IRiver T9 Manual de usuario

USER GUIDE

DESIGN BY IRIVER

CONTENTS

Getting Started

Components

Locating the Controls

Power Management

Connecting the Product

Using iriver plus 4

01 03

Using T9

Home Screen

MUSIC

FITNESS

RADIO

REC

BROWSER

SETTING

Other Information

Important Safety Information

Troubleshooting

Copyrights

Certification

Registered Trademark

Exemption

Components

Getting Started

Components may be changed without prior notice for improvement

of product performance or quality.

The exterior and the contents printed or engraved may differ by model

or according to the name of each part.

Locating

the Controls

Quick Start Guide

& Product warranty

Earphones

Earphones: Connect this to the product to output sound.

Quick Start Guide: Explains how to use our device.

Product Warranty: Please keep this in a safe place for use during any

warranty repairs.

Necklace Connection Loop

RESET Key

Earphones Jack MIC

Power

Getting Started

Down

LCD

Volume + Volume - USB Slide

USB Port

Left Right

Earphone Jack: Connect earphone here.

MIC: Records voice.

Power: Turn off the power by pressing and holding. Switch to standby

mode by pressing briefly.

while. You can switch to the standby mode by pressing it briefly.

Necklace Connection Loop: Connects with the necklace.

RESET: Resets the product.

LCD: Screen displays.

UP: Menu – Moves up in the list.

While playback – Playback and Rewind of previous file.

Listening to radio – Moves to the previous frequency / channel.

Down: Menu – Moves down in the list.

While playback – Playback and Fast Forward of next file.

Listening to radio – Moves to the next frequency / channel.

Left: Moves to upper menu / previous page.

Right: Confirm and execute the selected items.

USB Port: Connect to computer or recharge the battery using this port.

Volume: Controls the sound volume.

USB Port Slide: Pulls out or insert USB port by pushing slide.

Getting Started

1. Lock the device during use by pressing the [ ] button.

2. Unlock the device by pressing the [ ] button again.

Power

Management 1. Press and hold the [ ] until power comes on.

2. If you press and hold the [ ] when the product is turned on, then

the power will be turned off.

Power on/off

This model supports an automatic power-saving feature to minimize battery

consumption. Depending on [SETTING – Timer - Auto Power off], the product will be

automatically turned off when keys are not operated for a specified time. (Refer to page 20)

Even if you use reset function, current time and memory data will be preserved.

Do not use reset function while the product is playing. It may cause severe damage

to its memory.

Using the Hold Function

1. If buttons will not work while the device is being used, press

[RESET].

Using the Reset Function

1. Turn on your computer.

2. Press USB port slide, pull out USB port by sliding it to the direction

of arrow and connect the product with your computer.

The internal battery will charge automatically.

Charging the Battery

Getting Started

Connecting

the Product 1. Connect the earphones to the earphone jack.

Connecting Earphones

1. Turn on the device and computer.

2. Press USB port slide, pull out USB port by sliding it to the direction

of arrow and connect the product with your computer. You will see

the screen where you can select connection mode.

- Power & Data: The connection between the product and the

computer is established and you can start transferring data.

- Power Only: The product is currently being charged.

Connecting to Your Computer

For successful computer/USB connection, disable all functions.

Check that the product is connected to a high-power USB 2.0 port. Connecting to a

keyboard or a USB hub without a power supply its own may result in malfunction.

File system does not support other than FAT32. Format this device into FAT32.

Verify that the product is connected to a high-power USB 2.0 port. Some low-power

USB ports built into certain peripheral devices, such as some types of keyboards

and USB hubs without internal power may not provide enough power to charge.

While the PC is switched to standby mode, the product may not be charged.

Turn the product off when charging. Leaving the device turned on during recharge

may prevent “Charge Complete” from being displayed.

The battery will be fully charged within about 2 hours 30 minutes. (Based on fully

discharged, power Off).

Charging times may vary if device is used during recharge.

Charge and store the product only at room temperature. Charging times may vary if

device is used during recharge.

The rechargeable battery is a consumable and the available usage time of charged

battery becomes shorter over time.

Getting Started

1. Safely disconnect the product from your computer by clicking the

icon on the taskbar of the computer screen.

2. Confirm the device disconnection by clicking [Confirm].

Disconnecting from your computer

1. After selecting files/folders to copy from your computer, drag and

drop the selected file/folder to the added drive.

Copying Files (Folders) to the Product

Depending on the operating system for example Windows XP, the icon may be

hidden from the taskbar. Hidden icons can be displayed by clicking indicator.

Safe disconnection may not be performed if application programs such as Windows

Explorer or Windows Media Player are being used.

Make sure that the product is safely disconnected after all the active application

programs are closed. If safe disconnection fails, try again later. Failure to safely

disconnect result in data loss.

Please connect the device to computer properly.

If the power of the computer or product is turned off or the USB cable is disconnected

while copying or moving files/folders, serious damage to the memory may result.

Transfer rate may differ depending on the computer or OS environment available for

your region.

It is recommended to save media files using iriver plus 4. When saving through

removable disk, rebuild Database in [SETTING – Advanced - Rebuild Library]. (Refer

to page 20)

Please allow free memory space proportional to the number of the files below. If

remaining memory space is insufficient, the power will not be turned on.

100 files: 5MB, 500 files: 7MB, 1000 files: 9MB, 2000 files: 14MB, 3000 files: 25MB

If you save too many files on the device, you may have to wait too long for rebooting.

Getting Started

1. Select the files/folders to be deleted, right-click on them and select

[Delete].

2. Click [Yes] when the [Confirm File/Folder Deletion] window pops up,

and the selected files/folders will be deleted.

Deleting Files (Folders) from the Product

Please download the iriver plus 4 software program from the iriver website (www.iriver.com).

Minimum computer specifications are:

Windows® XP

- Intel® Pentium®Ⅱ 233MHz or above

- Memory: 64MB or above

- 30MB or more free space

- 16bit Sound Card and Speaker

- Microsoft Internet Explorer V 6.0 or above

- SVGA or high-resolution monitor (min 1024x768 resolution)

Using

iriver plus 4 iriver plus 4 is integrated software that manages a variety of

multimedia files. Using iriver plus 4, you can transfer files on the

computer to the product and do automatic firmware upgrade.

1. After installing the iriver plus 4 software program, you will see the

installation guide screen appearing.

2. Follow the step-by-step instructions on the screen to complete

the installation process.

Installation

Getting Started

Windows® Vista Specifications

(For Windows® Vista, note that only the 32-bit version will be supported.)

- Intel® Pentium®Ⅱ800MHz or above

- Memory: 512MB or above

- 20MB or more free space

- 16 bit Sound Card and Speaker

- Microsoft Internet Explorer V 6.0 or above

- SVGA or high-resolution monitor (min. 1024x768 resolution)

Windows® 7 Specifications (For Windows® 7, note that only 32-bit version will be

supported.)

- 1GHz or above, 32-bit processor

- Memory: 1GB or above

- 16GB or more free space

- DirectX 9 Graphic Device with WDDM 1.0 higher Drive

- SVGA or high-resolution monitor (min. 1024x768 resolution)

- Maximum file size for transfer: 4GB.

1. When iriver plus 4 is first run, the Add Media Wizard will be executed.

2. Follow the screen instructions to add library media files such as

music, video, photo, and texts stored in the computer.

Adding Media to the Library

1. Insert a music CD into the CD drive and execute iriver plus 4.

2. Select the music checkboxes you want to extract from [CD] tab in

iriver plus 4 and click [CD Ripping] at the bottom left.

3. When the music extraction is complete and [All Music] is selected,

the extracted music files have been added to the library.

Extracting Media from a CD

1. Connect the product to your computer’s USB port and then

execute iriver plus 4.

2. Select the file checkboxes you want to transfer from your computer

to the Product and then click [Transfer] button or drag & drop the file

to Device icon at the bottom or Device window.

Transferring Media to the Product

Getting Started

File transfer status is displayed in the [File Transfer] tab.

3. When the file transfer is complete, the selected music files have

been added to the device library.

1. Connect the device to your computer’s USB port and then execute

iriver plus 4.

2. Select [Device > Initialize Disc]. When the window pops up asking

whether to proceed with initializing the disc, click [Start].

3. When the initialization process is finished, the Complete window will be

displayed and the device can be disconnected from your computer.

Initializing the Disc

File recovery is not possible if files have been deleted from the device. Backup all

data before initializing the disc.

1. Connect the device to your computer’s USB port while connected

to the Internet and then execute iriver plus 4.

2. Select [Device > Firmware Upgrade], and the Upgrade window will

be displayed. Complete the firmware upgrade by following the

instruction window.

Upgrading the Firmware

Insufficient battery power may prevent initiation of firmware upgrade.

Never disconnect the device from your computer while a firmware upgrade file is

being downloaded.

After the download is completed, the upgrade will be initiated when the device is

disconnected from your computer.

A pop-up window will display the version of firmware installed.

When newer firmware versions are available, a notification window will be displayed

when the device is connected to the computer.

Tabla de contenidos

Otros manuales de Reproductor de MP3 de IRiver

IRiver

IRiver H10 20GB Manual de usuario

IRiver

IRiver PMP-120 Manual de usuario

IRiver

IRiver iFP-300 Series Manual de usuario

IRiver

IRiver H10 Manual de usuario

IRiver

IRiver H10 Manual de usuario

IRiver

IRiver iFP-120 Manual de usuario

IRiver

IRiver H300 Series Manual de usuario

IRiver

IRiver T60 1GB Manual de usuario

IRiver

IRiver E100 4GB Manual de usuario

IRiver

IRiver MP3 Player T30 Manual de usuario

IRiver

IRiver Astell&Kern AK70 Manual de usuario

IRiver

IRiver Astell & Kern AK120 II Manual de usuario

IRiver

IRiver T6 2GB Manual de usuario

IRiver

IRiver T10 1GB Manual de usuario

IRiver

IRiver iFP-195T Cómo utilizar

IRiver

IRiver IFP-800 Series Instrucciones de montaje

IRiver

IRiver IFP-800 Series Instrucciones de montaje

IRiver

IRiver X20 Manual de usuario

IRiver

IRiver Data Play IDP-100 Manual de usuario

IRiver

IRiver iFP-380T Manual de usuario

IRiver

IRiver N10 512MB Manual de usuario

IRiver

IRiver T20 Manual de usuario

IRiver

IRiver S100 Soft Silhouette Manual de usuario

IRiver

IRiver astell & kern AK120 Manual de usuario

Manuales populares de Reproductor de MP3 de otras marcas

Blaupunkt

Blaupunkt Compact Drive MP3 Manual de usuario

Memorex

Memorex MMP9008 - 8GB USB 2.0 Manual de usuario

Meizu Electronic Technology

Meizu Electronic Technology E5 Manual de usuario

Naxa

Naxa NMV-173NX Manual de usuario

Philips

Philips PSA250 Manual de usuario

Zipy

Zipy go! Waving Manual de usuario

Sylvania

Sylvania SMPK4068 Manual de usuario

Sony

Sony NW-MS7 - Memory Stick Walkman Manual de usuario

Irradio

Irradio RF-42UC Manual de usuario

NABAIJI

NABAIJI SWIM MUSIC 100 Manual de usuario

Laser

Laser MP3-A9-4GB Manual de usuario

Samsung

Samsung YP-T7F Manual de usuario

Savant

Savant SMS-1001-00 Guía de referencia rápida

Trevi

Trevi XP 71 BT Manual de usuario

AGPtek

AGPtek C2 Manual de usuario

MobiBlu

MobiBlu DAH-1500i Manual de usuario

Denver

Denver MPS-201 Manual de usuario

Steren

Steren MP3-002 Manual de usuario
