iE100A
Digital Infrared
Ear Thermometer
User Manual Ver 1.1
Copyright © Innovo Medical
2014-2020. All rights reserved.
Innovo Medical owns and reserves all
of the rights comprised in the copyright
of this document. No part of this
document may be changed, excerpted,
copied, reproduced, or imitated in any
form or by any means without prior
written consent of Innovo Medical.
All statements, information, and
recommendations in this document are
provided "AS IS" without warranties,
guarantees or representations of any kind,
either expressed or implied. The information
in this document is subject to change without
notice. Innovo Medical reserves the right of
final interpretation of this document.
Version 1.1
Issuing Date: April 2020
To download the latest manual for the
thermometer, simply scan the QR code below
or visit
https://innovo-medical.com
/products/innovo-iE100A-t
hermometer
Use only genuine Innovo ear probe covers
to ensure accurate results. To order refills,
please visit innovo-medical.com
Contact Us
Questions or Comments?
Call: 858-888-9781
Email: cs@innovogroups.com
Visit: www.innovo-medical.com
Introduction
Thank you for purchasing the Innovo iE100A
Digital Infrared Ear Thermometer. The iE100A
Ear Thermometer has passed numerous
rigorous clinical tests and has proven to be
safe, reliable and accurate when used in
accordance with the operation manual.
The iE100A Ear Thermometer has been
specifically designed to measure body
temperature from the ear. The method of
measurement is safe, hygienic and suitable
for use by people above three months old. It
can also be used to provide an estimation of
room temperature and surface temperature of
an object, such as a milk bottle.
Before using the thermometer, please read
this User Manual carefully and follow the
instructions stated herein. Please check and
inspect the package contents. If any
component is damaged or missing, or if you
have any concerns, please contact
for assistance.
Keep this User Manual in a safe place for
future reference.
Contents
1. Standard Packing List ........................ 1
2. Features of the iE100A Ear
Thermometer ..................................... 1
3. Important Warnings and Safety
Precautions........................................ 2
4. Note on Body Temperature................ 4
5. Elements of the Thermometer ........... 5
6. Battery Installation.............................. 6
7. Measuring Eardrum Temperature...... 7
8. Measuring Object Surface
Temperature..................................... 12
9. Temperature Taking Tips for Accurate
Measurement....................................15
10. Memory Mode...................................16
11. Care and Cleaning............................18
12. Errors and Troubleshooting ..............19
13. Technical Specifications................... 23
14. Warranty and After-Sale Service....... 25
15. Symbols ............................................ 25
16. EMC Information - Guidance and
Manufacturer’s Declaration................26
1
1.Standard Packing List
iE100A Ear Thermometer......……......1 PC
Innovo Ear Probe Cover (box of 20)...1 PC
Storage Case..…………………………1 PC
AAA Batteries (pre-installed)……….
User Manual……………………………1 PC
Quick Start Guide………………….......
2.Features of the iE100A Ear
Thermometer
The iE100A Ear Thermometer measures body
temperature from the ear canal. It detects the
natural infrared heat emitted from the eardrum
and displays the corresponding oral
equivalent temperature reading obtained via
clinical trials within 1 second.
When set to Object Measurement mode, the
thermometer can also detect natural infrared
heat emitted by an object or infrared heat
present in an environment to provide an
estimation of the surface temperature of the
object or room temperature respectively.
Convenient and easy to use
Easy mode of operation –take
measurement with the press of a button
Easily switch reading between Fahrenheit
and Celsius
Obtain reading faster than an oral
thermometer and more comfortable than a
rectal thermometer
Ergonomic design
Visual and audible alarm for fever detection
Accurate and quick
Utilize the latest infrared technology –
accurate, precise and instant readings
Safe and hygienic
Use of disposable ear probe cover
prevents cross-contamination
Unlike traditional thermometers, there is no
glass or mercury that could pose as a
potential health hazard. The thermometer
2 PCS
1 PC
2
is made up of ABS plastic, an infrared
sensor, an infrared temperature measuring
element, a microcomputer controlled circuit
and an LED display.
BPA and latex free
Memory recall
Has a Memory Mode that automatically
stores up to 30 readings
Conveniently tracks changes in
temperature by recalling stored data
Convenient fever warning
When the temperature registers
99.5°F/37.5°C and above, the thermometer
will warn user of a possible fever with 10 short
beeps and a color coded ring that glows red.
(For normal body temperature, the signal is a
long beep with a color coded ring that glows
blue.)
Intended use
The iE100A Ear Thermometer is an infrared
thermometer intended to measure body
temperature via the eardrum. It may be used
by medical professionals or by consumers in a
home environment.
Operating principle
The infrared temperature sensor detects
infrared energy emitted from the eardrum. A
built-in lens focuses the collected energy,
which is then converted into a temperature
reading by the thermopiles and measurement
circuits.
3.Important Warnings and Safety
Precautions
Warning
This product is not intended to
substitute advice from a physician,
pharmacist, or other licensed
health-care professional. You should
not use this product for self-diagnosis
or for treating a health problem. Seek
advice from your health-care provider
3
immediately if you suspect that you or
your child is not feeling well, has a
fever, appears distressed or has a
medical condition.
Do not use the thermometer if any part,
especially the sensor, shows any sign of
damage. Please contact manufacturer if it
is within the warranty period.
Do not attempt to repair, modify or
disassemble the thermometer. This voids
the warranty.
The thermometer is not designed for use
on newborns. Please consult a doctor
before using the thermometer on a
newborn.
The device is not a continuous monitoring
device.
The thermometer is not a toy. Please keep
out of children’s reach. Some parts are
small enough to be swallowed.
Do not use the thermometer in the vicinity
of strong electromagnetic fields such as
mobile telephones or radio installations.
Keep a minimum distance of 3.3 meters
from such devices when using the
thermometer.
Please dispose the used thermometer and
batteries in accordance with local
regulation and requirement.
Caution
Do not use the thermometer under an
ambient temperature higher than 40.0°C
(104.0°F) or lower than 10.0°C (50.0°F).
These are beyond the operating
temperature range of the thermometer.
The thermometer is not waterproof. Do not
immerse in water or other solutions. For
cleaning and disinfecting, please follow
instructions in the ‘Care and Cleaning’
section.
The thermometer is assembled precisely
in order to perform properly. Do not drop
the thermometer or touch the sensor with
a hard object. The thermometer is not
designed to withstand intense impact or
4
vibration.
Please remove the batteries if the
thermometer is not used for an extended
period of time, e.g. more than 1 month.
4.Note on Body Temperature
Normal body temperature is a range. It
varies from person to person and can
fluctuate throughout the day.
Body temperature also varies by sites.
Therefore, the iE100A Ear Thermometer
should not be used to obtain body
temperature from other parts of the body.
To determine if an individual is experiencing
an elevated body temperature or has a fever,
it is therefore critical to know, as a reference
point, the individual’s normal body
temperature range when he/she is well.
Normal body temperature fluctuates
throughout the day and is affected
by external factors. The body
temperature of an individual is the
lowest between 2:00 a.m. and 4:00
a.m. and the highest between 2:00
p.m. and 8:00 p.m. An individual's
body temperature typically changes
by less than 1°C (1.8 °F) each day.
5
5.Elements of the Thermometer
Measuring unit
(1) Unit button (Celsius/Fahrenheit)
(2) Mode button (Ear/Object measurement
mode)
(3) LED display
(4) Power/Measure button (with color coded
ring)
(5) Memory button
(6) Sound button (On/Off)
(7) Sensor lens
(8) Ear probe
(9) Battery cover
Button and its function
Button
Function
Power/Measure
button
Press once to power on or
to take measurement.
Press for about 3-4
seconds to power off.
Unit button
To switch unit of
measurement between
Celsius and Fahrenheit.
Measurement
mode button
To switch between Ear
and Object measurement
mode.
Memory button
To enter Memory mode.
Sound button
To turn sound on and off.
6
Screen display and symbol designation
6.Battery Installation
1. Open the battery cover.
2. Install two AAA batteries into the battery
compartment according to the stated
polarities.
3. Close the battery cover until it snaps back
in place.
Note:
•Prior to using the thermometer for the first
time, pull the plastic tab, if any, off the
battery compartment.
•Batteries should be installed according to
the stated polarities. Otherwise, the
thermometer bracket may be damaged.
•Replace the batteries when the low battery
icon ( ) flashes on the LED display. When
battery is completely exhausted, the battery
icon appears for 10 seconds, after which
device switches off automatically.
•Please remove the batteries if the
thermometer is not used for an extended
period of time, e.g. more than 1 month.
