Sabre 1555 RFID and

Bar Code Reader

Service Manual

Intermec Technologies Corporation

6001 36th Avenue West

Everett, WA 98203

U.S.A.

U.S. service and technical support: 1-800-755-5505

U.S. media supplies ordering information: 1-800-227-9947

Canadian service and technical support: 1-800-668-7043

Canadian media supplies ordering information: 1-800-268-6936

Outside U.S.A. and Canada: Contact your local Intermec service supplier.

The information contained herein is proprietary and is provided solely for the purpose of allowing customers to

operate and/or service Intermec manufactured equipment and is not to be released, reproduced, or used for any

other purpose without written permission of Intermec.

Information and specifications in this manual are subject to change without notice.

2002 by Intermec Technologies Corporation

The word Intermec, the Intermec logo, INCA (under license), MobileLAN, JANUS, IRL, Trakker Antares,

EZBuilder, TE 2000, Data Collection Browser, dcBrowser, Data Collection PC, Universal Access Point, UAP,

Duratherm, EasyCoder, Precision Print, PrintSet, Virtual Wedge, and CrossBar are either trademarks or

registered trademarks of Intermec.

Throughout this manual, trademarked names may be used. Rather than put a trademark (or )symbolin

every occurrence of a trademarked name, we state that we are using the names only in an editorial fashion, and

to the benefit of the trademark owner, with no intention of infringement.

There are U.S. and foreign patents pending.

Contents

iii

Contents

Before You Begin v

Warranty Information v

Safety Summary v

Warnings, Cautions, and Notes vi

About This Manual vii

Troubleshooting the 1555

About the 1555 1-3

Troubleshooting 1-4

Troubleshooting Guide 1-4

Replacing Parts in the 1555

Replacing Parts 2-3

Removing and Replacing the Extender Wedge (PDT 1555 only) 2-3

Removing and Replacing the Handle or Handle PCB 2-5

Replacing the Exit Window 2-10

Opening the 1555 2-12

Replacing the Piezo Assembly 2-14

Removing and Replacing the Digital Board 2-15

Replacing the RF Board Assembly 2-18

Removing and Replacing the Scan Engine 2-20

Removing and Replacing the Shield and Chassis Assembly (915 MHz 1555), or the

Antenna Assembly (2.4 GHz 1555) 2-23

Removing and Replacing the Lower Shell 2-26

Replacing the Upper Case Assembly 2-29

Reassembling the 1555 2-30

Testing the 1555

Overview 3-3

Accessories Needed for Testing 3-3

Equipment Needed for Testing 3-3

Replacing Product Labels on the 1555 3-3

Scanner and LED Operation Test 3-4

Sabre 1555 RFID and Bar Code Reader Service Manual

Bar Code Depth of Field Test 3-5

Setting Up for the Test 3-5

RFID Functional Test 3-7

Radiated Tag Read Test 3-7

Open Air Tag Read Test 3-9

Exploded View and Spare Parts List

Exploded View 4-3

Spare Parts List 4-4

Rework Procedures

Repairing the Mode Button A-3

Code39Before You Begin

Before You Begin

This section introduces you to standard warranty provisions, safety precautions,

warnings and cautions, document formatting conventions, and sources of additional

product information. A documentation roadmap is also provided to guide you in finding

the appropriate information.

Warranty Information

To receive a copy of the standard warranty provision for this product, contact your local

Intermec support services organization. In the U.S.A. call 1-800-755-5505, and in

Canada call 1-800-668-7043. If you live outside of the U.S.A. or Canada, you can find

your local Intermec support services organization on the Intermec Web site at

www.intermec.com.

Safety Summary

Your safety is extremely important. Read and follow all warnings and cautions in this

book before handling and operating Intermec equipment. You can be seriously injured,

and equipment and data can be damaged if you do not follow the safetywarnings and

cautions.

Do not repair or adjust alone Do not repair or adjust energized equipment alone under

any circumstances. Someone capable of providing first aid must always be present for

your safety.

First aid Always obtain first aid or medical attention immediately after an injury.

Never neglect an injury, no matter how slight it seems.

Resuscitation Begin resuscitation immediately if someone is injured and stops

breathing. Any delay could result in death. To work on or near high voltage, you should

be familiar with approved industrial first aid methods.

Energized equipment Never work on energized equipment unless authorized bya

responsible authority. Energized electrical equipment is dangerous. Electrical shock

from energized equipment can cause death. If you must perform authorized emergency

work on energized equipment, be sure that you comply strictly with approved safety

regulations.

Sabre 1555 RFID and Bar Code Reader Service Manual

Warnings, Cautions, and Notes

The warnings, cautions, and notes in this manual use this format.

Warning

A warning alerts you of an operating procedure, practice, condition, or statement that

must be strictly observed to avoid death or serious injury to the persons working on

the equipment.

Caution

A caution alerts you to an operating procedure, practice, condition, or statement that

must be strictly observed to prevent equipment damage or destruction, or corruption

or loss of data.

Optics

Always wear finger cots or non-powdered latex gloves when handling optical parts

such as the exit window.

Follow ESD

Procedures

Follow ESD Procedures

This icon appears at the beginning of any procedure in this manual that could cause

you to touch components (such as printed circuit boards) that are susceptible to

damage from electrostatic discharge (ESD). When you see this icon, you must follow

standard ESD guidelines to avoid damaging the equipment you are servicing.

Note: Notes are statements that either provide extra information about a topic or contain

special instructions for handling a particular condition or set of circumstances.

Code39Before You Begin

vii

About This Manual

This manual will help you repair and troubleshoot the Sabre 1555 scanner. It also

explains how to replace parts and includes the spare parts list.

This manual is written for service technicians who will troubleshoot and repair the 1555.

For information on operating the Sabre 1555, see:

•the Sabre 1555 RFID & Bar Code Reader Getting Started Guide, P/N 3-740049-01

•the Sabre 1555 RFID & Bar Code Reader Operator’s Guide, P/N 3-740049-00

•the Sabre 1555 RFID & Bar Code Reader Programmer’s Reference Manual,

P/N 072414

alexdaddy

Troubleshooting the 1555

alexdaddy
