.

• Use the device on at surfaces – you will prevent it from slipping

and falling to the ground.

• Save the user manual for a possible use later.

In cooperation with the service department:

• Check functionality after falling to water or to the ground.

• Check functionality when the cover is broken.

• Send the device back if it does not work in accordance with the

user manual.

FAQ

available on our website www.i-tec.cz/en/ on the „FAQ“ tab of this

product.
