SB52 Development Platform
SB52 Development Platform
for Yocto Linux
User Guide
June. 2020
Version 0.1
SB52 Development Platform
ii
Document Revisions
Date
Revision Number
Document Changes
06/2020
0.1
Draft version
SB52 Development Platform
iii
Table of Contents
1Overview...........................................................................................................................................4
2Setting up your computer .................................................................................................................. 4
3Building the Yocto Linux for SB52 ..................................................................................................4
3.1 Downloading the SB52 source....................................................................................................4
3.2 Extracting the SB52 source.........................................................................................................4
3.3 Building Yocto Linux images .....................................................................................................4
3.4 Commercial License.................................................................................................................... 5
4Flashing SB52 image.........................................................................................................................6
5Booting SB52..................................................................................................................................12
6Serial console terminal....................................................................................................................12
7Switch USB Mode........................................................................................................................... 13
8Versioning of Released FW ............................................................................................................14
9Reference.........................................................................................................................................14
SB52 Development Platform
4
1Overview
This tutorial guides new developers how to build Yocto Linux with the MTK i500 based
development platform –SB52 board. It provides manuals for:
•Setting up a Linux® OS build machine.
•Building SB52 Yocto Linux images.
•Flashing the images to SB52 development board.
2Setting up your computer
To build the Yocto Linux source files, you need a 64-bit version of Ubuntu (18.04 is recommended.
But compatible with 16.04).
After installing the computer running Linux OS, check whether all the necessary packages are
installed.
$ sudo apt-get install gawk wget git-core diffstat unzip texinfo gcc-
multilib build-essential chrpath socat cpio python python3 python3-pip
python3-pexpect xz-utils debianutils iputils-ping python3-git python3-
jinja2 libegl1-mesa libsdl1.2-dev pylint3 xterm g++ libstdc++6
lib32stdc++6 libpulse-dev libevent-dev ninja-build rpm2cpio libswitch-
perl
gn tools install
$ sudo apt-get install libssl-dev
$ wget -O gn http://storage.googleapis.com/chromium-
gn/3fd43e5e0dcc674f0a0c004ec290d04bb2e1c60e
$ sudo chmod 777 gn
Put the gn in build server /usr/bin/
Install adb and Fastboot
$ sudo apt-get install android-tools-adb android-tools-fastboot
Note: If your Ubuntu use default dash shell, please install bash shell to build image.
3Building the Yocto Linux for SB52
3.1Downloading the SB52 source
Please contact your Innocomm contact window to download the SB52 source code.
3.2Extracting the SB52 source
After you have set up a computer running Linux OS, extract the SB52 source tar by using the
following commands:
$ cd ~ (or any other directory you like)
$ unzip sb52-yocto.33.tar.xz.zip (need password)
$ tar -xJvf sb52-yocto.33.tar.xz
3.3Building Yocto Linux images
Full build
$ export TEMPLATECONF=${PWD}/meta/meta-innocomm/conf/base/sb52
$ source meta/poky/oe-init-build-env
SB52 Development Platform
5
$ bitbake innocomm-image-openmm-aiv
Note:
If you want a clean build, remove build and sstate-cache folder, and start from beginning.
Partial build
Partial compile can generate "boot","lk" image separately, also can verity build fail quickly.But
can’t generate “rootfs””userdata” images.
#Kernel
$ bitbake virtual/kernel -c cleansstate //clean
$ bitbake virtual/kernel -f //rebuild
#LK
$ bitbake lk -c cleansstate
$ bitbake lk –f
#Appmainprog and other target bb
$ bitbake appmainprog -c cleansstate
$ bitbake appmainprog
The images will be located in the below folder, if build is successful.
build/tmp/deploy/images/sb52
Note: All files under this folder are needed to flash the board
3.4Commercial License
Although Yocto Linux is open source, some licenses of modules/packages are commercial and
need to buy the license for your product.
Take AAC decoder plugin of gstreamer, gstfaad, as example, following modification should be
done to include it in the image.
1) Add gstreamer1.0-plugins-bad_%.bbappend
$ mkdir -p meta/meta-innocomm/recipes-multimedia/gstreamer
$ touch meta/meta-innocomm/recipes-multimedia/gstreamer/gstreamer1.0-
plugins-bad_%.bbappend
$ echo "PACKAGECONFIG += \" faad \\\"" > meta/meta-innocomm/recipes-
multimedia/gstreamer/gstreamer1.0-plugins-bad_%.bbappend
2) Fix wayland depend
In src/multimedia/gst-mtkwaylandsink/src/wayland.c
Change
#include <gst/wayland/wanland.h>
SB52 Development Platform
6
To
#include <wayland.h>
3) Add whitelist for fdd2 (please be NOTICED, the modification is for test only, if you want to
enable modules/packages for your product finally, please buy licenses)
In meta/meta-innocomm/conf/base/sb52/local.conf.sample, add following text.
LICENSE_FLAGS_WHITELIST = "commercial_faad2"
For more information about commercial license recipes, please refer to
https://www.yoctoproject.org/docs/current/mega-manual/mega-manual.html#enabling-
commercially-licensed-recipes
4Flashing SB52 image
Use the command below to flash the board
$ sudo python flashimage.py
Full flash steps:
1. Plug out SB52 power cable
2. Plug in USB cable
3. Run flashimage.py
$ sudo python flashimage.py
usage: flashimage.py [-h] [-d] [-s] [-u] [-b] [-t] [-v] [-n] [--toolsdir TOOLSDIR]
SB52 Development Platform
7
[--productdir PRODUCTDIR]
[partition]
********************************************************************************
Running flasher on Linux-4.15.0-72-generic-x86_64-with-Ubuntu-18.04-bionic
********************************************************************************
********************************************************************************
* flash images under: *
* /home/lin/sb52 *
********************************************************************************
Checking image
--------------------------------------------------------------------------------
MBR : PASS
bl2.img : PASS
tee.img : PASS
boot.img : PASS
system.ext4 : PASS
cam_vpu_a.img : PASS
cam_vpu_b.img : PASS
cam_vpu_c.img : PASS
sspm-fit.img : PASS
spmfw.img : PASS
userdata.ext4 : PASS
Start flashing
--------------------------------------------------------------------------------
Waiting for DA mode
4. Press and hold download key (to enter download mode)
5. Plug in SB52 power cable. Image flash will start...
$ sudo python flashimage.py
[sudo] password for lin:
usage: flashimage.py [-h] [-d] [-s] [-u] [-b] [-t] [-v] [-n] [--toolsdir TOOLSDIR]
[--productdir PRODUCTDIR]
[partition]
********************************************************************************
Running flasher on Linux-4.15.0-72-generic-x86_64-with-Ubuntu-18.04-bionic
SB52 Development Platform
8
********************************************************************************
********************************************************************************
* flash images under: *
* /home/lin/sb52 *
********************************************************************************
Checking image
--------------------------------------------------------------------------------
MBR : PASS
bl2.img : PASS
tee.img : PASS
boot.img : PASS
system.ext4 : PASS
cam_vpu_a.img : PASS
cam_vpu_b.img : PASS
cam_vpu_c.img : PASS
sspm-fit.img : PASS
spmfw.img : PASS
userdata.ext4 : PASS
Start flashing
--------------------------------------------------------------------------------
Waiting for DA mode
.
datool - device detected:
Waiting for fastboot mode
.
Fastboot - device detected: EM7LVGI7SORO4995
erasing 'mmc0'...
(bootloader) request sz: 0x3ab400000, real erase len: 0x3ab400000
OKAY [ 0.156s]
finished. total time: 0.156s
target reported max download size of 67108864 bytes
sending 'mmc0' (17 KB)...
OKAY [ 0.007s]
writing 'mmc0'...
OKAY [ 0.020s]
finished. total time: 0.027s
target reported max download size of 67108864 bytes
sending 'mmc0boot0' (274 KB)...
SB52 Development Platform
9
OKAY [ 0.021s]
writing 'mmc0boot0'...
OKAY [ 0.013s]
finished. total time: 0.034s
target reported max download size of 67108864 bytes
sending 'tee_a' (989 KB)...
OKAY [ 0.047s]
writing 'tee_a'...
OKAY [ 0.022s]
finished. total time: 0.069s
target reported max download size of 67108864 bytes
sending 'boot_a' (25376 KB)...
OKAY [ 1.163s]
writing 'boot_a'...
OKAY [ 0.552s]
finished. total time: 1.715s
target reported max download size of 67108864 bytes
Invalid sparse file format at header magic
sending sparse 'system_a' 1/9 (65532 KB)...
OKAY [ 2.946s]
writing 'system_a' 1/9...
OKAY [ 1.479s]
sending sparse 'system_a' 2/9 (64896 KB)...
OKAY [ 2.925s]
writing 'system_a' 2/9...
OKAY [ 1.354s]
sending sparse 'system_a' 3/9 (59772 KB)...
OKAY [ 2.710s]
writing 'system_a' 3/9...
OKAY [ 1.326s]
sending sparse 'system_a' 4/9 (63164 KB)...
OKAY [ 2.812s]
writing 'system_a' 4/9...
OKAY [ 1.287s]
sending sparse 'system_a' 5/9 (58976 KB)...
OKAY [ 2.673s]
writing 'system_a' 5/9...
OKAY [ 1.195s]
sending sparse 'system_a' 6/9 (65532 KB)...
OKAY [ 2.930s]
writing 'system_a' 6/9...
OKAY [ 1.337s]
sending sparse 'system_a' 7/9 (65532 KB)...
SB52 Development Platform
10
OKAY [ 2.967s]
writing 'system_a' 7/9...
OKAY [ 1.334s]
sending sparse 'system_a' 8/9 (65532 KB)...
OKAY [ 2.930s]
writing 'system_a' 8/9...
OKAY [ 1.329s]
sending sparse 'system_a' 9/9 (18476 KB)...
OKAY [ 0.816s]
writing 'system_a' 9/9...
OKAY [ 0.424s]
finished. total time: 34.775s
target reported max download size of 67108864 bytes
sending 'cam_vpu_a' (1614 KB)...
OKAY [ 0.145s]
writing 'cam_vpu_a'...
OKAY [ 0.035s]
finished. total time: 0.179s
target reported max download size of 67108864 bytes
sending 'cam_vpu_b' (9889 KB)...
OKAY [ 0.747s]
writing 'cam_vpu_b'...
OKAY [ 0.203s]
finished. total time: 0.950s
target reported max download size of 67108864 bytes
sending 'cam_vpu_c' (135 KB)...
OKAY [ 0.030s]
writing 'cam_vpu_c'...
OKAY [ 0.006s]
finished. total time: 0.037s
target reported max download size of 67108864 bytes
sending 'sspm_a' (486 KB)...
OKAY [ 0.060s]
writing 'sspm_a'...
OKAY [ 0.013s]
finished. total time: 0.072s
target reported max download size of 67108864 bytes
sending 'spmfw' (38 KB)...
OKAY [ 0.041s]
writing 'spmfw'...
OKAY [ 0.004s]
finished. total time: 0.045s
target reported max download size of 67108864 bytes
