Crown AC140 User Manual (1-Pack)

InWin’s ﬁrst 140mm case fan, CROWN AC140 inherits the

technical marvels of InWin’s previous models. Saturated,

addressable RGB lighting eﬀects and our patented modular

design makes this beautiful static pressure fan simple to

install. CROWN AC140 possesses innovative features to

maximize airﬂow and keep a cooled rig.

Product Story

Package Contents

A 1. CROWN AC140 Fan x 1

B 2. Screws x 4

C 3. Addressable RGB LED Y-Cable

(Connect Motherboard to Fan) 800mm x 1

D 4. 6-6 Pin Long Connecting Wire

(Connect Fan to Fan) 1000mm x 1

E 5. 6-6 Pin Short Connecting Wire

(Connect Fan to Fan) 100mm x 1

F 6. 3 Pin Header x 1

A x1

F x1

E x1

D x1

C x1

B x4

*The included addressable cable can only be used with the motherboard with addressable RGB

headers. Please make sure your motherboard supports addressable RGB lighting.

Installation

1. Please make sure the power is oﬀ.

2. Install the fans in your PC case, and screw it in the

designated areas.

3. Use Addressable RGB Y-Cable to connect the fan and

the motherboard. Please use ADD 3-Pin connector to

an ADD RGB header, and 4-pin fan connector to a fan

header on the motherboard.

4. Use the Addressable RGB Y-Cable 6-pin header to

connect the fan.

KEY

+5V

GND

ASUS Gigabyte

+5V

GND

KEY

Motherboard

Fan

ADD RGB

Troubleshooting

If your fan does not operate properly, please follow the

instructions below:

1. Please check your system’s power.

2. Please make sure all the connectors are connected

properly.

D E D E

5. If you are adding more CROWN fans, please start from

step 4 to chain with the other fans.

(*When connecting more than 5 fans, please use another Addressable RGB Y-Cable

to connect the 6 or more fans.)

Note to use

1. Please install the fan by following our instructions.

2. When storing the fan, please keep this product away from

high temperatures. Keep away from machines such as

heaters that might cause high temperatures.

3. Please do not put anything in the impeller.

4. Please do not modify the wire or the connector provided

by InWin.

5. Please do not touch the fan blades when the fan is in

operation.

6. Please only use your fan in the computer case.

7. Please keep this product away from any liquid.

Speciﬁcations

*Speciﬁcations may vary based on diﬀerent regions.

Product Name

Part Number

Fan Size

Materials

Rated Voltage

Rated Power

Rated Current

ADD RGB Rated Voltage

ADD RGB Rated Power

ADD RGB Rated Current

Speed Mode (PWM)

/ Noise Level

Air Flow

Air Pressure

LED

Fan Connector

Noise Level

Bearing Type

Life expectation

Net Weight

Package Dimension

(HxLxW)

Warranty

CROWN AC140

Single Pack - AC140FAN-1PK

Twin Pack - AC140FAN-2PK

140 x 140 x 25mm

PBT, PC

DC 12V

2.4W

0.2A

DC 5V

1.5W

0.3A

PWM 500~1500 R.P.M /

18.1~ 32.5dB(A)

69.03 CFM

1.93mm/ H2O

Addressable RGB

6-Pin Modular

32.5 dB(A) Max.

Long Life Sleeve Bearing

60,000 hrs/ 40℃

185.6g

245mm x 160mm x 33mm

(Single Pack)

245mm x 160mm x 65mm

(Twin Pack)

2 years
