INVENTOR EU-OSK105 Manual de usuario

ENGLISH | ΕΛΛΗΝΙΚΑ | ROMANA | DEUTSCH

• USER’S MANUAL

• ΕΓΧΕΙΡΙΔΙΟ ΧΡΗΣΗΣ

• MANUAL UTILIZATORULUI

• BENUTZERHANDBUCH

Wi-Fi FUNCTION

AIR CONDITIONING SYSTEMS

Wi-Fi

CONTENTS

1 SPECIFICATION..................................................4

2 PRECAUTIONS ...................................................4

3 DOWNLOAD AND INSTALL APP......................5

4 INSTALL THE SMART KIT

(WIRELESS MODULE).........................................6

5 USER REGISTRATION ........................................7

6 NETWORK CONFIGURATION...........................8

7 HOW TO USE THE APP ....................................20

8 SPECIAL FUNCTIONS ......................................22

DECLARATION OF CONFORMITY

Hereby, we declare that this AC is in compliance

with the essential requirements and other relevant

provisions of Directive 2014/53/EU.

A copy of the full DoC is attached.

Model: EU-OSK105

Standard: IEEE 802. 11b/g/n Antenna Type: Printed PCB

Antenna

Frequency: 2400~2483.5 MHz

Operation Temperature: 0ºC~45ºC/32ºF~113ºF

Operation Humidity: 10%~85%

Power Input: DC 5V/300mA

Maximum Transmitted Power: <20dBm

2PRECAUTIONS

• Applicable system: iOS, Android.

(Suggested: iOS 9.0 or above, Android 6.0 or above)

- Please keep you APP up to date with the latest version.

- Due to special situation may be occurred, we explicitly

claims below: Not all of the Android and i OS system are

compatible with APP. We will not be responsible for any

issue as a result of the incompatibility.

• Wireless safety encryption

Supported Wi-Fi band: 2.4GHz

Smart kit only support WPA-PSK/WPA2-PSK encryption

and none encryption .

WPA- PSK/WPA2-PSK encryption is recommended.

• Cautions

- Due to different network situation, control process may

return time-out sometimes. If this situation occurs, the

display between board and App may not be the same,

please do not feel confused.

1SPECIFICATION

- Smart Phone camera needs to be 5 million pixels or

above to make sure scan QR code well.

- Due to different network situation , sometimes , request

time-out could happen, thus, it is necessary to do

network configuration again.

- The APP system is subject to update without prior

notice for product function improvement. The actual

network configuration process may be slightly different

from the manual, the actual process shall prevail.

- Please Check The Service Website For More information.

3DOWNLOAD AND INSTALL APP

CAUTION: The following QR Code is only for downloading

the APP. This is different from the QR code the SMART

KIT has on it.

Android iOS

• Android Phone users: scan Android QR code or go to

google play, search «Invmate II» app and download it.

• iOS users: scan iOS QR code or go to APP Store, search

«Invmate II» app and download it.

INSTALL THE SMART KIT

(wireless module)

1.Remove the protective cap of the smart kit (wireless

module)

2.Open the front panel and insert the smart kit (wireless

module) into the reserved interface.

3.Attach the QR code packed with Smart kit (wireless

module) to the side panel of the machine, ensure it

is convenient to be scanned by the mobile phone.

Alternatively, user can take picture of the QR Code and

save in into their own phone.

WARNING: This interface is only compatible with

SMART KIT (wireless module) provided by the

manufacturer.

Insert

USER REGISTRATION

• Please ensure your mobile device is connected to Wi-Fi

router. Also, the Wireless router has already connected

to Internet before doing user registration and network

configuration.

• You can log in with the third party accounts.

2.Enter your email address

and password, and then

click «Registration»

1.Click «Sign up»

VI 5

USER REGISTRATION

Please ensure your mobile device is connected to

Wireless router. Also, the Wireless router has already

connected to Internet before doing user registration and

network configuration.

It is better to log in your email box and active your

registration account by clicking link in case you forget

the password. You can log in with the third party accounts.

1Click "Create Account

Android iOS

2Enter your email address

an d password, and then

cl ick " "Register

NETWORK CONFIGURATION

Cautions

• It is necessary to forget any other local / nearby

networks and make sure the Android or i OS device

is connected to the Wireless network you want to

configure.

• Make sure during the configuration to keep your

mobile data connection turned off

• Make sure the Android or i OS device Wireless function

works well and can be connected back to your original

Wireless network automatically.

Kind reminder:

User must finish all the steps in 8 minutes after powering

on AC, otherwise you need to power on it again.

■Add New Device

1. Make sure your mobile device has already been

connected to the Wireless network which you

want to use. Also, you need to forget other local /

nearby Wireless networks in case it influences your

configuration process.

2. Disconnect the power supply of AC for 5 minutes.

3. Connect the power supply of AC, and continuously

press the “ LED DISPLAY” or “DO NOT DISTURB” button

seven times in 10 seconds.

4. When the AC displays “AP”, it means that the AC

wireless has already entered into “AP” Mode.

• Some type of AC do not need the 2 step to be in AP

mode

6.Select the appliance you

are setting up

5.Press “ + Add Device ”

Network configuration by Bluetooth scan

Note: Make sure the bluetooth of your mobile device is

working.

Press “ + Add Device ” Press “Scan for nearby

devices”

Network configuration by select appliance type :

If the bluetooth network

cofiguration is failure, please

select the appliance type.

Manually Add New Device:

7.Follow the above steps to enter “AP” mode.

please follow the above steps to enter “AP” mode.
