Intel AXX6DRV3GEXP Manual de usuario

Drive Cage Upgrade Kit Installation Guide:

Intel®Server Chassis SC5400

Order Number: D38448-002

This document provides instructions for installing the following accessory kits:

AXX4DRV3G

AXX6DRV3G

AXX4DRV3GEXP

AXX6DRV3GEXP

ii Important Safety Instructions

Disclaimer

Information in this document is provided in connection with Intel®products. No license, express or implied, by estoppel or

otherwise, to any intellectual property rights is granted by this document. Except as provided in Intel's Terms and Conditions

of Sale for such products, Intel assumes no liability whatsoever, and Intel disclaims any express or implied warranty, relating

to sale and/or use of Intel products including liability or warranties relating to fitness for a particular purpose, merchantability,

or infringement of any patent, copyright or other intellectual property right. Intel products are not designed, intended or

authorized for use in any medical, life saving, or life sustaining applications or for any other application in which the failure of

the Intel product could create a situation where personal injury or death may occur. Intel may make changes to specifications

and product descriptions at any time, without notice.

Intel is a registered trademark of Intel Corporation or its subsidiaries in the United States and other countries.

*Other names and brands may be claimed as the property of others.

Important Safety Instructions iii

Important Safety Instructions

Read all caution and safety statements in this document before performing any of the instructions.

See Intel Server Boards and Server Chassis Safety Information at

http://support.intel.com/support/motherboards/server/safecert.htm.

Wichtige Sicherheitshinweise

Lesen Sie zunächst sämtliche Warn- und Sicherheitshinweise in diesem Dokument, bevor Sie eine

der Anweisungen ausführen. Beachten Sie hierzu auch die Sicherheitshinweise zu Intel-

Serverplatinen und -Servergehäusen unter

http://support.intel.com/support/motherboards/server/safecert.htm.

重要安全指导

在执行任何指令之前，请阅读本文档中的所有注意事项及安全声明。和/或

http://support.intel.com/support/motherboards/server/safecert.htm 上的

Intel Server Boards

and Server Chassis Safety Information

（《Intel

服务器主板与服务器机箱安全信息》）。

Consignes de sécurité

Lisez attention toutes les consignes de sécurité et les mises en garde indiquées dans ce document

avant de suivre toute instruction.Consultez Intel Server Boards and Server Chassis Safety

Information rendez-vous sur le site

http://support.intel.com/support/motherboards/server/safecert.htm.

Instrucciones de seguridad importantes

Lea todas las declaraciones de seguridad y precaución de este documento antes de realizar

cualquiera de las instrucciones. Vea Intel Server Boards and Server Chassis Safety Information en

http://support.intel.com/support/motherboards/server/safecert.htm.

iv Warnings and Cautions

Warnings and Cautions

These warnings and cautions apply whenever you remove the access cover to access components

inside the server. Only a technically qualified person should integrate and configure the server.

WARNINGS

The power button on the front panel DOES NOT turn off the AC power.

To remove power from server, you must unplug the AC power cord

from the wall outlet or the chassis.

Hazardous electrical conditions may be present on power, telephone,

and communication cables. Turn off the server and disconnect the power

cords, telecommunications systems, networks, and modems attached to

the server before opening it. Otherwise, personal injury or equipment

damage can result.

Hazardous voltage, current, and energy levels are present inside the

power supply. There are no user-serviceable parts inside it; servicing

should be done by technically qualified personnel.

CAUTIONS

ESD can damage disk drives, boards, and other parts. Perform all procedures

in this document only at an ESD workstation. If one is not available, provide

ESD protection by wearing an anti-static wrist strap attached to chassis

ground any unpainted metal surface on your server when handling parts.

Always handle boards carefully. They can be extremely sensitive to ESD.

Hold boards only by their edges. Do not touch the connector contacts. After

removing a board from its protective wrapper or from the server, place the

board component side up on a grounded, static free surface. Use a conductive

foam pad if available but not the board wrapper. Do not slide board over any

surface.

For proper cooling and airflow, always install the access cover before turning

on the server. Operating it without the cover in place can damage system

parts.

Contents v

Contents

Before You Begin ................................................................................................ 1

About the Drive Cage Upgrade Kits ........................................................................................ 1

Kit Contents Lists .................................................................................................................... 2

Tools and Supplies Needed....................................................................................................4

How to use this Guide............................................................................................................. 4

Intel® Server Chassis SC5400 Installation ....................................................... 5

Remove the Access Cover...................................................................................................... 5

Remove the Bezel Assembly .................................................................................................. 6

Remove Hot Swap Fans ......................................................................................................... 7

Four-drive Upgrade Drive Cage Installation............................................................................ 8

Make Backplane Cable Connections: ................................................................................... 10

For a four-drive expander backplane connect the following cables: ............................ 10

For a four-drive non-expander backplane connect the following cables: ..................... 11

For a four-drive SAS hot swap drive cage installation: ................................................ 12

Six-drive Upgrade Drive Cage Installation ............................................................................ 13

Make Backplane Cable Connections: ................................................................................... 15

Make Server Board/RAID Controller Card Connections ....................................................... 18

Reinstall Hot Swap Fans....................................................................................................... 18

Install Hot Swap Hard Drives ................................................................................................ 19

Install Fixed Hard Drives.......................................................................................................19

Replace Bezel Assembly ...................................................................................................... 19

Replace Access Cover.......................................................................................................... 21

vi Contents

Figures

Figure 1. Removing Access Cover.......................................................................................... 5

Figure 2. Removing Bezel Assembly ...................................................................................... 6

Figure 3. Removing Hot Swap Fans from Chassis ................................................................. 7

Figure 4. Removing Grill ......................................................................................................... 8

Figure 5. Installing Drive Cage into Chassis ........................................................................... 9

Figure 6. Making Four-drive Expander Fixed Drive Cage Cable Connections ..................... 10

Figure 7. Making Four-drive Non-expander Fixed Drive Cage Cable Connections .............. 11

Figure 8. Removing Six-drive Fixed Drive Cage from Chassis ............................................. 13

Figure 9. Installing Six-drive Hot Swap Drive Cage into Chassis.......................................... 14

Figure 10. Layout of Cable Connectors on the Backplane.................................................... 15

Figure 11. Making Six-drive SAS Hot Swap Drive Cage Backplane Cable Connections

Figure 12. Making Six-drive Non-expander SAS Hot Swap Drive Cage Backplane Cable

Connections ................................................................................................................. 17

Figure 13. Reinstalling Hot Swap Fans................................................................................. 18

Figure 14. Reinstalling Bezel Assembly................................................................................ 19

Figure 15. Replacing Access Cover...................................................................................... 21

Before You Begin 1

Before You Begin

Before removing the access cover for any reason, observe these safety guidelines.

1. Turn off any peripheral devices connected to the server.

2. Turn off the server by pressing the power button on the front of the chassis.

3. Unplug the AC power cord from the chassis or wall outlet.

4. Label and disconnect all peripheral cables connected to I/O connectors or ports on the back of

the chassis.

5. Label and disconnect all telecommunication lines connected to I/O connectors or ports on the

back of the chassis.

6. Provide electrostatic discharge (ESD) protection by wearing an anti-static wrist strap attached

to a chassis ground—any unpainted metal surface—when handling components.

About the Drive Cage Upgrade Kits

Four- and six-drive cage upgrade kits allow you to install various hard drive solutions for the

following Intel®Server Chassis:

Intel®Server Chassis SC5400

Intel®Server Chassis SC5400 LX

Intel®Server Chassis SC5400 Base Redundant Power (BRP)

NOTE

Refer to your server board documentation to determine SAS/SATA support

for your server system.

If you want to use your SAS/SATA drives for a RAID configuration, you may

need to install a SAS/SATA RAID add-in card. Refer to your server board

documentation and/or your SAS/SATA RAID card documentation for

additional installation instructions and requirements.

2 Before You Begin

Kit Contents Lists

Each upgrade kit contains different items. See the following for a list of contents for each upgrade

kit.

Four-drive Fixed Drive Cage Upgrade Kit (AXX4FIXDB)

Item Quantity

Drive cage assembly 1

Fixed drive rails (pre-installed in drive cage) 8

This manual 1

Four-drive SAS Drive Cage Upgrade Kit (AXX4DRV3G)

Item Quantity

Drive cage assembly 1

SAS hot swap drive carriers (pre-installed in drive cage) 4

SAS/SATA connection ID label 1

SAS/SATA cable assembly 1

IPMB cable 1

SES cable 1

SGPIO cable 1

This manual 1

Four-drive SAS Drive Cage (Expander) Upgrade Kit (AXX4DRV3GEXP)

Item Quantity

Drive cage assembly 1

SAS hot swap drive carriers (pre-installed in drive cage) 4

SAS connection ID label 1

SAS cable assembly 1

IPMB cable 1

This manual 1

Six-drive SAS Drive Cage Upgrade Kit (AXX6DVR3G) 1

Item Quantity

Drive cage assembly 1

SAS hot swap drive carriers (pre-installed in drive cage) 6

SAS/SATA connection ID label 1

SAS/SATA cable assembly 1

IPMB cable 1

SES cable 1

SGPIO cable 1

This manual 1

Before You Begin 3

Six-drive SATA Drive Cage (Expander) Upgrade Kit (AXX6DVR3GEXP) 1

Item Quantity

Drive cage assembly 1

SAS/SATA hot swap drive carriers (pre-installed in drive cage) 6

SAS connection ID label 1

SAS cable assembly 1

IPMB cable 1

This manual 1

4 Before You Begin

Tools and Supplies Needed

Phillips*(cross head) screwdriver (#2 bit)

Flat-head screwdriver

Anti-static wrist strap (recommended)

Needle-nosed pliers

Serial ATA RAID card (dependent on installation)

SAS RAID card (dependent on installation)

How to use this Guide

If you are installing drive cage upgrade kits into an Intel® Server Chassis SC5400, SC5400 Base

Redundant Power (BRP) or SC5400 LX follow the instructions under the section titled “Intel®

Server Chassis SC5400 Installation.”

For either chassis, if you are installing hot swap drives, follow the instructions under the section

titled “Install Hot Swap Hard Drives”.

For the Intel Server Chassis SC5400, if you are installing fixed drives, follow the instructions under

the section titled “Install Fixed Hard Drives.”

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Servidor de Intel

Intel

Intel ISP1100 - Server Platform - 0 MB RAM Manual de usuario

Intel

Intel NSC2U - IP Network Server Manual de usuario

Intel

Intel SR870BH2 - Server Platform - 0 MB RAM Manual de usuario

Intel

Intel MFSYS25V2 Manual de usuario

Intel

Intel SSR212MC2 - Storage Server Hard Drive Array Guía

Intel

Intel D50DNP Series Manual de usuario

Intel

Intel R2000GZ series Manual de usuario

Intel

Intel MFSYS25V2 Manual de usuario

Intel

Intel R2000WF series Manual de usuario

Intel

Intel TIGI2U - Carrier Grade Server Manual de usuario

Intel

Intel SR2520SAFRNA - Server System - 0 MB RAM Manual de usuario

Intel

Intel SBXD62 - Server Compute Blade Manual de usuario

Intel

Intel P4000RP Manual de usuario

Intel

Intel SR870BN4 - Server Platform - 0 MB RAM Manual de usuario

Intel

Intel SR1500 - AXXMINIDIMM DDR-2 RAID Controller Cache... Manual de usuario

Intel

Intel MFSYS25V2 Manual de usuario

Intel

Intel H2000G Series Manual de usuario

Intel

Intel M70KLP Series Guía de configuración

Intel

Intel SR1630BC - Server System - 0 MB RAM Guía de configuración

Intel

Intel SR1625UR - Server System - 0 MB RAM Manual de usuario

Intel

Intel SR1530HSH - Server System - 0 MB RAM Manual de usuario

Intel

Intel SERVER SYSTEM SR2500AL Manual de usuario

Intel

Intel 320014-003US Manual de usuario

Intel

Intel NSW1U - IP Network Server Guía de referencia

Manuales populares de Servidor de otras marcas

HP AlphaServer ES47 Manual de usuario

Dell

Dell PowerEdge R410 Manual de usuario

PowerNAS

PowerNAS CMA Manual de usuario

Supero

Supero FatTwin F617R3-FT Manual de usuario

MSI

MSI P1-109N-L70 Manual de usuario

Dell

Dell PowerEdge XE9640 Manual

Dell

Dell PS4100 Instrucciones de montaje

EtroVISION

EtroVISION EV3151 Manual de usuario

NEC

NEC Express5800/T110j Manual de usuario

HP ProLiant Gen9 Manual de usuario

Compaq

Compaq ProLiant 3000 Manual

Dell

Dell PowerEdge 3YPMN Manual de usuario

iRobo

iRobo IPC2U Manual de usuario

Nortel

Nortel 1000 Con?guration guide Manual de usuario

Asus

Asus AP7500 Manual de operación y mantenimiento

Avid Technology

Avid Technology AirSpeed 5000 Manual de usuario

HP Integrity rx2600 Guía de instalación

Milestone

Milestone Husky IVO 350T Manual de usuario
