RM-02 I 3
RM-02
Dynamic Remote Microphone
2I RM-02
TheRM-02isanidealremotepagingmicrophonewithpush-to-
talkcontrol.Itfeaturesaunidirectionaldynamicmicrophonewith
agooseneck.Themicrophonehasafrequencyrangeof50Hzto
10kHzwithanimpedanceof600ohmsandasensitivityof-52db.
Thestandisofheavydiecast-zincconstructiontoprovidestability
andminimizenoisecausedbytheoperatortouchingthestand.
FEATURES
POLAR PATTERN & FREQUENCY RESPONSES
OVERVIEW
RM-02
Unidirectional Moving Coil Dynamic Microphone
Heavy die-casting zine construction base
MIC ON/OFF Switch
Frequency response 50Hz ~ 10kHz
Sensitivity -52dB±3dB (0dB=1V/Pa at 1KHz)
Impedance 600Ω
Constitution and Accessory
Stand(RM-02), Microphone(MC-02)
240
o
27
0
o
300
o
330
o
0
o
30
o
60
o
90
o
120
o
150
o
180
o
210
o
-90
-80
-70
-60
-50
-40
10
k20k
2k 5k500200100
20 50
1k
RM-02 I 3
NAME OF GOOSE NECK ASS’Y
NAME OF STAND ASS’Y
WIND SCREEN
UNIT
This unit which range is from 50Hz to 10kHz can make
sound.
UNIT BASE
This base settles unit, and made of aluminium ware to
protect goose neck not to be lower.
GOOSE NECK
This goose neck can adjust the direct of unit without
moving stand.
CONNECTOR HOLDER
This case is in order to connect stand to connector.
WRENCH BOLT
This screw solidifies mounting between goose neck
and connector holder.
3P CONNECTOR
This screw solidifies mounting between goose neck
and connector holder.
RUBBER FOOT
This rubber foot of stand avoid sliding on the glass or
table.
STAND
This stand made of heavy Zn diecasting which can minimize
touch noise.
STAND COVER
RECEPTACLE
Input signal through 3p connector of goose neck
becomes sound at this part of stand ass’y.
TALK SWITCH
After press talk switch, the microphone does work and
press again is off.
2I RM-02
SPECIFICATIONS
RM-02
TYPE Unidirectional
POLAR PATTERN
Moving Coil Dynamic
SENSITIVITY -52dB±3dB (0dB=1V/Pa at 1KHz)
FREQUENCY RESPONSE 50Hz ~ 10kHz
MAX SPL Over 130dB
IMPEDANCE 600Ω ±30%
WEIGHT (SET) 1.6kg / 3.5lb
DIMENSIONS(SET)
BASE 99(W) x 50(H) x 148(D)mm
3.9(W) x 2(H) x 5.8(D)in
MIC 26.5(W) x 440(H) x 26.5(D)mm
1(W) x 17.3(H) x 1(D)in
Inter-M Corp. (IMK)
719, Dobong-ro, Dobong-gu, Seoul, Korea
Overseas Sales Team
Tel_ +82-2-2289-8141~7 Fax_ +82-2-2289-8149 E-mail_ overseas@inter-m.com www.inter-m.com
※Design and specication are subject to be changed for the improvement of product quality without pre notice. 2015. 7. V1
