Intel 410 Manual de usuario

Intel

Express 410

Standalone Switch

Quick Start and User Guide

Intel Corporation, 5200 NE Elam Young Parkway, Hillsboro OR 97124-6497

Intel Corporation assumes no responsibility for errors or omissions in this manual. Nor does Intel make any commitment to update the

information contained herein.

* Other product and corporate names may be trademarks of other companies and are used only for explanation and

to the owners’ benefit, without intent to infringe.

Second Edition May 2000 740604-002

Contents

Quick Starts 2

English...........................................................................................2

Chinese ..........................................................................................4

Korean ...........................................................................................6

French............................................................................................8

Italian.............................................................................................10

German ..........................................................................................12

Spanish ..........................................................................................14

User Guide 16

About the 410T/F Switches..........................................................17

Port LEDs...............................................................................17

Status LED .............................................................................17

Fiber Port LEDs .....................................................................18

Crossover Button....................................................................18

Local Management ........................................................................19

Overview ................................................................................19

Navigation ..............................................................................19

Functions ................................................................................20

Connecting to Devices ..................................................................21

Connection Guidelines ...........................................................21

Workgroup Example......................................................................22

Cabling Devices ............................................................................23

Media Requirements ..............................................................23

Straight-through vs. Crossover Cables...................................23

Testing a Cable.......................................................................24

FAQs/Troubleshooting ..................................................................25

Regulatory Information and Warnings ..........................................26

Limited Hardware Warranty ..........................................................29

Intel Customer Support Inside back cover

5678

Quick Start

Install the Switch

Check the

Connections

• Check the port LEDs to confirm the link

status.

• A solid green LED (on the left) indicates

a valid link.

Left (Green/Orange)

Solid Green = Link

Blinking Green = Activity

Blinking Orange = Collision

Right (Orange)

Off = 100Mbps

Solid = 10Mbps

MDI/

MDI-X

210

311

412

513

6147 15

816

Left

Right

Link= Solid Green

Activity= Blinking Green

Collision= Blinking Orange

10Mbps= Solid Orange

100Mbps= Off

Intel

Express 410T Standalone Switch

Status

Rack: Use the three small

screws to attach the

brackets to the switch.

Shelf: Peel off the protective

backing and attach the rubber

feet to the switch.

English

• Remove the switch and parts from the box.

• Attach the enclosed brackets if you plan

to mount the switch in a rack.

• Install the Intel®Express 410T or 410F

Standalone Switch in a rack or on a shelf.

• Plug in the power cord.

Connect

the Devices

• All ports automatically detect the speed

and duplex-mode of any connected device.

• Connect PCs and print servers to the

switch with straight-through cables.

• Use a crossover cable to connect a switch

to another switch or hub.

• Use a straight-through cable to connect to

another switch or hub when port 1 is set to

MDI.

• Use only CAT 5 UTP cable to connect

100Mbps devices. To connect 10Mbps

devices, use CAT 3, 4, or 5 UTP cable.

10/100

Switch Hub or Switch

Switch Print Server

Switch PC/Server

straight-through

From To

Switch Hub or Switch

straight-through

when port 1 set to MDI

crossover

Optional Information

How to Change Port 1

from MDI-X to MDI

• All ports on the switch are MDI-X.

Press the MDI/MDI-X button to change

port 1 to MDI so you can connect to

another switch or hub using a straight-

through cable.

1234

MDI

MDI-X

Intel®Express 410T Standal

MDI/MDI-X

button

English

MDI

MDI-X

Access the

Configuration Screen

• Connect your PC to the Management

module’s serial port using the null-modem

cable (included).

• Set a VT100-compatible terminalemula-

tion program (such as HyperTerminal*) to

these parameters:

- 9600 baud - 8 data bits

- No parity - 1 stop bit

- No flow control

Press Eto connect to the Configura-

tion screen.

• Navigate the screen with these keys:

TMove to next item.

BMove to previous item.

zToggle options within a field.

c +SSave changes to configuration.

c +RRepaint the screen.

• <Auto> is the default setting for the ports.

You only need to configure the port

settings if you are having difficulty

connecting to a device.

Configuration Screen: Items enclosed with angle

brackets < > indicate a toggle field. Use the z to

toggle selections.

Speed Auto =all port settings are

automaticallynegotiated.

100 = port set to 100Mbps.

10 = port set to 10Mbps.

Duplex Half = port set to half duplex.

Full = port set to full duplex.

– = port set to auto mode.

Flow enable = flow control is enabled in half

Control duplex mode (back pressure).

disable = flow control is disabled in full

duplex mode.

– = port set to auto mode.

5678

kable

Hub

10/100

MDI/

MDI-X

210

311

412

513

6147 15

816

Left

Right

Link= Solid Green

Activity= Blinking Green

Collision= Blinking Orange

10Mbps= Solid Orange

100Mbps= Off

Intel

Express 410T Standalone Switch

Status

•LED

• LED

= 100 Mbps

= 10 Mbps

( Rack ) ( switch )

( Shelf ) ( switch )

•

•Intel®Express 410T

410F Standalone Switch

•

•PC

•

•1 MDI

•CAT 5 UTP 100 Mbps

10 Mbps

CAT 3 4 5 UTP

( Switch ) ( Hub or Switch )

( Switch )

PC/

( Switch )

( Switch ) ( Hub or Switch )

1 MDI

1234

MDI

MDI-X

Intel®Express 410T Standal

1 MDI-X

MDI

•MDI-X

MDI/MDI-X 1

MDI

MDI/MDI-X

MDI

MDI-X

•PC

•VT100

- 9600 - 8

- - 1

•

c +S

c +R

•< >

< >

(Auto) =

(Speed) 100 = 100 Mbps

10 = 10 Mbps

(Half) =

(Duplex) (Full) =

– =

(Enable) =

(Flow Control) (Disable) =

– =

45678

Module A

ackable Hub

10/100

MDI/

MDI-X

210

311

412

513

6147 15

816

Left

Right

Link= Solid Green

Activity= Blinking Green

Collision= Blinking Orange

10Mbps= Solid Orange

100Mbps= Off

Intel

Express 410T Standalone Switch

Status







12345

MDI

MDI-X

Intel

Express 410T Standalone

MDI

MDI-X





5678

10/100

MDI/

MDI-X

210

311

412

513

6147 15

816

Left

Right

Link= Solid Green

Activity= Blinking Green

Collision= Blinking Orange

10Mbps= Solid Orange

100Mbps= Off

Intel

Express 410T Standalone Switch

Status

Français

Démarrage rapide

Installez le Switch

Vérifiez les

connexions

• Vérifiez les diodes du port pour confirmer

l’état de la liaison.

• Une lumière verte continue (sur le côté

gauche) indique une liaison valable.

Gauche (vert/orange)

Vert continu = Liaison

Vert clignotant = Activité

Orange clignotant = Collision

Droite (orange)

Éteint = 100 Mbps

Continu = 10 Mbps

Armoire : utilisez trois petites vis

pour fixer les supports au switch.

Étagère : enlevez la pellicule

adhésive et placez les supports

en caoutchouc sous le switch.

• Retirez le commutateur et les pièces de la

boîte.

• Fixez les supports livrés avec l’appareil si

vous envisagez de le monter dans une armoire.

• Installez Intel®Express 410T ou 410F

Standalone Switch dans une armoire ou sur

une étagère.

• Branchez l’alimentation électrique.

Connectez les

périphériques

• Tous les ports sont configurés de manière

à détecter automatiquement la vitesse et le

mode duplex du périphérique connecté.

• Connectez les PC et les serveurs d’impression

au switch à l’aide de câbles directs.

• Utilisez un câble croisé pour connecter

le switch à un autre switch ou à un hub.

• Utilisez un câble direct pour vous connecter

à un autre switch ou à un hub lorsque le port 1

est défini sur MDI.

• Utilisez uniquement un câble CAT 5 UTP pour

connecter des périphériques 100 Mbps. Pour

connecter des périphériques 10 Mbps, utilisez

un câble CAT 3, 4 ou 5 UTP.

Switch Hub ou Switch

Switch Serveur d’impression

Switch PC/Serveur

Direct

De À

Switch Hub ou Switch

Direct

Lorsque le port 1 est défini sur

MDI

Croisé
