Ingersoll-Rand Xe-50 Manual de usuario

Xe-50 Controller

Insert Footer 2

•Power supply is from a

separate transformer

•Pressure transducers are

4 –20mA

•No “PAC” Protection

Xe-50 Controller

Please Note:-

Insert Footer 3

Xe-50 Controller

Temperature Sensor is 10K NTC Thermistor

Temp °C RESISTANCE (ohms) Temp °F

0 33631.0 32

5 25988.0 41

10 20244.0 50

15 15889.0 59

20 12562.0 68

25 10000.0 77

30 8013.0 86

35 6461.0 95

40 5241.0 104

45 4276.0 113

50 3507.0 122

55 2894.0 131

60 2400.0 140

65 2001.0 149

70 1677.0 158

75 1412.0 167

80 1194.0 176

85 1014.0 185

90 865.2 194

95 741.0 203

100 636.9 212

105 549.7 221

110 476.1 230

115 413.9 239

•Analog Input

–2ATT Airend Discharge Temperature

–4APT Package Discharge Pressure

Insert Footer 4

Xe-50 Controller

•Digital Input

–High Pres Dryer high pressure switch -TAS Option

–Temp Trip Dryer Temperature Trip -TAS Option

–REM Start/Stop Remote Start/Stop

–REM Load/Unload Remote Load/Unload

–FA1 Main Motor Overload

–QF4 Fan Motor Protection

–SB1 Emergency Stop

•Digital Output

–KA3 Main Drive Start Control Relay

–KM1-4 Contactors

–1SV Load/Blowdown Solenoid Valve

–KA1 Dryer Control Relay -TAS Option

Insert Footer 5

Xe-50 Controller Navigation

Navigation Keys

Reset

Enter

1: Main Display Value

2: Main Display Value Units

3: User Menu Item Display Value

4: User Menu Item Display Units

5: Status Symbols Started, Running, Loaded

6: Service/Fault Symbols Service, Fault: Alarm/Warning/Trip

Insert Footer 6

•Operational Menu - 0009

–Provides access Operator set points: -

1.Sh Service Interval Hours

1.Pu Upper Pressure Set point

1.PL Lower Pressure Set point

1.rt Run-On Time

1.bt Blowdown Time

1.St Stop Time

1.P- Pressure Display Units

1.t- Temperature Display Units

1.At Power Out Restart Time

Do not increase factory settings for pressure set points.

TAS units cannot exceed Rated Discharge Pressure.

Menu Routines

PASSCODE SETTING: WATCH THE VIDEO

This folder is for IR factory and service

personnel. A password must be entered in

order to adjust values in this menu. This

menu is used for setting parameters that

are specific to that compressor and

displaying software information for the

controller.

Xe-50 Controller

Insert Footer 7

•Configuration Menu –0121

–Provides access to Factory set points:-

2.Sd Motor Star/Delta Time

2.Ad Network Address

2.PA High Pressure Warning Level

2.PF High Pressure Trip Level

2.tA High Temperature Warning Level

2.AF High Temperature Trip Level

2.d2 C2 configuration

2.d3 C3 configuration

2.d4 C4 configuration

2.d5 C5 configuration

2.d6 C6 configuration

2.Po Pressure Sensor Offset Calibration

2.Pr Pressure Sensor Range Calibration

2.tL Low Temperature Load Inhibit

2.d5 Low Temperature Run Inhibit

Menu Routines

This menu is for IR factory and service

personnel. A password must be entered in

order to adjust values in this menu. This

menu is used for setting parameters that

are specific to that compressor and

displaying software information for the

controller.

Xe-50 Controller

Insert Footer 8

Displayed Text Full Description

•A:0060 High Sep Element Delta P (Option) DI = C6

•A:2040 Freeze Warning (TAS Option) DI = C4

•A:2050 Dryer High Pressure (TAS Option) DI = C5

•A:2118 High Pressure: alarm limit exceeded

•A:2128 High Temperature: alarm limit exceeded

•A:2816 Power Failure Detected

•A:3123 Run Inhibited

•A:3129 Airend Discharge Temperature is above 103ºC

•A:3423 Load Inhibited

•A:4804 Service Due

Warning Events –Symbol illuminated continuously

Xe-50 Controller

Insert Footer 9

Displayed Text Full Description

•E:0010 Emergency Stop

•E:0020 Motor Overload DI = C2

•E:0030 High Airend Discharge Temperature

•E:0040 High Discharge Pressure

•E:0115 Pressure Sensor Fault

•E:0119 Excess Pressure

•E:0125 Temperature Sensor Fault

•E:0129 Excess Temperature

•E:0821 Power Supply Analogue Inputs Low

•E:0866 Power supply 24V DC Low

Alarm Events –Symbol Flashing

Xe-50 Controller
