MODEL HA07 - MASTER CONTROLLER INSTRUCTIONS
Page 1 of 35 158HA11645
Thank you for purchasing Intermatic’s Home Settings
devices. With these products you can reliably and remotely
control lighting and appliances. The outstanding features of
the Home Settings program include:
ØFeedback that will allow you to see whether your
device has received the ON/OFF/DIM signal.
ØEase of installation
ØManual override
ØRF signal reliability – each Home Settings product
has a special repeater feature that virtually
guarantees that RF signals are received.
The HA07 Controller also includes the following features:
Ø12 Channels - each channel can control up to 16 devices
to create scenes or timed events.
ØAstronomic Feature – this option allows your time settings
to match the daily changes in sunrise and/or sunset. Set
it once and never have to set it again for these types of
time changes.
ØWall mountable or place on a tabletop.
ØDaylight Saving Time – this option automatically adjusts
your timer for daylight saving time.
ØProgramming flexibility – timing options can be every day
of the week, Mon- Fri, Sat-Sun, or individual days.
ØALL ON/ALL OFF Feature – Turn all devices ON or OFF
with the push of one button.
ØIf required, more than one controller can be used for the
same system.
ØTimed control
Z-Wave™ Introduction
The HA07 Master Remote Controller is a Z-Wave™ enabled
device and is fully compatible with any Home Settings network
and any Z-Wave™ enabled network. Z-Wave™ enabled devices
displaying the Z-Wave™ logo can also be used with Home
Settings modules and controllers regardless of the manufacturer,
and Home Settings modules and controllers can also be used in
other manufacturer’s Z-Wave™ enabled networks. Each module
in a Home Settings network is designed to act as a repeater.
Repeaters can re-transmit the RF signal to ensure that the signal
is received by its intended destination by routing the signal around
obstacles and radio dead spots.
Page 2 of 35
Table of Contents
Glossary of Terms………………………………………….……….. 4
Installing Batteries…………………………………………………… 6
Module Installation and Set-up Recommendations……………… 7
Programming Instructions…………………………………………... 8
Setting the Clock……………………………………...…………. 8
Setting the Calendar……………………………………….……. 9
Setting Daylight Saving Time & Zone………………..……..…. 11
Setting Astronomic Function…………….……………………… 13
Creating a Network………………………………………………….. 14
INCLUDE Modules to a Network………………………………. 14
Associating Modules to Channels….……………………….…. 16
EXCLUDE from Network………………………………….…….. 18
EXCLUDE from Channel……………………..…………………. 18
Remote ON/OFF/DIM Operation…………………………………... 19
Adding Modules to ALL ON/ALL OFF Feature……………….….. 20
INCLUDE Modules to ALL ON/ALL OFF Feature……...…..... 20
EXCLUDE Modules to ALL ON/ALL OFF Feature…..………. 22
Programming the Controller………………………………………… 23
Automatic, Automatic Random, and Manual Mode……………… 27
Additional Features………………………………………………….. 28
Controller Replication…………………………………...………. 28
Replicating the Network and Channel Settings….…………... 28
Replicating the Network only…………...……………….……… 30
Resetting the Controller…………………………………………….. 31
Resetting the NETWORK only……………………..…………... 31
Resetting the CHANNELS only…………………..…………….. 31
Resetting the NETWORK and CHANNELS…..……….……… 31
Troubleshooting……………………………………..………………. 32
Federal Communications Commission Statement………………. 34
Specification Information……………………………………………. 34
Warranty Information…………………………………………….….. 35
Page 3 of 35
Master Remote Controller _
Fig 1. LCD display and button configuration.
Glossary of Terms
Astronomic Function – Allows a device to follow sunrise and
sunset times. The unit will automatically adjust as daylight
time increases or decreases without the need to be
reprogrammed.
Channel – Achannel will control up to 16 modules, allowing
them to be programmed to turn on/off with the same time
settings. HA07 has 12 channels.
Device – Any item that is connected to a module (for
example, lamps).
Page 4 of 35
Event - A program in the controller that will instruct the
controller to control various modules at a set day and time.
The HA07 can accommodate up to 28 events.
Module – Any Intermatic Home Settings product that is
controlled with a remote controller.
Network – All Intermatic Home Settings devices controlled
by the Master Controller and duplicate remote controls
operating on the same system. Each network has its own
unique identification code so that no one else can control the
system.
Primary Controller – The first controller used to set up your
modules and network.
NOTE: Only the Primary Controller can be used to include or
delete modules from a network.
Scene – Lighting modules assigned to the various channels can
be set at different levels, thus creating desired light levels
throughout your house called scenes. Scenes can be set during
the “Associating Modules To Channels” step (see page 16) by
choosing ON, OFF and/or DIM settings.
Secondary Controller – A controller containing network information
about other modules within the network, and is created from the
primary controller. Secondary controllers cannot include or delete
modules to the network.
Page 5 of 35
Battery Installation
1. Open the battery compartment door located on the
back of the remote control by pressing down on the
battery compartment tab and pulling the door outward.
2. Insert 4 size “AA” alkaline batteries (not included),
placing the batteries as shown in the battery
compartment. (See Fig 2)
3. Replace the battery compartment door by first inserting
the 2 tabs at the bottom of the door, then pressing the
door in until the door clicks shut. Fig 2. Battery compartment
Page 6 of 35
Module Installation and Set-Up Recommendations
1. Modules should be plugged-in or hardwired into the
location where they will be used.
2. For best results, do not move or relocate modules after
they have been included into the network. If you wish to
re-locate or move a module from a particular location,
first delete it from the network, then include it back to
the network after you have re-located it.
3. Devices should be plugged into modules before adding
modules to the network. Devices (for example, lamps)
should be turned to the ON position.
Module Installation and Set-Up Recommendations
4. Controllers must be brought within 6 ft. of modules
during set-up. This is because during set-up, the
controller communicates with the modules using low
radio transmission power. This helps provide additional
security when setting up your network.
5. HA06 Dimmer Switches have a 40-Watt minimum lamp
requirement.
Page 7 of 35
Programming Instruction
_______________Setting the CLOCK_________________
1. (See Fig 3a) Press MODE until CLK mode is shown.
Fig 3a
2. (See Fig 3b) Press ENTER and the hour will flash. Press +
or - to set the hour. Press ENTER to accept the hour.
Fig 3b
Page 8 of 35
3. (See Fig 3c) The minutes will flash. Press + or - to set
minutes. Press ENTER to accept the minutes.
Fig 3c
Setting the CALENDAR
NOTE: The day of the week will be automatically calculated
when the CALENDAR setting is completed.
1. (See Fig 4a) Press MODE until the CAL mode is shown.
2. (See Fig 4b) Press + or - to set the month. Press
ENTER to accept the changes.
3. (See Fig 4c) The day of the month will flash.
Press + or - to set the day. Press ENTER to accept
the changes.
4. (See Fig 4d) The year will flash. Press + or - to set the
year. Press ENTER to accept the year.
Page 9 of 35
Setting the CALENDAR (continued)
Fig 4a – CAL mode Fig 4b – Set Month Fig 4c – Set Day Fig 4d – Set Ye
