iMuon AH120A Manual de usuario
www.imuon.com
Corp.
AH120A
1702 East B/D IT Venture 78,
Garakbon-Dong, Songpa-Gu, Seoul Korea
INTERNET : http://www.imuon.com
3
TABLE of Contents
1. Product Guide....................................................................4
2. Product features.................................................................5
3. Precautions.........................................................................7
4. Components.......................................................................9
5. Locating the Controls......................................................11
6. Connection.......................................................................13
7. Driver Installation and Folder Generation.....................14
8. User Manual.....................................................................19
9. Q&A....................................................................................30
10. Product Specification....................................................33
11. Customer Support........................................................34
iMuon AH120A is a compact and stylish, portable multi media player
and handheld hard disk. Your iMuon has been designed to perform
a number of functions ranging from displaying DVD quality video or
text files through the built-in QVGA TFT-LCD, playing MP3/WMA
music files or allowing you to enjoy these features on your TV via AV
cable or IR remote control.
iMuon is handy for anyone on the go. While traveling, you can view
movies and video lectures. You can store and view photo albums
and listen to MP3/WMA files. You can also read text files like
electronic novels, essays or other text files. iMuon is compatible with
MP3, WMA, AVI, DivX, XViD, VOB, DAT, MPEG and JPEG multi
media file formats.
Dvix files with subtitles, such as SMI, are supported. Subtitle
languages currently supported are Korean, English, Japanese and
Chinese. Additional languages are also supported through firmware
upgrades available on our web site at www.imuon.com. The player
supports data transfer speeds of 480mbps through a USB 2.0
connection. iMuon can also be used as a 20GB removable hard
disk.
You can connect iMuon to a TV with an AV cable, using the player
like a VTR or you can connect via iMuon’s IR functionality. Through
the TV, you can play all your favorite media files - from Dvix to
MP3s!
4 5
1. Product Guide 2. Product Features
UV coated body and ultra miniature size with a super high
quality, detailed, QVGA quality, color LCD screen with backlight.
Room enough to store up to 30 of your favorite
movies or 4,500 MP3 songs or 40,000 digital photos. The iMuon
combines a modular MPEG-4 video player, MP3 music player, digital
photo album, and data storage into a compact device that fits in the
palm of your hand.
Built-in, QVGA quality, 2.2¡–TFT LCD supporting 260,000
colors.
Video functions support resolution up to a maximum 1920 x
1080 or 30 frames per second (normal video speed).
High quality video and audio play functionality through
Composite out and AV Stereo audio out.
TV out function switch able to NTSC / PAL
Wide bit rate range from 30 ~ 320 kb/s and 5 Equalizers that
change according to desired music genre.
Stores up to 4,500 audio files for your listening pleasure.
S/PDIF output supported to produce 5.1 channel stereo
sound through Coaxial or Optical output (Cable optional).
Plays DivX 3.x, 4.x, 5.x and Xvid video files.
Stores and provides viewing capability for up to 40,000 .jpg
file photos.
JPG Photo
DivX Video
Optical Output
MP3 Audio
5 Equalizer
NTSC/PAL
TV Out
HQ Video
QVGA Display
20GB HDD
Quality Design
7
Stores and provides viewing capability for text files that can
be read on the go.
Allows the player to be operated by the buttons on the
device, wired Remote Control or by wireless Remote Control.
Backlight function allows the backlight on/off time to be
adjusted.
High speed data transfer at a maximum 480Mbps. Firmware
easily upgradeable through the USB port.
Currently supports subtitles in Korean, Japanese,
Chinese and English.
Built-in speakers provide high quality stereo sound
without earphones.
Built-in Li-Polymer battery allows a maximum play
time of 10 hours for MP3 audio files or 5 hours for video files.
Battery is rechargeable through an AC adapter, 24
pin rechargeable cable in the mobile travel kit or by USB cable.
Firmware upgrades and User support available at
www.imuon.com.
Firmware Upgradeable
Rechargeable
Li-Polymer Battery
Stereo Speaker
Multi Language Subtitles
USB 2.0
Back Light
3 Way Control
e-Book Text
6
2. Product Features 3. Precautions
If the AC adapter is plugged in and
begins to smoke, produces a burning
smell or becomes excessively noisy,
unplug immediately. Failure to do so may
result in fire or electrical shock.
When plugging the AC Adapter into the
power outlet, make sure it is properly
plugged into the socket. Failure to do so
may result in fire or electrical shock.
NO!
Do not plug in the AC Power Adapter
with wet hands. Use Only the AC Power Adapter
supplied with the player. Other adapters
may result in fire or electrical shock.
In stormy weather, unplug the AC
adaptor from the wall outlet. Failure to do
so may result from power surges.
Do not dissemble, repair or alter the
player.
9
■Main body
■Wired Remote Control
4. Components
MENU
REW. F.F
VOL
ON
OFF
VOL
■Wireless IR Remote Control
8
3. Precautions
Keep the player away from any strong
magnetic force. This can cause
malfunctions in the Hard Drive.
Avoid dropping or physically impacting
the player. Dropping or physically
impacting the player may cause
damage.
Clean the player with a soft cloth or towel.
Never clean the player with a chemical
solutionlike Benzene,Acetone, paintthinner or
solvent.These chemicalscan causetheplayer
tochange coloror looseits paint.
Do not leave the player exposed to
excessive dust or sand, moisture,
physical shock or rough surfaces.
Do not leave the player near heat
sources, direct sunlight, or in a car with
closed windows.
Do not dissemble, repair or alter the
player.
11
5. Locating the Controls
Main Body
USB2.0 Ext. I/O RESET DC5V
MENU
REW. F.F
VOL
ON
OFFVOL
HOLD
Main Menu/Sub Menu
Volume/Menu/Folder Up
Rewind/Previous
Operating Indicator/
Charging Indicator LED
Built-In Speaker
IR Receiver
Remote Control
/Earphone Jack
USB Connection Port Reset
DC IN 5.0V
24 Pin Expandable
Connection Port
Hold
LCD Window
LCD/
TV Converter
Stop/Power Off
Fast Forward/Next
Volume/Menu/
Folder
Down
Power On/Play/Paus
LCD/TV
* Accessories are subject to change without notice and may vary from images shown.
10
4. Components
■USB Cable■Earphones
■A/V Cable■AC Adapter (DC 5V 2A)
■Carrying Case
■User Manual/Warranty card
■Install CD
13
6. Connection
1. Connecting to a
USB cable 2. Connecting iMuon to a
24 pin connection cable 3. Connecting iMuon to
the AC Power Adapter
(Video Input - Yellow, Audio Input - White, Red)
PC
USB1.1/2.0
MENU OFF DOWN VOL UP
MIC
ON
MENU
REW. F.F
VOL
ON
OFF
VOL
Video Cable(Yellow)
Audio Cable(White, Red)
Adapter
Main Body
Main Body
EarphoneRemote Control
TV
12
5. Locating the Controls
Wired Remote Control
Wireless IR Remote Control
MENU OFF DOWN VOLVOL UPUP
MIC
HOLD
ON
Hold
Main Menu/Sub Menu End point of the section repeat/
Stop the section repeat
Joy Stick for Multi
Function Control/
Play/Power On
Stop/Power Off Start point of the section repeat
LCD Window
Power Off
Main Menu/Sub Menu
Execution/Play/Save
Previous Next
Rewind Fast Forward
End point of section repeat/
stop the section repeat
Zoom In/Out
File Information
Mute
Time Search
Stop
Play
Pause
TV/LCD Converter
Start point of section repeat
NOTE: You must turn the power on after connecting the USB Cable or the
AV Cable or the Wired Remote Control to avoid loss of data or
freezing the computer and/or the device.
14 15
7. Driver Installation and Folder Generation 7. Driver Installation and Folder Generation
Windows 2000/XP
Windows 2000 and Windows XP are programmed to automatically
support USB2.0 storage devices. iMuon can be used without any
program installation.
Windows 98/ME
Although Windows 2000 and Windows XP automatically support USB 2.0,
Windows 98/ME does not. To use iMuon on a Windows 98/ME computer,
you must first install the storage device driver. To install, insert the installation
CD into the CD Rom and follow the prompts. If the installation CD is not
available, you can download the driver at www.iMuon.com.
1. Windows 98/ME has recognized a new piece of hardware and starts its
wizard. Click on Next.
2. Click on the button search for the best driver Now click on Next.
3. Uncheck all of the checked boxes, and then check the box specify the
drive to. Click on Next and Windows will then load the correct drivers.
17
7. Driver Installation and Folder Generation
16
7. Driver Installation and Folder Generation
4. Windows is now ready to install the driver into its operating system. Click
on Next to tell Windows to install the driver.
5. Windows will indicate when it has finished copying the drivers. Click on
Finish. Do not unplug the device from the computer yet.
6. Once finished, you should restart your computer. Upon restart, it will
automatically recognize the connected device. It will be seen as another
hard disk in Windows Explorer.
NOTE: You must properly remove your device from the computer before
disconnecting the USB cable to avoid loss of data or freezing the
computer and/or the device.
Attention: The operating system will not allow you to safely disconnect the
device if you have an open file from it in a running application. You
will have to close all open the device files in any running application.
Sometimes even when files are closed in an application, you will
have to shut down the application. Using the green disconnect
arrow in the system tray will then allow you to safely disconnect the
device.
Windows
To safely disconnect the device, click on the system tray remove icon (green
arrow) and follow the instructions. Wait until you get a message saying that
you can safely unplug the device before disconnecting the USB cable.
19
8. User guide
To turn on the player, push and hold the ON button of the device or
the ON button of the joy stick on the wired remote control. Once the
player is on, the LCD will display the main menu.
NOTE: The player can’t be turned on via the wireless remote control.
To turn on the player
MENU
REW. F.F
VOL
ON
OFFVOL
MENU OFF DOWN VOL UP
MIC
ON
To turn the player off, push and hold the OFF button on the player or the wired
remote control. You may also press and hold the Power button on the
wireless remote control.
NOTE: When “Hold” is ON, the buttons on the player will not function.
If the player has been stopped or is idle for 30 minutes, it will automatically
turn off per the STOP POWER OFF default setting.
To turn off the player
MENU
REW. F.F
VOL
ON
OFFVOL
MENU OFF DOWN VOL UP
MIC
ON
18
7. Driver Installation and Folder Generation
To generate folders
The player has the following, basic folders that are listed below.
Folder names may be changed or new folders may be added as
desired by the user.
Audio: Folder to store MP3 and WMA Audio files.
E-BOOK:
Folder to store
*.txt electronic books and other files.
Photo: Folder to store
*.jpg photos.
Video: Folder to store
*.avi, DivX 3.x, 4.x, 5.x, Xvid and mpg video files.
Tabla de contenidos
