INIM NRB100 Instrucciones de montaje

Installation and Programming Manual NRB100

SELF-POWERED HORNSTROBE FOR OUTDOOR USE

INSTALLATION

AND

PROGRAMMING

MANUAL

NRB100

NRB100 Installation and Programming Manual

Table of

contents

Table of contents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Chapter 1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

1-1 Manufacturer's details. . . . . . . . . . . . . . . . . . . . . . . . . . 3

1-2 Product description and models . . . . . . . . . . . . . . . . . . . 4

Chapter 2 General description. . . . . . . . . . . . . . . . . . . . 5

2-1 Box contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

2-2 Hornstrobe description . . . . . . . . . . . . . . . . . . . . . . . . . 5

2-3 Lights signalling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Chapter 3 Installation . . . . . . . . . . . . . . . . . . . . . . . . . 9

3-1 Installation guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . 9

3-2 2 wire connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

3-3 3 wire connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

3-4 Extra connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Chapter 4 Programming . . . . . . . . . . . . . . . . . . . . . . . . 12

Notes: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Limited warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Directives 2004/108/CE (EMC) and 2006/95/CE (LVD). . . . . 15

Overview 3

Installation and Programming Manual NRB100

Chapter 1

OVERVIEW

The heavy duty NRB100 Hornstrobe unit is especially designed to

allow maximum installation flexibility and durability.

A microprocessor continuously monitors all the device parameters

and assures high-reliability and first-rate performance.

A tamper output with a configurable balance resistor permits full-

integration with every type of system.

Optimized flexibility allows you to choose the wiring method you

prefer (activation and signalling by means of 2 or 3 wires, etc.).

Ready-to-go factory settings (refer to Table 6 "Programming

phases") ensure fast and easy installation with few or even no

changes.

1-1Manufacturer's details

Manufacturer: INIM Electronics s.r.l.

Place of production: Via Fosso Antico - Centobuchi

Comune: 63033, Monteprandone (AP) - Italy

Tel.: +39 0735 705007

Fax: +39 0735 704912

e-mail: [email protected]

Web: www.inim.biz

WARNING!

Only persons authorized by the manufacturer may repair or

replace the components of this device.

4Overview

NRB100 Installation and Programming Manual

1-2Product description

and models

DESCRIPTION

Self-powered outdoor hornstrobe

FIRST YEAR OF

PRODUCTION

2010

MAIN FEATURES

• Power supply and alarm trigger input

• Alarm trigger input (BELL)

• Alarm trigger input (FLASH)

• Trigger input for ancillary LED

• Programmable input polarity

• Tamper signal output

•Strobeflasher

• Piezoelectric horn

•4tones

• Dislodgement and open-casing protection

• Battery test circuit

• Houses 12V 2.1Ah backup battery

• IP34 Rated

• CEI 79-2:1998 e 79-2/Ab:2000 compliant

• Stainless-steel casing

General description 5

Installation and Programming Manual NRB100

Chapter 2

GENERAL

DESCRIPTION

2-1Box contents

Inside the box you will find:

• NRB100 Hornstrobe

• 2 frontplate screws (4x22)

• 3 wall plugs (screw 4x35) for mounting the backplate

• 1 wall plug (screw 3.5x50) for tamper microswitch

• Plastic spacer

• Installation and Programming manual

• Drilling pattern

2-2Hornstrobe description

Note

The devices that supply power to the hornstrobe must have a limit of 1.5 A.

Note

The material of the backup battery case must be HB flammability class or

better.

Table 1: Technical specifications

Operating voltage

13.8 V

Min. current draw

40 mA

Max. current draw

70 mA

Horn output (@ 3m)

110 dB(A)

Flashes per minute

Max. alarm time

8 min

Protection rating

IP34

Operating temperature

-25

to +70 °C

Battery

12V - 2,1Ah

Dimensions

(W x H x D)

293 x 203 x 52

Weight

(without battery)

1.5 Kg

Alimentazione

Voltaje operativo

Power

Assorbimento MAX

Consumo máx corriente

MAX power absorption

LBDTIN4ANRB100

13.8 V

0.070 A

MADE

ITALY

SIRENA AUTOALIMENTATA PER USO ESTERNO

SELF-POWERED SOUNDER/FLASHER FOR OUTDOOR USE

SIRENA/FLASH EXTERIOR AUTOALIMENTADA

NRB100

6General description

NRB100 Installation and Programming Manual

Table 2: Description of parts

Ter mi na l bo ar d

Programming button

Battery wires

Jumpers for tamper balance configuration

STATUS LED - Red

PRG LED - Green

Red programming LEDs

Strobe

Open casing and Dislodgement tamper

microswitch

Frontplate

Grill

Frontplate screw locations

Cable entry

Backbox screw locations

Tamper- microswitch screw location

Battery housing

Piezoelectric horns

Table 3: Terminal board

n. icon/

name Description

Positive power terminal supports 13.8V.

In 2-wire connections, this terminal will

also operate as an alarm trigger.

Negative power terminal

3+-B

BELL trigger terminal with

programmable polarity

4+-F

Strobe trigger terminal (FLASH) with

programmable polarity

5 - 6 T/AF

Tamper terminal with configurable

balance resistors

7LED

LED activation signal input

General description 7

Installation and Programming Manual NRB100

WARNING!

Do not touch the hornstrobe board while the Mains is connected.

Electric shock risk!

8General description

NRB100 Installation and Programming Manual

2-3Lights signalling

STROBE FLASHER

The strobe (Table 2, H) will flash at 2 second intervals in the event

of tamper (wire cutting) or when activated via the +-F terminal.

STATUS LED

This LED (Table 2, E) will blink at 2 second intervals during the

installation phase.

During normal functioning, it will blink at half-second intervals if the

battery drops below 11V (if this occurs, the horn and strobe flasher

will shutdown). This LED will stop signalling the battery fault when

the battery voltage restores to above 12V.

If duly programmed, this LED can be activated directly via the LED

terminal (refer to paragraph 3-4 Extra connections and Chapter 4 -

Programming).

PRG LED

If duly programmed, this LED (Table 2, F) can be activated via the

LED terminal (refer to paragraph 3-4 Extra connections and Chapter

4 - Programming).

PROGRAMMING

LEDS

These LEDs (Table 2, G) signal the current Programming phase and

any "SAVE" operations relating to the selected settings (refer to

Chapter 4 - Programming).

Table 4: Tamper device

Ta m p e r s c r e w

Spacer

Microswitch

Screw location

Microswitch-block location

Rawplug

Frontplate screw

Frontplate screw location

Installation 9

Installation and Programming Manual NRB100

Chapter 3

INSTALLATION

The Hornstrobe should be mounted high up on an even surface, in

such way that it is out of reach but clearly on view and therefore

may serve as a visible deterrent against break-in.

3-1Installation guidelines

1. Remove all power.

WARNING!

Before opening the hornstrobe, wait 30 seconds at least.

Electric shock risk!

2. Open the device casing.

3. Configure the balance resistor (refer to paragraph 3-4 Extra

connections), if you wish to forward tamper signals to the con-

trol panel.

4. Pull the connection wires through the cable entry (Table 2, O).

5. Using the wall plugs, attach the backplate to the wall (Table

2, N).

Note

Ensure that the grill (Table 2, M) is located on the under part of the device.

6. If you want to enable the tamper remove the microswitch-

block from its location (Table 4, E), then insert into this loca-

tion the spacer (Table 4, B) and the screw (Table 4, A); be

careful the microswitch (Table 4, C) position is below the

screw.

7. Locate the battery into its housing (Table 2, R) and complete

the wiring. Ensure that the battery polarity is correct.

8. Complete the device wiring. The STATUS LED (Table 2, E) will

blink at 2 second intervals during this phase.

9. Configure the device as described in Chapter 4 - Program-

ming.

10. Using the screw locations (Table 2, N) for correct alignment,

close the casing and secure it in place with the screws. The

tamper microswitch (Table 2, I) will close and the STATUS LED

will bink at half-second intervals.

11. Powerup the device. The STATUS LED will go Off.

10 Installation

NRB100 Installation and Programming Manual

3-22 wire connection

This standard wiring method triggers the device using a "Positive

Removed" signal.

This wiring method needs to disable through programming the

inputs +-B e +-F or to connect the terminals of these imputs with

the +power terminal.

The "Positive Removed" signal will trigger both the horn and strobe.

3-33 wire connection

This wiring method triggers alarm signalling on the both the horn

and strobe through the +-B and +-F inputs.

The +-B and +-F inputs must be configured as "Negative Removed"

(refer to Table 6 "Programming phases").

The wiring diagram shows a 3 wire connection configured as

"Negative Removed".

The "Positive Removed" signal will still trigger both the horn and

strobe.
