DIGI-HD60-WP-S Installation Guide
Important notice:
• Do not attempt to disassemble or alter the extender housing. There are no user-serviceable parts inside
the unit. Doing so will void your warranty.
• To minimize the possibility of equipment damage from electrostatic discharge (ESD), all source and
destination equipment must be powered o during installation.
• Do not connect the extender to a telecommunication outlet wired to unrelated equipment. Doing so may
damage the unit or any connected equipment. Ensure all connected twisted pair cabling is straight-through
(point-to-point).
• Allow proper ventilation to reduce the risk of thermal failure.
The Intelix DIGI-HD60-WP-S extends HDMI over a single twisted pair cable by incorporating HDBaseT
technology. The DIGI-HD60-WP-S supports HDCP Encrypted Content & DDC/EDID Transmission.
DIGI-HD60-WP-S transmits Ultra HD (4K2K), HDTV Video Resolutions up to 720p/1080i/1080p@60Hz
and WUXGA (1920X1200 @60Hz) at distances of 60m (196ft). Diagnostic LED ensure hassle-free and
robust installations. Power design allows the units to be powered at the RX end, and pass power
upstream to the wall plate.
The DIGI-HD60 series extenders are compatible with all Intelix HDBaseT product oerings and any
product that meets the HDBaseT specications.
Instructions
The following instructions describe the installation process for a point-to-point installation. The
procedure is similar for compatible HDBaseT components. In the event a compatible HDBaseT product
cannot provide power over the HDBaseT cable connection, the DIGI-HD60-WP-S product will require a
local power supply.
1. Verify all components included with the extender set are present before installation.
2. Turn o power and disconnect the audio/video equipment by following the manufacturer’s
instructions.
3. Connect shielded Category 5e or greater twisted pair cable with RJ45 connectors between the
transmitter (DIGI-HD60-WP-S) and the receiver (DIGI-HD60-R). TIA/EIA-568B straight-through wiring
connections must be used with all HDBaseT extenders.
4. Connect an HDMI cable between the display and the receiver (DIGI-HD60-R).
5. Connect an HDMI cable between the source and the transmitter (DIGI-HD60-WP-S).
6. Connect the power supply to the compatible receiver.
7. Power on attached audio/video devices.
Diagnostic LED:
The DIGI-HD60-WP-S provides one LED to indicate the current operating status and to assist
troubleshooting an installation.
Link: Solid red when powered up. Blinking red/amber when HDBT is connected without video
signal. Solid amber when video connection is established.
TIA/EIA-568B
Orange/White
Orange
Green/White
Blue
Blue/White
Green
Brown/White
Brown
Pin 1
Pin 2
Pin 3
Pin 4
Pin 5
Pin 6
Pin 7
Pin 8
1 8
Twisted Pair Wiring
Use TIA/EIA-568B wiring for Category
6 connection between send and
receive units.
Troubleshooting Tips
Symptom Possible Soluons
• Power indicator is off. • Ensure that active power is connected.
• If power is provided by another HDBase-T device, verify
twisted pair cable is securely connected to the HDBT port
on back of wall plate.
• Power indicator is on, but link
indicator is off.
• Verify CAT5e or greater twisted pair cable is being utilized
and terminated with 568B crimp pattern.
• Test with another twisted pair cable.
• Power and link indicator
are on, but no video signal is
present.
• Verify the source is powered on.
• Test with another HDMI cable. Verify the HDMI cable
between the source and the transmitter is less than or
equal to 5 meters in length.
• Test with another HDMI source.
• Ensure twisted pair cable connections between
transmitter and receiver are securely fastened.
• Turn the power off, then back on to reset the link.
rev 151030
11675 Ridgeline Drive
Colorado Springs, Colorado 80921
1-800-530-8998
supportlibav@libav.com
Technical Specicaons
Input/Output Connecons
HDMI One (1) HDMI Type A Receptacle
Twisted Pair One (1) 8P8C port (Shielded RJ45)
Supported Audio and Video
Maximum Video Compability at 60 m Deep Color 36/30/24 Bit at 1080p
Maximum Video Compability at 35 m Deep Color 48 Bit at 1080p, 3D, and 4k x 2k (UHD) up to 30 Hz:
RGB, YCbCr 4:4:4, YCbCr 4:2:2; up to 60 Hz: YCbCr 4:2:0
Video Compliance HDMI, HDCP 2.2, and CEC (Consumer Electronics Control)
Embedded Audio Up to PCM 8 channel, Dolby Digital TrueHD, and DTS-HD Master
Audio
HDBaseT Signal Characteriscs
Maximum Distance 60 m
Cable Requirements Solid core shielded Category 5e, Category 6 or greater with TIA/
EIA-568B crimp paern
Bandwidth 10.2 Gbps
Chassis and Environmental
Enclosure Painted steel
Dimensions 45.72mm x 20.82mm x 104.14mm (1.80 in. x 0.82 in. x 4.10 in.)
Shipping Weight 0.22 kg (0.49 lbs.)
Operang Temperature (Environment) 0° to +40° C (+32° to +104° F)
Operang Temperature (Chassis) 0° to +55° C (+32° to +131° F)
Operang Humidity (Environment) 20% to 90%, Non-condensing
Storage Temperature (Environment) -10° to +60° C (+14° to +140° F)
Storage Humidity (Environment) 20% to 90%, Non-condensing
Power, ESD, and Regulatory
Maximum Power Consumpon 24VDC @ 0.5 Amps (Max.)
ESD Protecon 15kV
Regulatory CE, RoHS, FCC
Other
Standard Warranty 2 years
Diagnosc Indicators Link LED
Included Accessories Installaon Guide
Distances and picture quality may be aected by cable grade, cable quality, source and desnaon equipment, RF
and electrical interference, and cable patches.
