INTRODUCTION

The InFocus®LP260™ multimedia projector is specifically

designed for the mobile presenter. It generates crisp, clear images

and is easy to connect, easy to use, easy to transport, and easy to

maintain.

NOTE: The projector automati-

cally expands 640x480 images to

800x600. You can display these

images at their native resolutions

using the True feature. See “True”

on page 25 for more information.

Image Resolution

The SVGA resolution of the LP260’s projected image is 800x600.

The projector cannot compress screen resolutions above

1280x1024. If your computer’s screen resolution is higher than

1280x1024, reset it to a lower resolution before you connect the

projector.

Compatibility

The projector is compatible with a wide variety of computers and

video devices, including:

•IBM-compatible computers, including laptops, up to 1280x1024

resolution.

•Apple®Macintosh®and PowerBook®computers up to

1280x1024 resolution.

•Most standard VCRs, DVD players, HDTV sources, camcord-

ers and laser disc players.

Unpacking the Projector

The projector comes with the items shown in Figure 1. Check to

make sure all are included. Contact your InFocus dealer imme-

diately if anything is missing.

If you are experienced in setting up presentation systems, use the

Quick Start card that was included in the shipping box. For com-

plete details on connecting and operating the projector, refer to

this User’s Guide. User’s Guides are also available for download

from our website at www.infocus.com.

A registration card is included in the box. Register to receive

product updates, announcements, and special offers from

InFocus. Or, register online at www.infocus.com/service/register

and you will be automatically entered to win free merchandise.

Introduction

FIGURE 1

Shipping box contents

1. LP260 projector + lens cap 7. VGA computer cable

2. Soft carry case 8. Computer audio cable

3. User’s Guide and quick start

card

9. AV Audio cable

4. Power cords 10. Composite video cable

5. Remote control 11. S-video cable

6. Macintosh adapter 12. Control cable for PS/2 port

13. Control cable for ADB port

14. Control cable for serial port

comp

volume

mute

standbybrightness

freeze

help

light

scribble

videoliteshow

10 11

FIGURE 2

Views of the projector

connector panel

speaker

focus ring

zoom ring

power

cord

connector

keypad

foot

latch

IR receiver

exhaust vent

air intake vent

lamp cover

adjustable foot

air filters

Introduction

Usage Guidelines

•Do not look directly into the projection lens when the lamp is

turned on. The bright light may harm your eyes.

•Do not block the grills on the projector. Restricting the air flow

can cause it to overheat and turn off. If this happens, you must

wait a minute before attempting to turn it back on.

•Handle the projector as you would any product with glass

components. Be especially careful not to drop it.

•Avoid leaving the projector in direct sunlight or extreme cold

for extended periods of time. If this happens, allow it to reach

room temperature before use.

•Transport the projector in a vendor-approved hard or soft case.

Part numbers for these cases are listed on page 45.

If You Need Assistance

The first place to look for help is in this manual. Be sure to check

the guidelines in “Troubleshooting” on page 39. Or, check the

Service and Support section of our website at

http://www.infocus.com/service. You’ll find a Technical Library,

FAQs, and support contacts including a technical support e-mail

form.

If those sources don’t answer your question, call your InFocus

dealer. You can also call InFocus Customer Service directly at

1-800-799-9911. Call between 6 a.m. and 6 p.m. PST, Monday

through Friday. Service is available in North America after hours

and on weekends for a fee at 1-888-592-6800.

In Europe, call InFocus in The Netherlands at (31) 35-6474010.

In Asia, call InFocus in Singapore at (65) 332-0659.

Or, send us an e-mail at techsupport@infocus.com

Our World Wide Web a d dress is http://www.infocus.com.

Warranty

This product is backed by a limited two-year warranty. The

details of the warranty are printed at the back of this manual. A

longer term warranty can be purchased from your InFocus

dealer. Refer to page 45 for the part number.
