Intel EtherExpress PRO 10+ ISA
Ethernet Adapter
Installation Guide
Notice
The information contained in this document is subject to change without notice.
Hewlett-Packard makes no warranty of any kind with regard to this
material, including, but not limited to, the implied warranties of
merchantability and fitness for a particular purpose.
Hewlett-Packard shall not be liable for errors contained herein or for incidental
or consequential damages in connection with the furnishing, performance, or use
of this material.
Hewlett-Packard assumes no responsibility for the use or reliability of its
software on equipment that is not furnished by Hewlett-Packard.
This document contains proprietary information that is protected by copyright.
All rights are reserved. No part of this document may be photocopied,
reproduced, or translated to another language without the prior written consent
of Hewlett-Packard Company.
Microsoft®, Windows® and MS-DOS® are registered trademarks of Microsoft
Corporation.
MMXTM is a trademark of Intel Corporation.
Pentium® is a registered trademark of Intel Corporation.
Hewlett-Packard France
Commercial Desktop Computing Division
38053 Grenoble Cedex 9
France
©1999 Hewlett Packard Company
General information to read before installing
General information to read before installing
On all systems: before installing LAN card, go into Bios setup and set PnP OS option field
to NO.
• How to change LAN card configuration if needed (Advanced users only)
This is a general advisory on how to forcibly modify resources for ISA and PCI network
cards.
ISA cards:
• For ISA network adapters, start the configuration tool provided in driver
kit (See install documentation)
• Under CMOS setup, go to Advanced > PnP/PCI ISA IRQ Resource Exclu-
sion > reserve an IRQ for the adapter.
PCI cards:
• For PCI network adapters, go to CMOS setup > Advanced > PnP/PCI ISA
IRQ Resource Exclusion > reserve the IRQ for Legacy ISA.
• ISA cards can’t use IRQ9
• IRQ 9 is reported as being used by ACPI during POST. This is due to ISA’s
inability to share IRQs.
• Using a different IRQ (e.g. 5, 7, 10, and 11) will work. For this:
1Install the NIC then power up the system.
2Press F2 to go to CMOS setup.
3Set PnP OS to NO and reserve IRQ 5, 7, 10, or 11 (explained in installation
section)
4Save the configuration settings and boot to the applicable OS.
5Follow installation steps.
Sound conflict under Win 95 on VLi8 only
• On VLi8, LAN cards cause an IRQ conflict with the embedded sound de-
vice under Win95.
• To solve the problem: Reserve IRQ 5 and sett PNP OS to no. For this:
1Install the NIC then power up the system
General information to read before installing
2Press F2 to go to CMOS setup.
3Set PNP OS to NO and reserve IRQ 5.
4Save settings and boot to applicable OS.
5Remote boot:
6Remote boot fails HP tests on Vectra VEi7.
7Message during boot on VEi8:
8Message “EtherExpress PRO flash routines disabled. ROM shadowing
problem.” appears when warm or cold booting the system.
The work-around for the above issues is to disable Plug and Play on the
NIC using the Intel SOFTSET2 utility and to disable shadowing in the
CMOS for the address region used by the NIC flash ram. Both must be
done. Disabling only the shadowing will not fix the problem.
1Boot into DOS 6.22.
2Run Intel’s SOFTSET2 utility. Go to “View adapter configuration” and
take down the Flash chip address for later use.
3Go back to main menu of SOFTSET2 and go to Change adapter config-
uration > Advanced Options menu > Set Plug and Play to Disabled.
For remote boot set Remote boot program to NDIS or Netware ODI de-
pending on the OS of the remote boot server. Save settings and exit
SOFTSET2.
4The system will reboot.
5Press F2 to go into CMOS settings. Go to Advanced > Shadow Options
> At a minimum, disable shadowing for the address region noted in
step 2. Save settings and exit SOFTSET2.
6Reboot the system.
7The Intel Flashstart configuration utility starts by default. Press the
spacebar twice to go to main menu > Exit. Note that after exiting, the
user will be given the option to start the Flashstart utility again on the
next reboot.
Another option to prevent the issues from occurring is to disable the
Flash memory feature on the NIC.
NOTE This option disables remote boot.
1 Run Intel SOFTSET2 utility.
General information to read before installing
9From main menu go to Change adapter configuration > Change “Flash
Memory” to Disabled.
1 Installing the Intel EtherExpress PRO 10+ ISA Ethernet Adapter
Microsoft Windows 95 SR2.5
1 Installing the Intel EtherExpress PRO 10+ ISA Ethernet
Adapter
Microsoft Windows 95
SR2.5
Connecting to a
Windows NT 3.51 Server
Requirements
• HP Vectra with Windows 95 SR2.5.
• Intel EtherExpress PRO 10+ ISA Ethernet card and driver disk version
3.50.
• Driver File: PROW95.VXD, version 1.43a
• Microsoft Windows 95 SR2.5 media.
• Microsoft Windows NT 3.51 Server system that supports NetBEUI,
NWLink IPX/SPX Compatible Transport, and NWLink NetBIOS network
protocols.
Device Configuration
Procedure
1With the HP Vectra turned off, install the Intel EtherExpress PRO 10+ ISA
adapter card into an ISA slot.
2Connect network cable media to the EtherExpress PRO 10+ card.
3Power on the machine and start Windows 95SR2.5 in MS-DOS mode.
4Insert the EtherExpress PRO 10+ driver disk, “PRO/10+ ISA LAN Adapter
Configuration and Driver Diskette” and execute “SOFTSET2.EXE”.
5Select “View Adapter Configuration” and verify the resource settings
listed above under the heading “Device Configuration”.
6Save any required changes and exit.
7Remove the Intel driver diskette from the floppy drive and restart the
system.
Device Configuration Vectra Vli8 Vectra VEi7 Vectra VEi8
Interrupt 05 03 07
I/O Address 210 210 210
1 Installing the Intel EtherExpress PRO 10+ ISA Ethernet Adapter
Connecting to a Windows NT 3.51 Server
8Windows 95SR2.5 will automatically recognize the Intel ethernet card as
“Intel EtherExpress PRO/10 (PnP Enabled)”.
9Insert the “PRO/10+ ISA LAN Adapter Configuration and Driver Diskette”
in the floppy drive and click on “Next” from the Update Device Driver
Wizard dialog box.
10 When Windows 95 detects the updated driver, “Intel EtherExpress{TM}
PRO/10+ {PnP Enabled}”, click on “Finish”.
11 Insert the Windows 95 CDROM when prompted. The system will copy all
the necessary files to complete the installation.
12 Click on “OK” when the system prompts for the computer and workgroup
names.
13 Enter the Computer Name, Workgroup, and Computer Description in the
appropriate spaces and click on “Close” (Contact your network
administrator if you do not have the required information).
14 Remove the Intel diskette from the floppy drive and click on “YES” to
restart the system when prompted.
15 Right-click on the “Network Neighborhood” icon and select “Properties”.
16 Accept the default Network Protocols and the Primary Network Logon
(Client for Microsoft Networks) as seen below and click on “OK”. (If you
do not have the required information, contact your network
administrator)
17 Client for Microsoft Networks
Client for Microsoft Networks
Intel EtherExpress[TM] PRO/10+ [PnP Enabled]
IPX/SPX-compatible Protocol
NetBEUI
18 Click on “OK” to accept the configuration.
19 Specify the path to your Windows 95 files when prompted.
2 Installing the Intel EtherExpress PRO 10+ ISA Ethernet Adapter
Microsoft Windows 95 SR2.5
2 Installing the Intel EtherExpress PRO 10+ ISA Ethernet
Adapter
Microsoft Windows 95
SR2.5
Connecting to a
Windows NT 4.0 Server
Requirements
• HP Vectra with Windows 95 SR2.5.
• Intel EtherExpress PRO 10+ ISA Ethernet card and driver disk version
3.50.
• Driver File: PROW95.VXD, version 1.43a
• Microsoft Windows 95 SR2.5 media.
• Microsoft Windows NT 4.0 Server system that supports NetBEUI, NWLink
IPX/SPX Compatible Transport, and NWLink NetBIOS network protocols.
Device Configuration
Procedure
1With the HP Vectra turned off, install the Intel EtherExpress PRO 10+ ISA
adapter card into an ISA slot.
2Connect network cable media to the EtherExpress PRO 10+ card.
3Power on the machine and start Windows 95SR2.5 in MS-DOS mode.
4Insert the EtherExpress PRO 10+ driver disk, “PRO/10+ ISA LAN Adapter
Configuration and Driver Diskette” and execute “SOFTSET2.EXE”.
5Select “View Adapter Configuration” and verify the resource settings
listed above under the heading “Device Configuration”.
6Save any required changes and exit.
7Remove the Intel driver diskette from the floppy drive and restart the
system.
8Windows 95SR2.5 will automatically recognize the Intel ethernet card as
“Intel EtherExpress PRO/10 (PnP Enabled)”.
Device Configuration Vectra Vli8 Vectra VEi7 Vectra VEi8
Interrupt 05 03 07
I/O Address 210 210 210
2 Installing the Intel EtherExpress PRO 10+ ISA Ethernet Adapter
Connecting to a Windows NT 4.0 Server
9Insert the “PRO/10+ ISA LAN Adapter Configuration and Driver Diskette”
in the floppy drive and click on “Next” from the Update Device Driver
Wizard dialog box.
10 When Windows 95 detects the updated driver, “Intel EtherExpress{TM}
PRO/10+ {PnP Enabled}”, click on “Finish”.
11 Insert the Windows 95 CDROM when prompted. The system will copy all
the necessary files to complete the installation.
12 Click on “OK” when the system prompts for the computer and workgroup
names.
13 Enter the Computer Name, Workgroup, and Computer Description in the
appropriate spaces and click on “Close” (Contact your network
administrator if you do not have the required information).
14 Remove the Intel diskette from the floppy drive and click on “YES” to
restart the system when prompted.
15 Right-click on the “Network Neighborhood” icon and select “Properties”.
16 Accept the default Network Protocols and the Primary Network Logon
(Client for Microsoft Networks) as seen below and click on “OK”. (If you
do not have the required information, contact your network
administrator)
17 Client for Microsoft Networks
Client for Microsoft Networks
Intel EtherExpress[TM] PRO/10+ [PnP Enabled]
IPX/SPX-compatible Protocol
NetBEUI
18 Click on “OK” to accept the configuration.
19 Specify the path to your Windows 95 files when prompted.
3 Installing the Intel EtherExpress PRO 10+ ISA Ethernet Adapter
Microsoft Windows 95 SR2.5
3 Installing the Intel EtherExpress PRO 10+ ISA Ethernet
Adapter
Microsoft Windows 95
SR2.5
Connecting to a Novell
Netware 3.12 Server
Requirements
• HP Vectra with Windows 95 SR2.5.
• Intel EtherExpress PRO 10+ ISA Ethernet card and drivers disk version
3.50.
• Driver File: PROW95.VXD, version 1.43a
• Microsoft Windows 95 SR2.5 media.
• Novell NetWare 3.12 Server system that supports IPX network protocol.
• Novell Client for Windows 95 v2.5 installation media.
Device Configuration
Procedure
1With the HP Vectra turned off, install the Intel EtherExpress PRO 10+ ISA
adapter card into an ISA slot.
2Connect network cable media to the EtherExpress PRO 10+ card.
3Power on the machine and start Windows 95SR2.5 in MS-DOS mode.
4Insert the EtherExpress PRO 10+ driver disk, “PRO/10+ ISA LAN Adapter
Configuration and Driver Diskette” and execute “SOFTSET2.EXE”.
5Select “View Adapter Configuration” and verify the resource settings
listed above under the heading “Device Configuration”.
6Save any required changes and exit.
7Remove the Intel driver diskette from the floppy drive and restart the
system.
8Windows 95SR2.5 will automatically recognize the Intel ethernet card as
“Intel EtherExpress PRO/10 (PnP Enabled)”.
Device Configuration Vectra Vli8 Vectra VEi7 Vectra VEi8
Interrupt 05 03 07
I/O Address 210 210 210
Otros manuales para Vectra VEi7
1
Este manual sirve para los siguientes modelos
2
Otros manuales de Adaptador de Intel
Intel
Intel ETHEREXPRESS PRO/100 Manual de usuario
Intel
Intel PRO/1000 PF Guía de referencia
Intel
Intel 1000BASE-T Manual de usuario
Intel
Intel NUC CEC Manual de usuario
Intel
Intel PRO/1000 T Manual de usuario
Intel
Intel I350 Manual de usuario
Intel
Intel RSP3TD160 Manual de instalación
Intel
Intel WPC2011BWW - PRO/Wireless 2011B LAN PC Card Manual de usuario
Intel
Intel PRO1000 - MT Dual Port Server Adapter Manual de usuario
Intel
Intel PROWIRELESS 3945ABG NETWORK CONNECTION Manual de usuario
Intel
Intel PRO/1000 T Manual de usuario
Intel
Intel ETHEREXPRESS PRO/100 Manual de usuario
Intel
Intel ETHEREXPRESS PRO/100 Manual de usuario
Intel
Intel E810 VDA4T Series Manual de usuario
Intel
Intel PRO/Wireless 2011B LAN USB Device Manual de instalación y operación
Intel
Intel X520 SFP+ Manual de usuario
Intel
Intel Ethernet X520 10GbE Dual Port KX4 Mezz Manual de usuario
Intel
Intel INTEL 10 GIGABIT AT2 SERVER ADAPTER Manual de usuario
Intel
Intel RS3P4TF160F Manual de instalación
Intel
Intel WM3B2100 Manual de usuario
