WARNING
PLANNING and INSTALLING YOUR SYSTEM
High powered audio systems in a vehicle are capable of generating “Live Concert”
levels of sound pressure. Continued exposure to excessively high volume sound
levels may cause hearing loss or damage. Also, operation of a motor vehicle while
listening to audio equipment at high volume levels may impair your ability to hear
external sounds such as; horns, warning signals, or emergency vehicles, thus
constituting to a potential traffic hazard.
Installation Applications
This amplifier is designed for operation in vehicles with 12V, negative-ground electrical
systems. Use of this product in vehicles with positive ground and/or voltages other than
12V may result in damage to the product and will void the warranty.
Planning Your Installation
It is important that you take the time to read this manual and that you plan out your
installation carefully. The following are some considerations that you must take into
account when planning your installation.
Installation Guidelines
Mounting your Amplifier is easy. Keep in mind the following guidelines:
- Supply ample power, Amplifiers do not make power they convert the current from the
cars battery into musical energy through the speakers in your system.
- Proper ground connection is required. The ground for the amplifier must carry the
same current as the positive power wire. It is suggested to upgrade the factory ground
wire from the battery to the chassis of your vehicle.
· The amplifier requires adequate ventilation. Position the amplifier with sufficient
surrounding area for proper cooling. If possible mount amplifier in a vertical position .
· Keep the amplifier out of the engine compartment and other locations that may
cause excessive heat or moisture.
·Do not mount the amplifier to a subwoofer enclosure or any other place that
may have excessive vibration!
- It is required that the main power wire for the amplifier(s) be fused within 18”
of the battery for safety.
Mistakes to Avoid:
-Check before drilling any holes in your vehicle to make sure that you will not be drilling
through a gas tank, brake line, wiring harness or other vital vehicle system.
-Do not run system wiring outside or underneath the vehicle. This is an extremely
dangerous practice which can result in severe damage to your vehicle and person.
- Protect all system wires from sharp metal edges and wear by carefully routing them,
tying them down, and using grommets & loom where appropriate.
