WHEELMAN
MAINTENANCE AND CLEANING
The WHEELMAN Mixer requires very low maintenance.However, a few basic maintenance procedures
shouldbefollowed.
NOTE: Always unplug the mixer from its power source before cleaning or maintenance
functions are performed.
1) Clean the mixer after each use and do not allowany concrete to build up on anyportion of the mixer.
2) Essentially the gearbox is sealed for life. The quality of the gears and the lubricant are such that
changing the oil is not necessary. Should you want to change the oil, see your dealer or call IMER
U.S.A. @ 800.275.5463.
3) Keep all moving parts lightly lubricated with WD-40.
4) Keep the electric motor cooling fins clean and free of debris build-up.
5)BeforestoringtheWHEELMAN afteraprojectis completed,sprayn'wipetheentiremachinewithWD-
40, and store it inside.
NOTE: When cleaning the mixer with water, do not spray the water onto the motor or the
ON/OFF switch assembly.
SPARE PARTS
All orders forspare parts must include the following:
1) Type of machine.(Example: concrete mixer)
2) Part number and drawing referencesof each part,see the parts list.
3) Serial numberand year of manufacturerecorded on the machine's identification plate.
OPERATION
WHEELMAN WITH ELECTRIC MOTOR
1) Use a2 prong, grounded, 110/115 Volt powerconnection for safe operation. The line should be at least
12 gauge.
2) To mix concrete, add water, concrete, and aggregate while the drum is rotating.
3) Discharge the mixed concrete by lifting up the dump handle Drawings #7 page 9 while the drum is
rotating.
NOTE: When tilting the drum to discharge the concrete, do so slowly. It is important to
perform the discharge smoothly, this keeps the machine balanced and upright.
4)TheON/OFFswitchonthe motoroftheWHEELMAN mixerprovidesthermalprotectionto the motorin
the event of overheating. Should your motor shut off automatically, turn off the unit and unplug it for 15
minutes. This allows the motor to cool. After the cooling period, plug in the motor and press the start
switch. If the motor does not restart and continue to run, contact your local IMER products distributor, or
call IMER direct @ 800.275.5463.
®
®
®
