Invacare Excel Manual de instrucciones

Yes, you can. ™

Storm Series®

Ranger II™

Excel™

R2™ jr.

FWD

Power Wheelchairs

Parts Catalog Issued: Apr 24, 2012

The information contained in this document is subject to change without notice. This catalog contains

service parts for Form No. 98-289. If you have any questions regarding this catalog, please contact one

of our Customer Service Representatives.

For Customer Service Support Call:

1-800-333-6900

For Faxed In Orders Call:

1-800-678-4682 or

1-440-366-0709

For Technical Service Call:

1-800-832-4707

Literature Can Be Found at:

www.invacare.com or

1-800-828-6272

SYMBOL DEFINITION

Throughout this catalog you will notice letters to draw your attention to specific footnotes which are located at the

bottom of the page or below specified charts.

HARDWARE MEASUREMENTS

Examples: = Special Comments

= General information pertaining to that specific page

= No Longer Available

NOTE:

NLA

The measurements for the hardware will be listed as follows:

Screws, Bolts

Washers

Spacers

For your convenience, we have supplied an area for you to list your Invacare Representatives.

A,B,C etc.

Diameter X Thread Count/Pitch X Length

Inside Diameter X Outside Diameter X Thickness

Inside Diameter X Outside Diameter X Length

Name Phone Numbers

Corporation. Dynamic is a registered trademark of Dynamic Controls Limited. Tash is a registered trademark of Tash International Inc.. Therafin is a

registered trademark of W/R/ Medical Electronics Co..

Bussman is a registered trademark of Cooper Industries. MIDI is a registered trademark of Littelfuse Inc. Dynamic is a registered trademark of Dynamic

Controls Limited.

Parts Catalog Usage Guide

Form No. 98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Accessories - Headrest & Attaching Hardware - Sling Seat Only ............................................ 138

Accessories - Miscellaneous .................................................................................................... 140

Accessories - Oxygen Holder Assembly Kit - Captain Seat (After 4/14/03) ............................. 145

Accessories - Oxygen Holder Assembly Kit - Captain Seat (Before 4/15/03) .......................... 143

Accessories - Oxygen Holder Assembly Kit - Sling Seats Only ............................................... 147

Accessories - Power Wheelchair Tool Kit ................................................................................ 149

Arms - Captain Seat & Hardware ............................................................................................. 34

Arms - Excel ............................................................................................................................ 39

Arms - Ranger II / R2 jr. ........................................................................................................... 36

Back Canes & Attaching Hardware - Sling Seat Only .............................................................. 20

Battery Boxes & Trays .............................................................................................................. 51

Battery Boxes & Trays - R2 jr. (14" Wide) ................................................................................ 53

Battery Chargers & Harness - R2 jr. (14" Wide) ....................................................................... 58

Battery Chargers & Harnesses ................................................................................................. 55

Captain Seat Assembly (After 8/31/02) .................................................................................... 28

Captain Seat Assembly (Before 9/1/02) ................................................................................... 25

Captain Seat Frame & Actuator Hardware (After 8/31/02) ....................................................... 32

Captain Seat Frame & Actuator Hardware (Before 9/1/02) ...................................................... 30

Caster & Forks - Rear .............................................................................................................. 42

Crossbraces - Seat Extensions & Hardware - R2 jr. ................................................................ 16

Crossbraces - Seat Extensions & Hardware - Sling Seat ........................................................ 14

TABLE of CONTENTS

Description

Page

Number

To order call toll free 1-800-333-6900, or www.invacare.com

Form No. 98-289

Crossbraces & Hardware - Captain Seat ................................................................................. 18

Drive Wheel & Hub Mount (14 x 3") ......................................................................................... 49

Drive Wheel, 2-Pole Motor & Gearbox (Ranger II Basic, Excel and R2 jr.) (12-1/2 x 2-1/4") .. 44

Drive Wheel, 4-Pole Motor & Gearbox (Ranger II Standard) (12-1/2 x 2-1/4") ........................ 46

Electronics - COM12 & COM34 ............................................................................................... 129

Electronics - MKIV Controller, Programmer & Attaching Hardware ......................................... 126

Electronics - MKIV Displays ..................................................................................................... 131

Electronics - MKIV Joystick Mounting Hardware & Joystick Accessories ................................ 114

Electronics - MKIV Joystick Options ......................................................................................... 133

Electronics - MKIV Joysticks - Excel, RII, RX, A, A+, TCHJOY ............................................... 109

Electronics - MKIV Joysticks - PSF and PSR ........................................................................... 112

Electronics - MKIV Mid-Line Swing Bracket Assembly ............................................................ 118

Electronics - MKIV Recliner Control & Recliner Cable ............................................................. 130

Electronics - MKIV Sip-N-Puff/Digital Interface ........................................................................ 128

Electronics - MKIV Swivel Joystick Hardware .......................................................................... 116

Electronics - Quad Link Assembly (After 4/06/06) .................................................................... 123

Electronics - Quad Link Assembly (Before 4/07/06) ................................................................. 120

Electronics - Tash & Therafin Accessories ............................................................................... 136

Frame Finishes, Touch-Up Paint & Upholstery Options ........................................................... 6

Front Riggings - Adjustable Flip-Up Removable Footboard (After 2/29/00) ............................. 102

Front Riggings - Adjustable Flip-Up Removable Footboard (Before 3/1/00) ............................ 99

TABLE of CONTENTS

Description

Page

Number

To order call toll free 1-800-333-6900, or www.invacare.com

Form No. 98-289

Front Riggings - Calf Pads & Attaching Hardware ................................................................... 89

Front Riggings - Footrest & Legrest Accessories ..................................................................... 105

Front Riggings - Footrest Supports - P93M .............................................................................. 81

Front Riggings - Footrest Supports - PW93 ............................................................................. 75

Front Riggings - Footrest Supports - PW93E ........................................................................... 77

Front Riggings - Footrest Supports - PW93ST ......................................................................... 79

Front Riggings - Legrest Release Handle & Ratchet ............................................................... 87

Front Riggings - Legrest Supports - Articulating - PAS4A/PAL4A ........................................... 85

Front Riggings - Legrest Supports - P904A ............................................................................. 83

Front Riggings - Pivot/ Slide Tube w/ Footplate - PW93ST .................................................... 93

Front Riggings - Pivot/ Slide Tube w/ Footplate - P904, PAL4A, PAS4A ................................. 97

Front Riggings - Pivot/ Slide Tube w/ Footplate - P93M .......................................................... 95

Front Riggings - Pivot/ Slide Tube w/ Footplate - PW93, PW93E ............................................ 91

Front Riggings - Reference Chart ............................................................................................ 72

Packaging - Literature - Decals - Sling Seat w/ Shrouds & Captain Seat ................................ 10

Packaging - Literature - Decals - Sling Seat w/o Shrouds ....................................................... 8

Shroud Covers (After 2/29/00) ................................................................................................. 64

Shroud Covers (Before 3/1/00) ................................................................................................ 60

Shroud Covers R2 jr. (After 2/29/00) ........................................................................................ 70

Shroud Covers R2 jr. (Before 3/1/00) ....................................................................................... 68

Side Frames & Hardware ......................................................................................................... 12

TABLE of CONTENTS

Description

Page

Number

To order call toll free 1-800-333-6900, or www.invacare.com

Form No. 98-289

Solid Folding Seats & Inserts ................................................................................................... 23

Upholstery - Seat and Back ...................................................................................................... 21

Warranty Replacement Parts ................................................................................................... 151

TABLE of CONTENTS

Description

Page

Number

To order call toll free 1-800-333-6900, or www.invacare.com

Form No. 98-289

Frame Finishes, Touch-Up Paint & Upholstery Options

Frame Finishes and Touch-Up Paint

Color

Number Part

Number Bottle

Size Color

Pink Pearl.6 oz.103145202P Super Teal.6 oz.103145406P Deep Purple.6 oz.103145608P Cobalt Blue.6 oz.104631917P Anthracite.6 oz.103337622P Wet Black.6 oz.103145024P White.6 oz.103144729P Sunny Yellow.6 oz.103144830P Red.6 oz.103145533P Flat Black.6 oz.104632734P Electric Red.6 oz.104632161P Electric Blue.6 oz.104632062P Metallic Blue.6 oz.104632464P Teflon Black.6 oz.1101320-NLA69P Silver VeinN/AN/A71P Evergreen with Navy.6 oz.107389280P Dark Olive with Copper.6 oz.107389381P Fruit Punch with Fucshia.6 oz.107389482P Royal Blue with Grape.6 oz.107389583P Lavender.6 oz.107389684P Jeweled Green.6 oz.1101325101P Denim Blue.6 oz.1101327102P Mocha Frost.6 oz.1101324103P Electric Teal.6 oz.1101316104P Midnight Blue.6 oz.1101326105P

To order call toll free 1-800-333-6900, or www.invacare.com

Form No. 98-289

Frame Finishes, Touch-Up Paint & Upholstery Options

Sparkle Frame Finishes

Color Number Color

Twilight Sparkle72P Gold Sparkle73P Green Sparkle74P Blue Sparkle75P Red Sparkle76P Wet Black with Twilight Sparkle88P

Upholstery Options

Vinyl Colors Nylon Colors

U240 BlackU67 Black

U75 Dove Grey

U85 Dark Blue

U86 Ruby

U97 Sky Blue

U88 Camel

To order call toll free 1-800-333-6900, or www.invacare.com

Form No. 98-289

Packaging - Literature - Decals

Sling Seat w/o Shrouds

To order call toll free 1-800-333-6900, or www.invacare.com

Form No. 98-289

Packaging - Literature - Decals

Sling Seat w/o Shrouds

Item

Number Part Number DescriptionNote

Quantity Per

Package Assembly

40131X148 Carton, Hardware 1 11 1074356-NLA NLA - Insert, Carton 1 12 1023167 Carton, Battery Boxes 1 13 1074355 Carton 1 14 40131X011 Carton, Front Riggings 1 15 1058833 Carton 1 16 1015592 Bag, Poly (72" L x 35" W x 19" D) 1 17 1043198-NLA NLA - Tube, Paper 1 18 1080739-NLA NLA - Insert, Carton 1 19 1090146-NLA NLA - Decal, Invacare 3-D Logo (1-19/32" L) 1 210 A 1095224-NLA NLA - Decal, Model, Black - Ranger II 1 211 A,B 1095225-NLA NLA - Decal, Model, White - Ranger II 1 211 A 1095232-NLA NLA - Decal, Model, Black - Excel 1 211 A,B 1095233 Decal, Model, White - Excel 1 211 A 1090273 Decal, Model - R2 Junior 1 211 1080267-NLA NLA - Decal, Warning Motor 1 212 1080266 Decal, Warning Controller 1 113 40131X039 Insert, Carton 1 114 D 1097104-NLA NLA - Decal - 250-S 1 215 1080265-NLA NLA - Decal, FWD 1 2C 1065145-NLA NLA - Decal, Virtual Service 1 2C 1035900 Decal, Transportation 1 1C 1119281 Plate, Name, Patent Numbers 1 1C 1095272 Instruction Manual, MKIV RII 1 1C 1080722 Owner's Manual - Ranger II and R2 jr. 1 1C 1080737-NLA NLA - Owner's Manual - P9000 and Excel 1 1C

A - Invacare logo added and model decals changed 1/11/00. When replacing side frames before 1/11/00 order decals in pairs

to match.

B - Used for chairs with frame colors 02P, 29P, 30P, and 84P only.

C - Not Shown

D - R2 jr.

NOTE:

When adjusting or replacing parts, please refer to the Owner's Manual for assistance.

NOTE:

To order call toll free 1-800-333-6900, or www.invacare.com

Form No. 98-289
