SetupMenu—TachPulseCount
Tach Input Pulse Per Revoluon ‐this seng determines the number of Tach Pulses per revoluon of the
cranksha.
Example ‐if the Tach Signal input is connected to a common V8 engine mul‐spark ignion controller a seng of 4
Pulse per Revoluon would be used.
Common sengs are,
1 Pulse per Two Revoluons = modern coil on plug systems with white wire connected to single coil wire.
1 Pulse per Revoluon = single cylinder engine and some twin cylinder motorcycle engines.
2 Pulse per Revoluon = 4 cylinder car and motorcycle engines.
3 Pulse per Revoluon = 6 cylinder engines.
4 Pulse per Revoluon = 8 cylinder engines.
1—Press the SETUP buon from the main screen.
2—Highlight the Pulse Per Rev menu selecon and press the ENTER buon. (If Help is on choose opon)
3—Highlight the Pulse per Rev seng desired and press the ENTER buon to save.
4—Press the BACK buon to return to the main screen.
SetupMenu—TransBrakeInputDelay
Trans Brake/Clutch Input Delay Timer ‐this seng controls how long the Trans Brake/Clutch input must be On before
accepng the signal. The clutch input hold delay seng is ignored unl the controller is Acvated. Before the controller
is Acvated the clutch input is recognized in real me with no delay. This seng could be used to ignore shis with a
manual transmission (1 second) or a very low seng would act as noise filter to ignore spurious signals (.005 second).
If a clutch input signal is received and accepted aer the controller is acvated the system will turn offthe progressive
system and mers. This would allow the nitrous to be turned Offduring a shiand resumed when the clutch is re‐
leased.
1—Press the SETUP buon from the main screen.
2—Highlight the Tbrake In Delay menu selecon and press the ENTER buon. (If Help is on choose opon)
3—Adjust the value as desired. (See “Slider Bar, Value Adjust Overview”)
4—Press the BACK buon to return to the main screen.
SetupMenu—RPMWindowEnable
Enable RPM control ‐this seng enables a RPM Window funcon for both Outputs.
NOTE ‐If the RPM window feature is enabled and the engine is not running the solenoids can be dry fired for tesng.
Once an RPM signal is present the solenoids will only fire at the desired RPM range.
1—Press the SETUP buon from the main screen.
2—Highlight the RPM Window (ON/OFF) menu selecon and press the ENTER buon. (If Help is on choose opon)
3—Choose YES or NO to enable or disable the opon.
4—Press the BACK buon to return to the main screen.
