Safety warnings
When using the Intellinav 3, make sure you are operating the device in
compliance with all local, state, and federal regulations. It is the sole responsibility
of the driver of the vehicle to operate the vehicle in a safe manner and not
become distracted by the Intellinav system . You should not operate the controls
of the Intellinav system while driving, nor place the device where it obstructs
airbags operation. Netropa shall not be liable for any accident. By using the
Intellinav system, you have agreed to the terms and agreements.
Please review additional information on page 13 of this guide. For full safety and
regulatory information, please refer to the
User's Manual.
©2006-2007 Netropa Corp. All rights reserved.
Intellinav 3 Quick Start Guide.
1
Do not mount where driver’ s field of vision is blocked
Do not place on dashboard unsecured
Do not mount where airbag deployments are obstructed
Intellinav3_Quick_Start_Guide_20070820:QSG_IN-KQG02_112706.qxd 2007/8/20 ⁄U⁄¨
Quick Start Guide
2
Welcome
Congratulations on your purchase of the Intellinav 3. You can use the
Intellinav 3 to guide you to the destination of your choice using signals from
Global Positioning Satellites (GPS) orbiting the earth. Use this
Quick Start
Guide
to start exploring your new system. When you want more information,
please refer to the
User's Manual.
Table of contents
Safety warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Welcome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Table of contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
What's in the box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Installing the Intellinav 3 in your vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Getting to know the Intellinav 3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Starting the Intellinav 3 for the first time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Getting GPS signal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Reading the map screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Screen Tap Area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Entering data on the Intellinav 3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Entering a route . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Getting information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Traffic pattern . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Using tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Driver safety features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Other features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Additional information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Intellinav3_Quick_Start_Guide_20070820:QSG_IN-KQG02_112706.qxd 2007/8/20 ⁄U⁄¨
Intellinav 3
Cradle
Windshield Mount
AC Adapter
Car Charger
Warranty Card
Quick Start Guide (this document)
2GB SD Card (pre-inserted into Intellinav 3)
User’ s Manual
Disc
Pouch
3
Quick Start Guide
What's in the box
Note: If you are missing any item, please contact your retailer.
1
1
2
3
4
5
7
8
9
10
2 3 4
5 6 7 8
910
11
6
11
Intellinav3_Quick_Start_Guide_20070820:QSG_IN-KQG02_112706.qxd 2007/8/20 ⁄U⁄¨
Quick Start Guide
4
Installing the Intellinav 3 in your vehicle
Mounting on the Windshield
1. Clean the surface of the windshield using rubbing alcohol.
2. Press the suction cup firmly against the windshield.
3. Press down the lever to fix the suction cup in place.
NOTICE TO DRIVERS IN CALIFORNIA AND MINNESOTA:
State law prohibits drivers in California (CVC 26708(a)) and
Minnesota (169.71, Minnesota Statutes 2006) from using
suction mounts on their windshields while operating motor vehicles.
Mounting on the Dashboard
1. Remove the adhesive cover on the disc, and stick the
disc on the dashboard.
2. Press the suction cup firmly against the disc.
3. Press down the lever to fix the suction cup in place.
Mounting the Cradle and GPS
1. Insert the GPS unit bottom in first, and then lock it using
the lever on the top.
2. Adjust the angles of the arms to achieve the best viewing
position.
Intellinav3_Quick_Start_Guide_20070820:QSG_IN-KQG02_112706.qxd 2007/8/20 ⁄U⁄¨
5
Charging the Battery
1. Prior to first use, please use the AC adapter to fully charge the unit for 4-6
hours, until battery LED turns green.
2. In the vehicle, you may plug in the car charger to provide continuous power.
On a full charge, the unit can operate between 2 to 3 hours.
3. To charge the battery, the Battery On/Off switch at the bottom of the unit
must in the On position.
4. To preserve battery power when the unit will not be used for an extended
period, set the Battery On/Off switch to the Off position.
Quick Start Guide
Intellinav3_Quick_Start_Guide_20070820:QSG_IN-KQG02_112706.qxd 2007/8/20 ⁄U⁄¨
6
Getting to know the Intellinav 3
SD Card Slot
Battery On/Off
Speaker (rear)
Reset Button
Headphone
Jack
Volume (+/-)
LED
*The USB feature has been disabled
*DC In
Standby
5
Quick Start Guide
Intellinav3_Quick_Start_Guide_20070820:QSG_IN-KQG02_112706.qxd 2007/8/20 ⁄U⁄¨
7
Starting the Intellinav 3 for the first time
To start the Intellinav system:
1. Press the <<Standby>> button. The
Main Menu screen appears. If the
Battery On/Off switch on the bottom of
the unit is in the Off position, set it to
On first.
2. Tap Navigation. A warning screen
appears.
3. Tap I Agree after you have read and
agreed to the warning. The map view
appears and you are ready to set your
first destination!
Quick Start Guide
Intellinav3_Quick_Start_Guide_20070820:QSG_IN-KQG02_112706.qxd 2007/8/20 ⁄U⁄¨
Quick Start Guide
8
To use the Intellinav 3 to guide you to a destination, the system's GPS antenna must
be receiving signals. GPS signals can be obstructed by ceilings, trees, heavy clouds,
and nearby tall buildings. Signals can also be obstructed by the roof of your vehicle
and UV filtering windshield. For best results, position your Intellinav 3 where it has a
clear view of the sky.
You need to receive data from four satellites to get an accurate location. Intellinav
provides a GPS Info screen that tells you how many satellite signals you are
currently receiving. The SAT field on the GPS info screen shows the number of
satellite signals that you are currently receiving (9) and an estimate as to how many
are in view (10).
There are 3 ways to view the state of the signal:
1) Car Cursor
Red: Acquiring GPS signal
Yellow: Weak GPS signal
Green: GPS signal locked and ready to navigate
GREY: Connectivity to GPS lost. Try turning the power switch off and then
back on. If the condition persists, contact Netropa Technical Support.
2) GPS signal strength meter.
White: Acquiring GPS signal
Yellow: Weak GPS signal
Green: GPS signal locked and ready to navigate.
3) For detailed information about the GPS operational state, please see the GPS
Information screen.
Getting GPS signal
Intellinav3_Quick_Start_Guide_20070820:QSG_IN-KQG02_112706.qxd 2007/8/20 ⁄U⁄¨
9
Quick Start Guide
The map view shows you the present location.
The bottom of the screen displays the name of
the street you are on, and your current speed.
The Intellinav map shows you more than just
your current location. As you navigate to a
destination, the map displays the direction of
your next turn, the distance to that turn, and
the name of the street you will be turning at
the top of the screen.
Screen Tap Areas
Tap in designated areas on the map display for
shortcuts to handy functions.
Reading the map screen
Repeat voice
guidance
(2D mode only)
Tap and hold to show
details of the street, set
as the start location or
the destination
Show details of
current location
Zoom Out
Menu
Change map
orientation to Heading
Up or North Up
Show route list
Zoom In
Mute
