IPC CT51 BT Manual de usuario

This guide is intended for quick consultation only and does not replace the user and maintenance manual.

Before using the machine, read the user and maintenance manual contained in the machine’s packaging thoroughly and strictly follow all the

instructions.

PREPARATION & OPERATION

CT51-71 BT Quick Guide

PLDC03880

SET

ECO

AUTO

CHEM

H O

REPLACING THE SQUEEGEE BLADES

ATTACHING/REMOVING THE BRUSHES

Open the clip (Ref. 1).

Remove the two blade retainers (Ref. 2) by pushing them outwards then extracting them.

Remove the blade.

screws on the body of the squeegee.

Reposition the two blade pressing devices by centering the wider part of the slots on the squeegee body fastening pins, then push the blade pressing

devices inwards.

Close the hook again.

Replace the squeegee on its support, following the instructions described previously.

Automatic brush attachment, version with head lift pedal:

raise the machine head by pushing the head lift pedal (Fig. 1) down and to the left, then using the operation selector, select the Brush control, rest

Automatic brush release, version with head lift pedal: raise the machine head by pushing the head lift pedal (Fig. 1) down and to the left, turn the selector

to the “OFF” position, press the “SET” button once then press the “-” button, the machine will complete the release sequence.

DAILY MAINTENANCE

Clean the dirty

water tank.

Check that the

is clean.

Check that the brushes are

clean. Replace if necessary.

Check that the

squeegee is clean

and the blades are not

worn.
