Data Sheet 1 Rev. 1.00

www.infineon.com 2017-07-31

TLE9261BQXV33

System Basis Chip

Mid-Range+ System Basis Chip Family

Quality Requirement Category: Automotive

Features

• Two integrated Low-Drop Voltage Regulators: Main regulator (5 V or 3.3 V

up to 250 mA) and auxiliary regulator (5 V up to 100 mA) with off-board

usage protection

• Voltage regulator (5 V, 3.3 V or 1.8 V) with external PNP transistor configurable for off-board usage or for

load sharing

• 1 high-speed CAN transceiver supporting FD communication up to 5 Mbit/s featuring CAN Partial

Networking & CAN FD tolerant mode according to ISO 11898-2:2016 & SAE J2284

•4high-sideoutputs7Ωtyp., 2 HV GPIOs, 3 HV wake inputs

• Integrated fail-safe and supervision functions, e.g. fail-safe, watchdog, interrupt- and reset outputs

• 16-bit SPI for configuration and diagnostics

Applications

• Body Control Modules (BMC), Passive keyless entry and start modules, Gateway applications

• Heating, ventilation and air conditioning (HVAC)

• Seat, roof, tailgate, trailer, door and other closure modules

• Light control modules

• Gear shifters and selectors

Description

Body System IC with Integrated Voltage Regulators, Power Management Functions, HS-CAN Transceiver

supporting CAN FD .

Featuring Multiple High-Side Switches and High-Voltage Wake Inputs.

Type Package Marking

TLE9261BQXV33 PG-VQFN-48-31 TLE9261BQXV33

Data Sheet 2 Rev. 1.00

2017-07-31

TLE9261BQXV33

1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

2 Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

3 Pin Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

3.1 Pin Assignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

3.2 Pin Definitions and Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

3.3 Hints for Unused Pins . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

3.4 Hints for Alternate Pin Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

4 General Product Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

4.1 Absolute Maximum Ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

4.2 Functional Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

4.3 Thermal Resistance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

4.4 Current Consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

5 System Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

5.1 Block Description of State Machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

5.1.1 Device Configuration and SBC Init Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

5.1.1.1 Device Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

5.1.1.2 SBC Init Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

5.1.2 SBC Normal Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

5.1.3 SBC Stop Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

5.1.4 SBC Sleep Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

5.1.5 SBC Restart Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

5.1.6 SBC Fail-Safe Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

5.1.7 SBC Development Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

5.2 Wake Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

5.2.1 Cyclic Sense . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

5.2.1.1 Configuration and Operation of Cyclic Sense . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

5.2.1.2 Cyclic Sense in Low Power Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

5.2.2 Cyclic Wake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

5.2.3 Internal Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

5.3 Supervision Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

6 Voltage Regulator 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

6.1 Block Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

6.2 Functional Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

6.3 Electrical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

7 Voltage Regulator 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

7.1 Block Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

7.2 Functional Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

7.2.1 Short to Battery Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

7.3 Electrical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

8 External Voltage Regulator 3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

8.1 Block Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

8.2 Functional Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

8.2.1 External Voltage Regulator as Independent Voltage Regulator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

8.2.2 External Voltage Regulator in Load Sharing Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Table of Contents

Data Sheet 3 Rev. 1.00

2017-07-31

TLE9261BQXV33

8.3 External Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

8.4 Calculation of RSHUNT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

8.5 Unused Pins . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

8.6 Electrical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

9 High-Side Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

9.1 Block Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

9.2 Functional Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

9.2.1 Over- and Undervoltage Switch Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

9.2.2 Overcurrent Detection and Switch Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

9.2.3 Open Load Detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

9.2.4 HSx Operation in Different SBC Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

9.2.5 PWM and Timer Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

9.3 Electrical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

10 High Speed CAN Transceiver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

10.1 Block Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

10.2 Functional Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

10.2.1 CAN OFF Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

10.2.2 CAN Normal Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

10.2.3 CAN Receive Only Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

10.2.4 CAN Wake Capable Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

10.2.5 TXD Time-out Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

10.2.6 Bus Dominant Clamping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

10.2.7 Undervoltage Detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

10.3 Electrical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

11 Wake and Voltage Monitoring Inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

11.1 Block Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

11.2 Functional Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

11.2.1 Wake Input Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

11.2.2 Alternate Measurement Function with WK1 and WK2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

11.2.2.1 Block Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

11.2.2.2 Functional Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

11.3 Electrical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

12 Interrupt Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86

12.1 Block and Functional Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86

12.2 Electrical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

13 Fail Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

13.1 Block and Functional Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

13.1.1 General Purpose I/O Functionality of FO2 and FO3 as Alternate Function . . . . . . . . . . . . . . . . . . . . 90

13.2 Electrical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

14 Supervision Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94

14.1 Reset Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94

14.1.1 Reset Output Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94

14.1.2 Soft Reset Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

14.2 Watchdog Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

14.2.1 Time-Out Watchdog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

Data Sheet 4 Rev. 1.00

2017-07-31

TLE9261BQXV33

14.2.2 Window Watchdog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

14.2.3 Watchdog Setting Check Sum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99

14.2.4 Watchdog during SBC Stop Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100

14.2.5 Watchdog Start in SBC Stop Mode due to Bus Wake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100

14.3 VS Power On Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102

14.4 Undervoltage VS and VSHS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103

14.5 Overvoltage VSHS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103

14.6 VCC1 Over-/ Undervoltage and Undervoltage Prewarning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103

14.6.1 VCC1 Undervoltage and Undervoltage Prewarning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103

14.6.2 VCC1 Overvoltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104

14.7 VCC1 Short Circuit and VCC3 Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105

14.8 VCC2 Undervoltage and VCAN Undervoltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105

14.9 Thermal Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106

14.9.1 Individual Thermal Shutdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106

14.9.2 Temperature Prewarning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107

14.9.3 SBC Thermal Shutdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107

14.10 Electrical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108

15 Serial Peripheral Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112

15.1 SPI Block Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112

15.2 Failure Signalization in the SPI Data Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113

15.3 SPI Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115

15.4 SPI Bit Mapping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117

15.5 SPI Control Registers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120

15.5.1 General Control Registers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121

15.6 SPI Status Information Registers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139

15.6.1 General Status Registers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140

15.6.2 Family and Product Information Register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150

15.7 Electrical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151

16 Application Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 153

16.1 Application Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 153

16.2 ESD Tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 158

16.3 Thermal Behavior of Package . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159

17 Package Outlines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 161

18 Revision History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 162

Data Sheet 5 Rev. 1.00

2017-07-31

TLE9261BQXV33

Overview

1 Overview

Scalable System Basis Chip Family

• Product family with various products for complete scalable application coverage.

• Dedicated Data Sheets are available for the different product variants

• Complete compatibility (hardware and software) across the family

• TLE9263 with 2 LIN transceivers, 3 voltage regulators

• TLE9262 with 1 LIN transceiver, 3 voltage regulators

• TLE9261 without LIN transceivers, 3 voltage regulators

• Product variants for 5V (TLE926xQX) and 3.3V (TLE926xQXV33) output voltage for main voltage regulator

• CAN Partial Networking variants for 5V (TLE926x-3QX) and 3.3V (TLE926x-3QXV33) output voltage

Device Description

The TLE9261BQXV33 is a monolithic integrated circuit in an exposed pad VQFN-48 (7mm x 7mm) power

package with Lead Tip Inspection (LTI) feature to support Automatic Optical Inspection (AOI).

The device is designed for various CAN automotive applications as main supply for the microcontroller and as

interface for a CAN bus network.

To support these applications, the System Basis Chip (SBC) provides the main functions, such as a 3.3V low-

dropout voltage regulator (LDO) for e.g. a microcontroller supply, another 5V low-dropout voltage regulator

with off-board protection for e.g. sensor supply, another 3.3V/1.8V regulator to drive an external PNP

transistor, which can be used as an independent supply for off-board usage or in load sharing configuration

with the main regulator VCC1, a HS-CAN transceiver supporting CAN FD for data transmission, high-side

switches with embedded protective functions and a 16-bit Serial Peripheral Interface (SPI) to control and

monitor the device. Also implemented are a configurable timeout / window watchdog circuit with a reset

feature, three Fail Outputs and an undervoltage reset feature.

The device offers low-power modes in order to minimize current consumption on applications that are

connected permanently to the battery. A wake-up from the low-power mode is possible via a message on the

buses, via the bi-level sensitive monitoring/wake-up inputs as well as via cyclic wake.

The device is designed to withstand the severe conditions of automotive applications.

Data Sheet 6 Rev. 1.00

2017-07-31

TLE9261BQXV33

Overview

Product Features

• Very low quiescent current consumption in Stop- and Sleep Mode

• Periodic Cyclic Wake in SBC Normal- and Stop Mode

• Periodic Cyclic Sense in SBC Normal-, Stop- and Sleep Mode

• Low-Drop Voltage Regulator 3.3V, 250mA

• Low-Drop Voltage Regulator 5V, 100mA, protected features for off-board usage

•Low-Drop Voltage Regulator, driving an external PNP transistor - 3.3V in load sharing configuration or

3.3V/1.8V in stand-alone configuration, protected features for off-board usage. Current limitation by shunt

resistor (up to 350mA with 470mexternal shunt resistor) in stand-alone configuration

• High-Speed CAN Transceiver:

– fully compliant to HS-CAN standard ISO 11898-2:2016

– supporting CAN FD communication up to 5 Mbps

• Fully compliant to “Hardware Requirements for LIN, CAN and FlexRay Interfaces in Automotive

Applications” Revision 1.3, 2012-05-04

•FourHigh-SideOutputs7Ωtyp.

• Dedicated supply pin for High-Side Outputs

•Two General Purpose High-VoltageIn- and Outputs (GPIOs) configurable as add. Fail Outputs, Wake Inputs,

Low-Side switches or High-Side switches

• Three universal High-Voltage Wake Inputs for voltage level monitoring

• Alternate High-Voltage Measurement Function, e.g. for battery voltage sensing

• Configurable wake-up sources

• Reset Output

• Configurable timeout and window watchdog

•Up to three Fail Outputs (depending on configuration)

• Overtemperature and short circuit protection feature

• Wide supply input voltage and temperature range

• Software compatible to all SBC families TLE926x and TLE927x

• Green Product (RoHS compliant) & AEC Qualified

• PG-VQFN-48 leadless exposed-pad power package with Lead Tip Inspection (LTI) feature to support

Automatic Optical Inspection (AOI)

Data Sheet 7 Rev. 1.00

2017-07-31

TLE9261BQXV33

Block Diagram

2 Block Diagram

Figure 1 Block Diagram

CC1

SPI

Interrupt

Control

SBC

STATE

MACHINE

SDI

SDO

CLK

CSN

VCC1

CAN cell

Window Watchdog

TXDCAN

RXDCAN

VCAN

CANH

CANL

WK1

RESET

GENERATOR

INT

GND

WAKE

Fail Safe

FO3/TEST

FO2

FO1

CC2

VCC2

High Side

HS2

HS3

HS4

HS1

WK2

WK3

CC 3

VCC3REF

VCC3SH

VCC3B

VSHS VS

Al ter nati ve function

for FO 2/ 3: GPIO 1 /2

Alternati v e

func ti on f or W K 1 /2:

Voltage m easur em ent

Data Sheet 8 Rev. 1.00

2017-07-31

TLE9261BQXV33

Pin Configuration

3 Pin Configuration

3.1 Pin Assignment

Figure 2 Pin Configuration

TLE9261

PG-VQFN-48

TLE9261 .vsd

1GND

2 n.c.

3 VCC3REF

4 VCC3B

5 VCC3SH

6 n.c.

7 n.c.

8HS1

9 HS2

10 HS3

11 HS4

12 n.c.

FO3/TEST 48

FO2 47

n.c. 46

n.c. 45

N.U. 44

GND 43

N.U. 42

n.c. 41

CANH 40

CANL 39

GND 38

VCAN 37

13 VSHS

14 VS

15 VS

16 n.c.

17 VCC1

18 VCC2

19 n.c.

20 GND

21 FO1

22 WK1

23 WK2

24 WK3

25 N.U.

26 N.U.

27 CLK

28 SDI

29 SDO

30 CSN

31 INT

32 RO

33 N.U.

34 N.U.

35 TXDCAN

36 RXDCAN

Data Sheet 9 Rev. 1.00

2017-07-31

TLE9261BQXV33

Pin Configuration

3.2 Pin Definitions and Functions

Pin Symbol Function

1GND Ground

2n.c. not connected; internally not bonded.

3VCC3REF VCC3REF; Collector connection for external PNP, reference input

4VCC3B VCC3B; Base connection for external PNP

5VCC3SH VCC3SH; Emitter connection for external PNP, shunt connection

6n.c. not connected; internally not bonded.

7n.c. not connected; internally not bonded.

8HS1 High Side Output 1; typ. 7Ω

9HS2 High Side Output 2; typ. 7Ω

10 HS3 High Side Output 3; typ. 7Ω

11 HS4 High Side Output 4; typ. 7Ω

12 n.c not connected; internally not bonded.

13 VSHS Supply Voltage HS and GPIO1/2 in HS configuration; Supply voltage for High-

Side Switches modules and respective UV-/OV supervision; Connected to

battery voltage with reverse protection diode and filter against EMC;

connect to VS if separate supply is not needed

14 VS Supply Voltage; Supply voltage for chip internal supply and voltage

regulators; Connected to Battery Voltage with external reverse protection

Diode and Filter against EMC

15 VS Supply Voltage; Supply voltage for chip internal supply and voltage

regulators; Connected to Battery Voltage with external reverse protection

Diode and Filter against EMC

16 n.c. not connected; internally not bonded.

17 VCC1 Voltage Regulator Output 1

18 VCC2 Voltage Regulator Output 2

19 n.c. not connected; internally not bonded.

20 GND GND

21 FO1 Fail Output 1

22 WK1 Wake Input 1; Alternative function: HV-measurement function input pin

(only in combination with WK2, see Chapter 11.2.2)

23 WK2 Wake Input 2; Alternative function: HV-measurement function output pin

(only in combination with WK1, see Chapter 11.2.2)

24 WK3 Wake Input 3

25 N.U. Not Used; Used for internal testing purpose. Do not connect, leave open

26 N.U. Not Used; Used for internal testing purpose. Do not connect, leave open

27 CLK SPI Clock Input

28 SDI SPI Data Input; into SBC (=MOSI)

29 SDO SPI Data Output; out of SBC (=MISO)

Data Sheet 10 Rev. 1.00

2017-07-31

TLE9261BQXV33

Pin Configuration

Note: all VS Pins must be connected to battery potential or insert a reverse polarity diodes where required;

all GND pins as well as the Cooling Tab must be connected to one common GND potential;

note that the tie bars at each package corner are connected to the cooling tab (see also Chapter 17)

30 CSN SPI Chip Select Not Input

31 INT Interrupt Output; used as wake-up flag for microcontroller in SBC Stop or

Normal Mode and for indicating failures. Active low.

During start-up used to set the SBC configuration. External pull-up sets config

1/3, no external pull-up sets config 2/4.

32 RO Reset Output

33 N.U. Not Used; Used for internal testing purpose. Do not connect, leave open

34 N.U. Not Used; Used for internal testing purpose. Do not connect, leave open

35 TXDCAN Transmit CAN

36 RXDCAN Receive CAN

37 VCAN Supply Input; for internal HS-CAN cell

38 GND GND

39 CANL CAN Low Bus Pin

40 CANH CAN High Bus Pin

41 n.c. not connected; internally not bonded.

42 N.U. Not Used; Used for internal testing purpose. Do not connect, leave open

43 GND Ground

44 N.U. Not Used; Used for internal testing purpose. Do not connect, leave open

45 n.c. not connected; internally not bonded.

46 n.c. not connected; internally not bonded.

47 FO2 Fail Output 2 - Side Indicator; Side indicators 1.25Hz 50% duty cycle output;

Open drain. Active LOW.

Alternative Function: GPIO1; configurable pin as WK, or LS, or HS supplied by

VSHS (default is FO2, see also Chapter 13.1.1)

48 FO3/TEST Fail Output 3 - Pulsed Light Output; Break/rear light 100Hz 20% duty cycle

output;

Open drain. Active LOW

TEST; Connect to GND to activate SBC Development Mode;

Integrated pull-up resistor. Connect to VS with pull-up resistor or leave open for

normal operation.

Alternative Function: GPIO2; configurable pin as WK, or LS, or HS supplied by

VSHS (default is FO3, see also Chapter 13.1.1)

Coolin

g Tab

GND Cooling Tab - Exposed Die Pad; For cooling purposes only, do not use as an

electrical ground.1)

1) The exposed die pad at the bottom of the package allows better power dissipation of heat from the SBC via the PCB.

The exposed die pad is not connected to any active part of the IC an can be left floating or it can be connected to GND

(recommended) for the best EMC performance.

Pin Symbol Function

Tabla de contenidos

Otros manuales de Computadora de placa única de Infineon

Infineon

Infineon PSoC 61 Manual de usuario

Infineon

Infineon PSoC 4000S Manual de usuario

Infineon

Infineon TLE9262BQXV33 Manual de usuario

Infineon

Infineon Cypress CYW43353 Manual de usuario

Infineon

Infineon Cypress WICED CYW43903 Manual de usuario

Manuales populares de Computadora de placa única de otras marcas

WIN Enterprises

WIN Enterprises PL-80910 Manual de usuario

AXIOMTEK

AXIOMTEK SBC81206 Series Manual de usuario

Embest

Embest SOM-PH8800 Manual de usuario

SeaLevel

SeaLevel SBC-R9 Manual de usuario

SMART Embedded Computing

SMART Embedded Computing ATCA-8310 Manual de usuario

WinSystems

WinSystems PPM-LX800-G Manual de usuario

GIGAIPC

GIGAIPC QBiX-PPC Series Manual de usuario

OLIMEX

OLIMEX A10S-OLinuXino-MICRO Manual de usuario

Commell

Commell FS-978 Manual de usuario

GIGAIPC

GIGAIPC QBiP-8665A/ Manual de usuario

VersaLogic

VersaLogic Python EBX-11 Manual de usuario

Micro Computer Specialists

Micro Computer Specialists IRV-3702 Manual de usuario

CompuLab

CompuLab SB-A510 Manual de usuario

Boser

Boser HS-7321 Manual de usuario

Premier Farnell

Premier Farnell Embest SBC8530 Manual de usuario

MicroSys Electronics

MicroSys Electronics miriac SBC-LS1043A2 Manual de usuario

Aaeon

Aaeon UP Manual de usuario

Portwell

Portwell WUX Series Manual de usuario
