IB900

Intel Xeon E7500/E7501

Full Size CPU Card

USER’S MANUAL

Version 1.0

ii IB900 User’s Manual

Acknowledgments

Award is a registered trademark of Award Software International,

Inc.

PS/2 is a trademark of International Business Machines

Corporation.

Intel and Xeon are registered trademarks of Intel Corporation.

Microsoft Windows is a registered trademark of Microsoft

Corporation.

Winbond is a registered trademark of Winbond Electronics

Corporation.

All other product names or trademarks are properties of their

respective owners.

IB900 User’s Manual iii

Table of Contents

Introduction........................................................1

Product Description..........................................................1

Checklist...........................................................................2

Specifications....................................................................3

Board Dimensions.............................................................4

Installations........................................................5

Installing the CPU.............................................................6

ATX Power Installation ....................................................7

Installing the Memory.......................................................7

Setting the Jumpers...........................................................9

Connectors on IB900 ......................................................13

BIOS Setup........................................................22

Drivers Installation.......................................41

Windows 2000/XP Chipset Drivers Installation...............42

Intel Software Installation Utility.........................................42

ATI M6 VGA Driver Installation.........................................45

PCI Ethernet Drivers.............................................................48

Windows NT 4.0 Chipset Drivers Installation .................50

ATI M6 VGA Driver Installation.........................................50

PCI Ethernet Drivers Installation.........................................50

iv IB900 User’s Manual

This page is intentionally left blank.

INTRODUCTION

IB900 User’s Manual 1

Introduction

Product Description

The IB900 Intel Xeon full size CPU card is based on the Intel

ET7500/ET7501 chipset. With two 184-pin DDR memory sockets, up to

4GB of memory is supported. A dual-channel DDR-200/266 memory

interface provides a maximum memory bandwidth of 3.2 GB/s through a

144-bit wide, 200/266 MHz Double Data Rate SDRAM memory

interface with densities up to 512 megabits is supported.

The Intel® Xeon™ Processor provides exceptional performance for

applications running on advanced operating systems and delivers

unparalleled computing power for powerful workstations, internet

infrastructure, and departmental server applications. The Intel®

NetBurst™ micro-architecture and Hyper-Threading Technology deliver

outstanding performance and headroom for peak internet server

workloads, resulting in faster response times, support for more users, and

improved scalability.

The on board Intel® E7501 Chipset Memory Controller Hub (MCH) is

the central hub for all data passing through core system elements such as

the dual Intel Xeon processors with 512 KB L2 cache via the system bus

interface, the memory via memory interface, and both the 64-bit

PCI/PCI-X and I/O controller hubs via Intel® Hub Interfaces.

IB900’s Intel® 82870P2 64-bit PCI/PCI-X Controller Hub 2 (P64H2)

connects to the MCH through a point-to-point Hub Interface 2.0

connection. P64H2 devices can be attached to the MCH with each

providing an I/O bandwidth greater than 1 GB/s.

Through the Intel® 82801CA I/O Controller Hub 3-S (ICH3-S) that

connects to the MCH through a point-to-point Hub Interface 1.5

connection, IB900 features two-channel Ultra ATA/100 bus master IDE

interface and four USB ports. It also supports System Manageability Bus

2.0 (SMBus 2.0) and PCI 2.2-compliant interfaces.

This CPU card represents the perfect choice for those who want superior

performance for rugged and demanding applications in industrial

automation, telecommunications and data-intensive applications.

INTRODUCTION

2IB900 User’s Manual

Checklist

Your IB900 package should include the items listed below.

•The IB900 Industrial CPU Card

•This User’s Manual

•2IDE Ribbon Cable

•1 Floppy Ribbon Connector

•2 Serial Port Ribbon Cable and 1 Parallel Port Attached to a

Mounting Bracket

•1 Y-Cable supporting a PS/2 Keyboard and a PS/2 Mouse

•1 CD containing the following:

•Chipset Drivers

•Flash Memory Utility

•Optional USB cable with bracket

INTRODUCTION

IB900 User’s Manual 3

Specifications

CPU Socket mPGA604 ZIF socket

CPU Intel Xeon Processor, 1.8GHz~2.8GHz+

Supports Hyper-Threading technology

Chipset Intel E7501 chipset

E7501 Memory Controller Hub (MCH)

82801CA Integrated Controller Hub (ICH3-S)

82870P2 64-bit PCI/PCI-X Controller (P64H2)

Bus Frequency System Bus: 533Mhz (E7501 chipset)

Hub Link 2.0 : 1GB/s

PCI-X (on board): 64-bit/133MHz

PCI : 32-bit/33MHz/66MHz or 64-bit/33MHz/66MHz

ISA : 16-bit/8MHz

Remarks: PCI 66Mhz/64-bit requires 3.3V voltage.

L2 Cache 512K, CPU integrated

BIOS Award BIOS, 4M FWH

System Memory Two 184-pin DDR memory slots

Up to 4GB memory capacity

PC266 (E7501) support

One 144-bit wide DDR memory port

Supports x72 ECC registered DIMMs

VGA ATI M6 VGA controller

8MB embedded VGA memory

Supports CRT, LVDS (24-bit) interface

LAN Intel 82546EB Dual Port Gigabit Ethernet Controller PCI-

X 1.0a

compliant bus supports 133 MHz

LPC I/O Winbond 83627HF supports parallel port, COM1 (RS232),

COM2 (RS232/422/485) serial ports, FDD controller, hardware

monitor

IDE Interface Chipset built-in; two enhanced IDE supports 4 IDE devices

including UDMA33/66/100,PIO mode 4 and bus master

FDD Interface Supports up to two floppy disk drives: 3.5" and/or

5.25" drives;3 Mode support

Parallel Port One parallel port supports SPP/EPP/ECP modes

Serial Ports One RS-232/422/485 and one RS-232 port

Watchdog Timer Generates system reset; 256 levels

USB Four USB ports

USB 1.1 compliant

Keyboard and

Mouse PS/2 type connectors

ISA High Drive Winbond W83628, W83629 PCI to ISA Bridge Chip

Power Connector ATX 12V power connector

Form Factor Full Size CPU Card

Dimensions 338mm x 122mm (13.3”x4.8”)

INTRODUCTION

4IB900 User’s Manual

Board Dimensions

INTRODUCTION

IB900 User’s Manual 5

Installations

This section provides information on how to use the jumpers and

connectors on the IB900 in order to set up a workable system. The topics

covered are:

Installing the CPU............................................................................ 6

ATX Power Installation................................................................... 7

Installing the Memory...................................................................... 7

Setting the Jumpers.......................................................................... 9

Connectors on IB900.....................................................................13

INTRODUCTION

6IB900 User’s Manual

135°

Installing the CPU

The IB900 CPU Card supports a CPU socket for Intel Xeon processors.

This socket comeswith a lever to secure the processor. Raise this lever to

about a 90°angle to allow the insertion of the processor. Place the

processor into the socket by making sure the notch on the corner of the

CPU corresponds with the notch on the inside of the socket. Once the

processor has slide into the socket, return the lever to the lock position.

Refer to the figures below.

After you have installed the processor into the socket, check if the

jumpers for the CPU type and speed are correct.

NOTE:

Ensure that the CPU heat sink and the CPU top surface are in

total contact to avoid CPU overheating problem that would

cause your system to hang or be unstable.
