Intel D915PLWD Manual de usuario

Intel®Desktop Board

D915PLWD

Specification Update

Release Date: July 2006

Order Number: D23990-003US

The Intel®Desktop Board D915PLWD may contain design defects or errors known as errata, which

may cause the product to deviate from published specifications. Current characterized errata are

documented in this Specification Update.

INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL®PRODUCTS. NO LICENSE,

EXPRESS OR IMPLIED, BY ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS

GRANTED BY THIS DOCUMENT. EXCEPT AS PROVIDED IN INTEL’S TERMS AND CONDITIONS OF SALE FOR

SUCH PRODUCTS, INTEL ASSUMES NO LIABILITY WHATSOEVER, AND INTEL DISCLAIMS ANY EXPRESS OR

IMPLIED WARRANTY, RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY OR

WARRANTIES RELATING TO FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT

OF ANY PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT. INTEL PRODUCTS ARE NOT

INTENDED FOR USE IN MEDICAL, LIFE SAVING, LIFE SUSTAINING APPLICATIONS.

Intel may make changes to specifications and product descriptions at any time, without notice.

Designers must not rely on the absence or characteristics of any features or instructions marked “reserved”

or “undefined”. Intel reserves these for future definition and shall have no responsibility whatsoever for

conflicts or incompatibilities arising from future changes to them.

The Intel®desktop board D915PLWD may contain design defects or errors known as errata which may cause

the product to deviate from published specifications. Current characterized errata are available on request.

Contact your local Intel sales office or your distributor to obtain the latest specifications before placing your

product order.

Copies of documents which have an ordering number and are referenced in this document, or other Intel

literature, may be obtained from:

Intel Corporation

P.O. Box 5937

Denver, CO 80217-9808

or call in North America 1-800-548-4725, Europe 44-0-1793-431-155, France 44-0-1793-421-777,

Germany 44-0-1793-421-333, other Countries 708-296-9333

Intel, Pentium, Celeron, and the Intel logo are trademarks or registered trademarks of Intel Corporation or

its subsidiaries in the United States and other countries.

* Other names and brands may be claimed as the property of others.

CONTENTS

REVISION HISTORY..................................................................................................................................... v

PREFACE.........................................................................................................................................................vi

Specification Update for the Intel®Desktop Board D915PLWD

GENERAL INFORMATION ............................................................................................................................3

SPECIFICATION CHANGES.........................................................................................................................5

ERRATA ..........................................................................................................................................................6

Intel®Desktop Board D915PLWD Specification Update

REVISION HISTORY

Date of Revision Version Description

June 3, 2005 -001 This document is the first Specification Update for the

Intel®Desktop Board D915PLWD.

September 2005 -002 Added Erratum 1 and updated General Information table.

July 2006 -003 Updated the General Information page, added

Specification Changes 1 and Erratum 2.

Intel®Desktop Board D915PLWD Specification Update

PREFACE

This document is an update to the specifications contained in the Intel®Desktop Board

D915PLWD Technical Product Specification (Order number D23930). It is intended for hardware

system manufacturers and software developers of applications, operating systems, or tools. It

will contain Specification Changes, Errata, Specification Clarifications, and Documentation

Changes.

Refer to the Intel®Pentium®4 Processor Specification Update (Order number 249199) for

specification updates concerning the Intel Pentium 4 processor and that may apply to the

desktop board D915PLWD. Unless otherwise noted in this document, it should be assumed that

any processor errata for a given stepping are applicable to the Altered Assembly (AA) revision(s)

associated with that stepping.

Refer to the Intel®915G/915GV/915GL/915P/915PL/910GL Express Chipset Specification

Update (Order Number 301468) for specification updates concerning the 82915PL MCH

Controller and that may apply to the desktop board D915PLWD. Unless otherwise noted in this

document, it should be assumed that any MCH errata for a given stepping are applicable to the

Altered Assembly (AA) revision(s) associated with that stepping.

Refer to the Intel®IO Controller Hub 6 (ICH6) Family Specification Update (Order Number

301474) for specification updates concerning the 82801FB I/O Controller Hub and that may

apply to the desktop board D915PLWD. Unless otherwise noted in this document, it should be

assumed that any ICH 6 errata for a given stepping are applicable to the Altered Assembly (AA)

revision(s) associated with that stepping.

Nomenclature

Specification Changes are modifications to the current published specifications. These

changes will be incorporated in the next release of the specifications.

Errata are design defects or errors. Characterized errata may cause the desktop board

D915PLWD’s behavior to deviate from published specifications. Hardware and software

designed to be used with any given Altered Assembly (AA) and BIOS revision level must assume

that all errata documented for that AA and BIOS revision level are present on all desktop

boards.

Specification Clarifications describe a specification in greater detail or further highlight a

specification’s impact to a complex design situation. These clarifications will be incorporated in

the next release of the specifications.

Documentation Changes include typos, errors, or omissions from the current published

specifications. These changes will be incorporated in the next release of the specifications.

Specification Update for the

Intel®Desktop Board D915PLWD

Intel®Desktop Board D915PLWD Specification Update

GENERAL INFORMATION

Basic Desktop Board D915PLWD Identification Information

AA Revision

BIOS Revision

Notes

D16710-100 VG91510A.86A.0042 1-2

D16710-101 VG91510A.86A.0042 1-2

D16710-102 VG91510A.86A.0048 1-2

NOTES:

1. The AA number is found on a small label on the component side of the board.

2. The 82910PL Chipset kit used on this AA revision consists of two components as follows:

Device Stepping S-Spec Numbers

82915PL GMCH C2 SL8D6

82801FB ICH6 B2 SL7Y5

Intel®Desktop Board D915PLWD Specification Update

Summary Table of Changes

The following table indicates the Specification Changes, Errata, Specification Clarifications, or

Documentation Changes that apply to the Intel®Desktop Board D915PLWD. Intel intends to fix

some of the errata in a future revision of the desktop board, and to account for the other

outstanding issues through documentation or specification changes as noted. This table uses

the following notations:

CODES USED IN SUMMARY TABLE

Doc: Document change or update that will be implemented.

Plan Fix: This erratum may be fixed in a future revision of the desktop board,

driver, or BIOS.

Fixed: This erratum has been previously fixed.

No Fix: There are no plans to fix this erratum.

Shaded: This erratum is either new or modified from the previous version of the

document.

NO. PLANS SPECIFICATION CHANGES

1 Doc Changes to Section 2.7.2.2, Add-in Card Connectors

NO. PLANS ERRATA

1 Plan Fix DMI fields may be overwritten during a BIOS update

2 Plan Fix The placement of capacitors behind PCI Express* x1 connector slots 1 and 2 may prohibit

some PCI Express x1 add-in cards from properly connecting to the motherboard
