Intel I915GL Manual de usuario

TRADEMARK

All products and company names are trademarks or registered

trademarks of their respective holders.

These specifications are subject to change without notice.

Manual Revision 1.1

July 14, 2006

IntelIntel

Intel

i915GL / i915GVi915GL / i915GV

i915GL / i915GV mainboardmainboard

mainboardmainboard

mainboard

forfor

for IntelIntel

IntelIntel

Intel SocketSocket

SocketSocket

Socket 775775

775775

775 processorprocessor

processorprocessor

processor

User’User’

User’ss

ManualManual

Manual

60000025EGM11

DISCLAIMER OF WARRANTIES:

THERE ARE NO WARRANTIES WHICH EXTEND BEYOND THE

DESCRIPTION ON THE FACE OF THE MANUFACTURER LIMITED

WARRANTY. THE MANUFACTURER EXPRESSLY EXCLUDES ALL

OTHER WARRANTIES, EXPRESS OR IMPLIED, REGARDING ITS

PRODUCTS; INCLUDING ANY IMPLIED WARRANTIES OF

MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR

NONINFRINGEMENT. THIS DISCLAIMER OF WARRANTIES SHALL

APPLY TO THE EXTENT ALLOWED UNDER LOCAL LAWS IN THE

COUNTRY PURCHASED IN WHICH LOCAL LAWS DO NOT ALLOW OR

LIMIT THE EXCLUSION OF THE IMPLIED WARRANTIES.

iii

Table of Contents

Section 1 Introduction

Package Contents ...................................................... 1- 1

Mainboard Features ................................................... 1- 2

System Block Diagram ............................................... 1- 5

Section 2 Specification

Mainboard Specification ............................................ 2- 1

Section 3 Installation

Mainboard Layout ..................................................... 3- 1

Easy Installation Procedure ....................................... 3- 2

CPU Insertion ............................................................. 3- 2

Jumper Settings .......................................................... 3- 4

System Memory Configuration .................................. 3-5

VGA Expansion .......................................................... 3- 6

Device Connectors..................................................... 3- 7

Power-On/Off (Remote) .............................................. 3-13

External Modem Ring-in Power ON and

Keyboard Power ON Function (KBPO) ..................... 3-13

ACPI S3 (Suspend To RAM) Function ...................... 3-14

Section 4 BIOS Setup

Main Menu ................................................................ 4- 1

Standard CMOS Setup ............................................... 4- 2

Advanced BIOS Features .......................................... 4- 3

Advanced Chipset Features ...................................... 4- 5

Integrated Peripherals ................................................ 4- 8

Power Management Setup ......................................... 4-13

PNP/PCI/PCI-E Configuration .................................... 4-16

PC Health Status ........................................................ 4-17

Page

Power BIOS Features ................................................. 4-19

Defaults Menu ........................................................... 4-21

Supervisor/User Password Setting ............................ 4-22

Exit Selecting .............................................................. 4-23

Section 5 Driver Installation

Easy Driver Installation .............................................. 6- 1

Realtek Sound Manager Quick User guide ................ 6- 2

Appendix Appendix A

Update Your System BIOS ......................................... A- 1

Appendix B

EEPROM BIOS Remover ............................................ B-1

Introduction

Page 1-1

Section 1

INTRODUCTION

1-1 Package Contents

Contents

A. Mainboard

B. User’s manual

C. Floppy drive cable

D. HDD drive cable

E. CD (drivers and utilities)

F. I/O Shield

G. S-ATA data and power cable

Optional Items

H. S/PDIF Module

I. IEEE 1394 two ports cable

J. Extra USB2.0 port cable

If you need the optional item, please

contact your dealer for assistance.

USER’S

MANUAL

Introduction

Page 1-2

1-2 Mainboard Features

Brief Introduction

Intel®Pentium®4 processors

The Pentium 4 processor is designed to deliver performance across applications

and usages where end-users can truly appreciate and experience the

performance. The Pentium 4 processor delivers this world-class performance for

consumer enthusiasts and business professional desktop PC users as well as for

entry-level workstation users.

Intel adds support for Hyper-Threading Technology to the Pentium 4 processor

family. HT Technology allows a single, physical Pentium 4 processor to function

as two logical processor for next generation multi threaded application.

For more information about all the new features the Pentium 4 delivers, check out the

Intel website at http://www.intel.com

Chipset

This board is designed with Intel®915GL/915GV chipset. The Intel®915G series

chipset consists of the Graphics Memory Controller Hub (GMCH) and the I/O

Controller Hub (ICH6).

DDR400

Supports dual channel of DDR400 memory to give you twice the memory

bandwidth for greater system performance.

PCI-Express (PCI-E)

Next generation peripheral interface to succeed to current PCI bus for the next

decade. With smaller slot size and 250MB/sec(PCI-E*1) or 4GB/sec(PCI-E*16)

maximum transfer, PCI-Express overcomes PCI bus bottleneck.

Ultra ATA100

The mainboard provides an Ultra ATA100 Bus Master IDE controller. This

controller supports Ultra ATA100 protocols which are ideal to support demanding

applications such as real-time video, multimedia, and a high performance operating

system. A new IDE cable is required for Ultra ATA100.

Introduction

Page 1-3

Hardware Monitoring

Hardware monitoring enables you to monitor various aspects of the system opera-

tion and status. This includes CPU temperature, voltage and fan speed in RPMs.

10/100 LAN (Optional)

This mainboard is mounted with a ethernet LAN chipset. It allows the mainboard to

connect to a local area network by means of a network hub.

GbE LAN (Optional)

The new Gigabit Ethernet LAN allows data transmission at 1,000 megabits per

second (Mbps), which runs 10 times faster than conventional 10/100BASE-T

Ethernet LANs.

Serial ATA (S-ATA)

Support Serial ATA, an evolutionary replacement for Parallel ATA IDE storage

interface. Increases the peak data transfer speed up to 150MB/sec and allows

future enhancements to the computing platform.

IEEE 1394 (Optional)

IEEE 1394a provides enhanced PC connectivity for consumer electronics audio/

video appliances, storage peripherals, portable devices such as digital cameras, and

inter-PC communications. IEEE 1394a provides transfer rates up to 400Mbits/sec.

USB2.0

A popular USB standard for plugging in peripherals with up to 480Mbps transfer

speed while maintaining backward compatibility with older USB1.1 device.

8ch

Delivers 8 channel audio to bring you the latest in audio realism from DVD

movies and games. Perfect for your home theatre system.

Introduction

Page 1-4

Special Features

&Magic Health

Reports your system hardware status for every boot-up to help detect faults

early. Monitor hardware status including CPU temperature, CPU/Memory/

Chipset voltage, fan RPM speed for chassis fan, CPU fan & Power supply fan.

&EZ-Boot

Simply press “ESC” to select your bootable device. No more hassle to search

the BIOS menu, change and re-start.

&PowerBIOS

Supporting a full range of overclocking setting via BIOS. Various adjustable

feature include FSB/Memory frequency tweaking.

&QuickSPDIF

On board SPDIF-out connector for quick connection to multi-channel

speakers. Not only removes cable cluttering but also delivers loss-free digital

audio to let you enjoy DVD movies and games with crystal clear sound.

BIOS Features:

H/W Features:

Introduction

Page 1-5

1-3 System Block Diagram

Introduction

Page 1-6
