EASYLOG BLUETOOTH QUICKSTART GUIDE
EASYLOG
EASYLOG BLUETOOTH
QUICK START GUIDE
Your data logger will arrive partially charged. For optimum
performance, charge it for 24 hours before use until no battery
symbol is displayed. Please use the USB cable provided.
Battery states
The symbols below show the various battery states:
Before the data logger can be set up, you must
install the EasyLog BT app available on Google
Play™.
The sensor will display a reading, but it will not
record until the app is installed and setup is
complete.
1. CHARGE YOUR DATA LOGGER
2. INSTALL ANDROID™ APP AVAILABLE ON
GOOGLE PLAY™
Battery OK/charged
No symbol displayed
Battery low
Solid
Battery charging
Flashing
Another solution from The IMC Group Ltd.
Pendle House, Jubilee Road, Letchworth, Hertfordshire SG6 1SP
Tel: +44 (0)1462 688070 | Email: [email protected] | Visit: www.the-imcgroup.com
EASYLOG BLUETOOTH QUICKSTART GUIDE
Open the EasyLog BT app on your Android™ device and follow
the on-screen instructions for connecting your logger.
A Bluetooth connection is established after pressing the button
on the logger, then selecting that logger from the scanned list in
the Android™ app. You will be prompted with a Bluetooth pairing
request. Enter the default logger password that is listed on-
screen or on the back of the logger.
3. SET-UP THE DATA LOGGER
Connection status
Wireless connectivity is enabled for two minutes after pressing the button on the logger. The Bluetooth symbol will
flash to show connection is possible. While connected, the Bluetooth logo will be on solidly. During the setup process
there are options to keep the display and/or Bluetooth module on at all times, but this will severely limit the battery
life.
Bluetooth
For a full product data sheet for your logger, or for more
information on the rest of the EasyLog range visit
www.the-imcgroup.com
4. YOUR LOGGER IS NOW READY
Android™ app features
Within the app you can set the sample
rate, temperature scale, temperature and
humidity alarms, Bluetooth power-save
settings, LCD settings and variable start
times. Downloaded data will be saved to
your phone’s memory card and can be
viewed any time. This data can then be sent
via email or your preferred cloud service, to
another device or PC for further analysis.
Another solution from The IMC Group Ltd.
Pendle House, Jubilee Road, Letchworth, Hertfordshire SG6 1SP
Tel: +44 (0)1462 688070 | Email: [email protected] | Visit: www.the-imcgroup.com
EASYLOG BLUETOOTH QUICKSTART GUIDE
GETTING TO KNOW YOUR LOGGER
LED Status
LCD Screen
Green & red single flash (together)
The data logger is in push-to-start mode Push button to start logging
Green single flash
The data logger is currently logging
No alarm has been triggered
No action required
Red single flash
The data logger is currently logging
The low alarm has been triggered!
Check your logger’s status using your Android™ device
Red double flash
The data logger is currently logging
The high alarm has been triggered!
Check your logger’s status using your Android™ device
No LEDs flash
The data logger is stopped or is in delayed
start mode
Check your logger’s status using your Android™ device
Another solution from The IMC Group Ltd.
Pendle House, Jubilee Road, Letchworth, Hertfordshire SG6 1SP
Tel: +44 (0)1462 688070 | Email: [email protected] | Visit: www.the-imcgroup.com
EASYLOG BLUETOOTH QUICKSTART GUIDE
Repairing or Modifying
Never attempt to repair or modify EasyLog
products. Dismantling them, other than
for the purpose of changing replaceable
batteries, may cause damage that is not
covered under the warranty. Servicing should
only be provided by an authorised supplier.
Disposal and Recycling Information
You must dispose of EasyLog products
in accordance with relevant laws and
regulations. They contain electronic
components and lithium batteries and
therefore must be disposed of separately
from household waste.
Need help with your data logger?
The IMC Group Ltd.
Pendle House,
Jubilee Road,
Letchworth,
Hertfordshire,
SG6 1SP,
United Kingdom
Tel: +44 (0)1462 688070
Email: [email protected]
For more information visit
www.the-imcgroup.com
IMPORTANT SAFETY INFORMATION
WARNING: Failure to follow these safety instructions could result in fire, electrical shock, other injury or damage.
