IONIA SM-S112TL Instrucciones de uso
Warning: Incorrect installation and/or operation could void your valuable warranty.
Please protect your investment! READ THIS MANUAL CAREFULLY
Alkaline Ionic Water System
Renement of Alkaline Ionized water
(Hexagonal & Hydrogen Water)
SM-S112TL
Owner’s Operation Manual
02
Safety Precautions
Hot
Water
If a break down occurs, do not make a repair by yourself. Contact the sales
distributors or service center.
If your ionizer becomes submerged
in water, unplug the power cord from
the wall BEFORE removing the
ionizer from the water.
Failure to do so may
cause electric shock!
NEVER attempt to repair or service the unit
yourself.
Contact your dealer.
Attempting to do so will void your valuable
warranty!
Do not use your ionizer at voltages other than
specified.
Do not plug in your ionizer where it will exceed
the rating of outlet or electric wiring.
Failure to do so can result in fire, injury and / or
damage to yourself, wiring or ionizer!
NEVER touch the power cord or plug with
wet hands
- this may result in electric shock!
Protect your ionizer from freezing temperatures.
Protect your ionizer from direct sunlight.
Ensure the power plug is firmly and
properly inserted into the outlet
- failure to do so may result in electric shock or fire!
Do not attempt to repair or service the unit yourself. Contact your dealer.
Attempting to do so will void your valuable warranty!
Make sure to use your ionizer only with potable water which is suitable for
human consumption.
DO NOT use your ionizer with well water, water with extreme hardness,
high sediment or TDS levels without first consulting your dealer.
Do not run hot water through your ionizer.
Do not clean by pouring water over or spraying
the ionizer.
Unplug your ionizer if you plan not to use it for an
extended period or turn off the main power switch
on the back of the unit.
Filter replacement may be
necessary
03
Do not close, bend, pinch, press or otherwise
obstruct output ports or hoses.
If the appliance makes strange or unusual noises
or burning smells are detected, unplug the power
cord immediately and contact your dealer to
arrange service.
pH Reagent Liquid Precautions
Some helpful tips
Do not expose the pH measuring reagent to extreme heat, flames or fire.
It is combustible.
For storing your alkaline water, glass or ceramic is best. Always try and
keep your stored water cool and away from direct sunlight.
You can use plastic, but only use lexan (number7) or poly bottles
(Can type). It is always best fresh out of the machine and ideal
if consumed on a day-today basis.
Do not store alkaline water in stainless steel, bronze or
aluminum containers.
Save the box and Styrofoam your ionizer came packed in.
This will help if your ionizer needs to be transported at a later date.
Do not use an ionizer downstream of a sodium-based ion exchange
softening system or Reverse Osmosis system without first consulting
with your dealer.
Do not drink the pH reagent liquid, put it in the eyes or drop on the body.
- If the liquid is ingested, induce vomiting immediately and call a doctor.
- If the liquid gets in the eyes, flush immediately and thoroughly with
cool water; call a doctor.
- If spilled or dropped on your body, wash if off immediately.
Make sure to keep the pH reagent liquid tightly closed and out of the
reach of children.
04
Names and functions of Parts
Body
Function display panel
Flexible stainless
steel alkaline water
outlet.
Function button
FRONT
BACK
Accessories
pH test kit Spare adaptor Inlet White
Hose(2.7m) Outlet White
Hose(1.2m) Color chart Alkaline water
flex hose
Manual
Filter Cover
Power switch
Fuse holder
Acidic water
discharging hole
Water supplying hole
A/C power cord
05
INDICATORS
Displaying filter lifespan
Indicating total amount of filter use
Alkaline selection button
Button which is used when function of alkaline
water is selected
Setting display
Method to use lamp which is on when each
function is selected
Water purification button
Button which is used when function of water
purification is selected
Acidic selection button
Button which is used when function of acidic
water is selected
Power button
Button which is used when on/off
Setting button
Button which sets each function
Voice button (muting voice sound)
Function that can make voice sound on/off which
is made when each function is selected
Displaying water discharging time
Indicating time during which water is discharged
Displaying number of grade in use
Indicating number of grade in alkaline/acid and
purification currently in use
Displaying pH
Indicating pH for each grade
Displaying volume of supplied water
Indicating total water flow per minute
Alkaline2
pH
Filter
Flow
Running Time
9 .0
3888
1.6
00:00:14
06
How to Install
Install the hose for acidic water lower than the main body.
(when the hose is longer in length or locate above the body, it can affect the
generation of ion and the taste of water can be changed)
Install water pump when the water pressure is low and shortage of water
supply happens.
When using the underground water with high hardness,
- use the water softener.
- push the acid water button for one minute once a day for water circulation
Installation Precautions
Installation Precautions
Caution
INSTALLATION PROCEDURE (TYPE1)
Warning!
Keep order of Dust pre-Filter
and Constant ow valve
when machine is installed
Dust Pre Filter
Source water
Inlet
Adaptor
Outlet
INSTALLATION PROCEDURE (TYPE2)
Source water
Dust Pre Filter
Inlet
Cold water valve
Outlet
07
INSTALLATION PROCEDURE (TYPE1)
adaptor
Install after closing water supply.
outlet
inlet
1
Please assemble the faucet top
(water top) and the adaptor as
shown above.
3
Push in and fasten the 4Ø (PE)
`hose in "Figure 2" into the water
inlet at the bottom of the machine.
4
Connect hose to the outlet of acid
water and connect it to the acid
water tank or drain to sink bowl.
2
Connect 4Ø (PE) hose to the
adaptor in "Figure 2"
[Figure 2]
[Figure 4]
[Figure 1]
[Figure 3]
[Figure 5] [Figure 6]
5
After finishing the connection of
"Figure 4" open the water supply
valve and adjust the water
pressure.
6
Check the leaks on the connections
part after installation completed.
adaptor
PE Hose
inlet
08
INSTALLATION PROCEDURE (TYPE2)
Install after closing water supply.
2
Connect 4Ø (PE) hose to the
Diverter in "Figure 2"
3
Push in and fasten the 4Ø (PE)
`hose in "Figure 2" into the water
inlet at the bottom of the machine.
4
Connect hose to the outlet of acid
water and connect it to the acid
water tank or drain to sink bowl.
5
After finishing the connection of
"Figure 4" open the water supply
valve and adjust the water
pressure.
6
Check the leaks on the connections
part after installation completed.
1
Loosen the nut of the cold water
valve.
[Figure 4]
[Figure 1]
[Figure 3]
[Figure 5] [Figure 6]
Cold water valve
[Figure 2]
PE Hose
inlet
outlet
inlet
diverter
How to Install
09
How to Use
OFF
ON
1. POWER UP YOUR IONIZER.
The water may initially come out discolored (light to charcoal gray) due to carbon
particulates in the new filter. This is not harmful and is typical of all carbon filters.
Allow the water to flow for 2-3 minutes in the "Filtered Only" mode and this will
flush all the carbon dust.
NOTE
Turn on power switch on back side
after plugging power code into socket.
2. START WATER FLOW THROUGH YOUR IONIZER
Signal sounds, initial screen appears and disappear
again which makes it stand-by status.
- Press the "POWER" button which opens the internal valve in your ionizer.
- The Digital Filter Life Indicator will begin and you will hear your ionizer's "voice"
announcing the selected mode of operation.
Alkaline2
pH
Filter
Flow
Running Time
9 .0
3888
1.6
00:00:14
er
r
3
38
38
8
88
88
k
te
TO SELECT ALKALINE WATER
2.
When pressing alkaline water selection
button, graphic lamp is on which
indicates character of alkaline water,
number of grade, and announcement
can be heard which informs
alkaline water grade.
1.
Repeat steps 1-3 above, or with water already running through the machine then:
HOW TO STOP
Press the power button, water supply is
stopped and it is converted to
stand-by status automatically.
If alkaline water function is set previously, alkaline water used in previous step is discharged
NOTE
12 3412 34
Alkaline2
pH
Filter
Flow
Running Time
9 .0
3888
1.6
00:00:14
e
e
e
2
2
2
2
e
Whenever you press alkaline
water selection button
repeatedly, it changes
number of grade.
How to Use
Stand-by mode status
