3. Slide the NEW 3 V, CR2032, Lithium cell Battery under the metal clip of the Battery
Holder, with the "+" Terminal facing UP.
4. Pull the plastic clip away from the Battery Holder and press the Battery firmly into
the Battery Holder.
5. Complete replacement by:
For ICS96X, replace the Controller’s Cover Plate.
For IPS96X, close the Lid of the Cabinet.
Installing the 12 V Sealed Lead Acid Battery
Power Supply Combo
1. Open the Lid of the Cabinet.
2. Slide the Lid in an upwards direction and unhinge.
3. Place the Battery into the Cabinet with the Battery Terminals in an upwards
position.
4. Connect the Red Battery Terminal Lead to the Positive Battery Terminal.
5. Connect the Black Battery Terminal Lead to the Negative Battery Terminal.
6. Re-hinge the Lid and slide it in a downwards direction.
7. Close the Lid of the Cabinet.
Installing the ImproX GSM Module (Optional Extra)
CAUTION: Connect the ImproX GSM Module BEFORE powering up the IXP220
Controller. Power down the IXP220 Controller BEFORE removing
the GSM Module.
1. Insert the SIM Card as shown on the Module.
2. Access the IXP220 Controller’s Printed Circuit Board (PCB):
For ICS96X, remove the Controller’s Cover Plate.
For IPS96X, open the Lid of the Cabinet.
3. Locate the GSM Module Connectors (See Figure 4).
4. Plug in the GSM Module with the SIM Card Slot positioned on the right-hand side.
5. Plug the GSM Quad Band Antenna into the base of the Module.
6. Select a suitable position for the GSM Quad Band Antenna, considering
accessibility and routing of wires for optimal signal strength.
CAUTION: Ensure that you locate the GSM Quad Band Antenna outside of the
Power Supply Combo (IPS96X) as the metal housing interferes with
the Antenna’s reception.
7. Use the Alcohol Prep Pad (provided) to clean the selected area.
8. Remove the backing paper from the back of the GSM Quad Band Antenna.
9. Affix the GSM Quad Band Antenna in position.
10. Complete installation by:
For ICS96X, replace the Controller’s Cover Plate.
For IPS96X, close the Lid of the Cabinet.
