inveo RFID IND-M1 Manual de usuario
User manual
RFID IND-M1 Reader
INVEO s.c.
ul. Rzemieślnicza 21
43-340 Kozy
Poland
mobile: +48 785552252
www.in eo.com.pl
info@in eo.com.pl
Dear Customer!
Thank you ery much for choosing our product. Before its use, please read these
instructions carefully. There are gi en here the most appropriate ways of dealing with
this de ice, the basic principles of safety and maintenance. Please also keep the user
manual so that you can read it during later use.
Remember!
The manu acturer is not liable or any damage caused by improper use o
the device or its intended purpose or improper handling, as well as ault driver
resulting rom improper use.
02/06/2018 User manual RFID-IND-M1 Page 2 z 21
Table o contents
1 PRELIMINARY INFORMATIONS..................................................................................................................5
2 PURPOSE OF THE DEVICE.............................................................................................................................6
3 WARRANTY AND LIABILITY OF THE MANUFACTURER....................................................................6
4 SAFETY GUIDELINES......................................................................................................................................7
4.1 POWER SUPPLY....................................................................................................................................................7
4.2 STORAGE, WORK CONDITIONS.................................................................................................................................7
4.3 INSTALLATION AND USE OF THE MODULE..................................................................................................................7
4.4 UTILISATION OF THE MODULE.................................................................................................................................7
5 CONSTRUCTION OF THE MODULE............................................................................................................8
5.1 GENERAL FEATURES.............................................................................................................................................8
6 DEVICE CONFIGURATION............................................................................................................................
6.1 OUTPUTS OUTPUTS OPERATING MODE...........................................................................................................10
6.2 INPUTS STATUS OF INPUTS............................................................................................................................11
6.3 BUZZER & LEDS LEDS AND SOUND SIGNALING CONTROL...............................................................................11
6.4 RS485 - CONFIGURATION RS485......................................................................................................................11
6.5 CARD SERIAL NUMBER - READ CARD NUMBER...........................................................................................11
7 MODBUS API FOR RFID IND-M1................................................................................................................12
7.1 MIFARE TAG STRUCTURE.....................................................................................................................................12
7.2 MODBUS ADDRESS TABLE.................................................................................................................................13
8 MEMORY BUFFER..........................................................................................................................................16
8.1 MEMORY BUFFER ADDRESSING.............................................................................................................................16
8.2 BUFFER DATA REPRESENTATION (ENDIANESS)........................................................................................................16
SECURITY SETTINGS....................................................................................................................................17
10 USER RESPONSE...........................................................................................................................................17
11 EXAMPLES......................................................................................................................................................17
11.1 STEP BY STEP READ OPERATION..........................................................................................................................17
11.2 STEP BY STEP WRITE OPERATION.........................................................................................................................17
11.3 STEP BY STEP MULTIPLE TAGS............................................................................................................................18
12 DESCRIPTION OF TERMINALS................................................................................................................1
13 DISTANCE FIXING HOLES.........................................................................................................................20
NOTES.................................................................................................................................................................21
02/06/2018 User manual RFID-IND-M1 Page 3 z 21
Be ore starting work with the device, read The User manual and ollow the
instructions contained therein!
02/06/2018 User manual RFID-IND-M1 Page 4 z 21
1 Preliminary in ormations
Be ore starting work with the device, read The User manual and ollow the
instructions contained therein!
Description of isual symbols used in this user manual:
This symbol is responsible for re iewing the appropriate place in the
user instructions, warnings and important information. Failure to
follow warnings could cause injury or damage to the module
Important information and guidelines
Following this guidelines makes the use of the module easier.
Attention: The appearance of the screen shots shown in this manual may differ slightly
from the actual work with the module. The differences may relate to the size and font
type and size of symbols. There are no differences in the content of the information.
02/06/2018 User manual RFID-IND-M1 Page 5 z 21
2 Purpose o the device
RFID-IND-M1 reader is used to read the Mifare transponders code. The transponder code
is a ailable using the MODBUS RTU protocol.
3 Warranty and liability o the manu acturer
The manufacturer pro ides a 2-year warranty on the module. The manufacturer also
pro ides post-warranty ser ice for 10 years from the date of the introducing the module
on the market. The warranty co ers all defects in material and workmanship
The manufacturer undertakes to comply with the contract of guarantee, if the following
conditions are met::
all repairs, alterations, extensions and device calibrations are performed by the
manufacturer or authorized service,
supply network installation meets applicable standards in this regard,
the device is operated in accordance with the recommendations outlined in this
manual
the device is used as intended..
The manufacturer assumes no responsibility for consequences resulting from improper
installation, improper use of the module, not following this manual and the repairs of the
module by indi iduals without permission.
This device doesn’t contain serviceable parts.
02/06/2018 User manual RFID-IND-M1 Page 6 z 21
4 Sa ety guidelines
The module has been constructed using modern electronic components, according to the
latest trends in the global electronics. In particular, much emphasis was placed on
ensuring optimum safety and reliability of control. The de ice has a IP65 hermetic
housing with a high-quality plastic.
4.1 Power supply
The module is suitable for power supply 10-24VDC.
4.2 Storage, work conditions.
The reader is equipped with a sealed IP65 enclosure which means:
•total resistance to foreign objects
•resistance to water jet directed directly to the de ice
•storage and operation at temperatures from -25 ° C to + 60 ° C,
4.3 Installation and use of the module
The module should be used ollowing the guidelines shown in next part o the
user manual.
4.4 Utilisation of the module
When it becomes necessary to liquidate the de ice (e.g., after the time of use), please
contact the manufacturer or its representati e, who are obliged to respond appropriately,
i.e., collecting the module from the user. You can also ask the companies in ol ed in
utilization and / or liquidation of electrical or computer equipment. Under no
circumstances should you place the de ice along with other garbage
02/06/2018 User manual RFID-IND-M1 Page 7 z 21
5 Construction o the module
.1 General features
The reader is equipped with an RS485 port supporting MODBUS RTU protocol and
a USB port used for configuration and testing of the module.
The de ice has two relay outputs and two inputs.
Technical data:
Supply oltage:12-24VDC
Power supply: 40mA (12V)
Transponders:
Supported transponder standard: Mifare
Carrier frequency: 13,56 MHz
Reading distance to 10cm (depending on the type of transponder used)
Communication:
1 RS485 port -modbus RTU
1 USB port to configuration
Inputs/Outputs
2 relay outputs
2 inputs
Dimensions:
(width) 100 mm x (height) 100 mm x (depth) 55.6 mm
02/06/2018 User manual RFID-IND-M1 Page 8 z 21
6 Device con iguration
After installing the RFID M1 Config program and starting it, connect the USB cable
to the computer and the module (in this case, the external power supply of the module is
not required - the de ice is plugged into the USB port).
The first line of the program window displays information about the ersion of the
configuration program - PC version, reader software ersion - RFID So tware and
reader ersion - RFID Hardware. We also ha e information on whether the
configuration program was connected to a reader - Connected - Not connected
Figure 1. Program window view
02/06/2018 User manual RFID-IND-M1 Page 9 z 21
6.1 OUTPUTS – Outputs operating mode
Mode – Sets the output mode. The output can work in the following modes:
DISABLE
BISTABLE
ASTABLE
TIME – the output will trip to the Time ON then the output will turn off (eg the
control of the electromagnet)
The work charts are shown in the figure below.
Power ON – the state of the output after turn on the power
•Active
•Inactive
Time ON – the time for which the channel is switched on (Astable and Time mode)
Time OFF – the time inter al between acti ations of the channel (Astable mode)
State – isualization of the output, if a rectangle is yellow it means that the output
current is turned on.
Buttons Out 1 and Out 2 outputs can be acti ate or deacti ate.
02/06/2018 User manual RFID-IND-M1 Page 10 z 21
t
on
t
off
t
on
t
off
t
on
t
off
t
on
t
on
BISTABLE
ASTABLE
TIME
