ILVE KHVI90TC Guía

10-2016
KHVI90TCKHVI90TC
cod. I/301/00/29
GB
Installation and users instruction
INDUCTION HOBINDUCTION HOB
GB

2
Index
Important safety warning ��������������������������������������������������������� 4
General description���������������������������������������������������������������������� 8
Ventilation ���������������������������������������������������������������������������������������������������������������8
First switch-on ���������������������������������������������������������������������������������������������������������8
Control description����������������������������������������������������������������������� 9
Displayed functions���������������������������������������������������������������������������������������������������9
Functions �������������������������������������������������������������������������������������������������������������� 10
Turning on appliance����������������������������������������������������������������������������������������������� 11
Turning on a cooking area���������������������������������������������������������������������������������������� 11
Turning off a cooking area ��������������������������������������������������������������������������������������� 11
Turning off all cooking areas ������������������������������������������������������������������������������������ 11
Power levels ��������������������������������������������������������������������������������������������������������� 11
Booster “P”������������������������������������������������������������������������������������������������������������ 11
Joining two areas ��������������������������������������������������������������������������������������������������� 11
Automatic turning off ���������������������������������������������������������������������������������������������� 11
Protection in case of accidental turning on ����������������������������������������������������������������� 12
Child safety ����������������������������������������������������������������������������������������������������������� 12
Timer function�������������������������������������������������������������������������������������������������������� 12
Timer starting ������������������������������������������������������������������������������������������������������� 12
Courtesy timer ������������������������������������������������������������������������������������������������������� 12
“HEAT-UP” fnction��������������������������������������������������������������������������������������������������� 12
Pause ������������������������������������������������������������������������������������������������������������������� 13
Recall function ������������������������������������������������������������������������������������������������������� 13
Heating to 42°c, 70°c, 95°c function ������������������������������������������������������������������������� 13
Pan presence recognition����������������������������������������������������������������������������������������� 13
Residual heat indication ������������������������������������������������������������������������������������������ 13
Key blocking/unblocking ����������������������������������������������������������������������������������������� 13
Power management ������������������������������������������������������������������������������������������������ 13
Overheating����������������������������������������������������������������������������������������������������������� 14
Limit of the duration of operation������������������������������������������������������������������������������ 14

3
GB
Advice when cooking����������������������������������������������������������������� 15
Pots���������������������������������������������������������������������������������������������������������������������� 15
Size of pots ����������������������������������������������������������������������������������������������������������� 15
Maintenance and cleaning ������������������������������������������������������� 16
Controls to carry out in case of malfunction���������������������������������������������������������������� 16
Installation ������������������������������������������������������������������������������������ 17
Respect for the environment ������������������������������������������������������������������������������������ 17
Instructions for installation �������������������������������������������������������������������������������������� 17
Electrical connection ���������������������������������������������������������������������������������������������� 18
Connecting cable to hob ������������������������������������������������������������������������������������������ 18

4
READ CAREFULLY BEFORE USING
• Only qualied technicians should install the appliance. The techni-
cian will not be held responsible for any damages caused by electri-
cal malfunctions�
• The hob must be installed in the appropriate inset�
• The appliance should be used solely for cooking foods, excluding any
other domestic or industrial uses�
• Remove the adhesive labels from the glass on the hob�
• Do not modify or alter the appliance�
• Do not use the hob as a working zone�
• The appliance must be connected and installed in compliance with
current local regulations�
• Do not use extension cables for connections�
• The appliance should not be used with pots and pans that are unsu-
itable for induction cooking�
USING THE APPLIANCE
• After use, switch off the hob by means of its control device and do
not rely on the cookware detector�
• WARNING: unattended cooking on a hob with fat or oil can be dan-
gerous and may result in re.
• WARNING: in the event of re never attempt to extinguish a ame/
re with water, but turn off the unit and cover the ame for example
with a lid or a re blanket.
Important safety warning

5
GB
• This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and under-
stand the hazards involved� Children shall not play with appliance�
• WARNING: Accessible parts may become hot during use� To avoid
burns young children should be kept away�
• Cleaning and maintenance must never be carried out by unsupervi-
sed children�
• Make sure that the power cable does not come into contact with the
glass or a pot�
• Magnetic objects such as credit cards, oppy disks, calculators,
should not be placed close to the working appliance�
• Do not use any metallic object except for cookware suitable for in-
duction�
• Do not cover the cooking area with inammable materials.
• The appliance must be used by responsible persons�
• Metallic objects such as knives, spoons, forks or covers should not
be placed on the cooking area as they can become hot�
• If the surface is cracked, switch off the appliance to avoid the possi-
bility of electric shock�
• The appliance is not intended for driven by an external timer or se-
parate remote control system�
• Do not use steam appliances for cleaning�
Important safety warning

6
PRECAUTIONS
• Unsuitable pots could ruin the surface of the hob�
• Do not use abrasive substances to clean the appliance�
• Avoid dropping heavy objects on the hob�
• Delicately place pots on the hob�
• Make sure that the appliance’s ventilation complies with the instruc-
tion manual�
• Do not place empty pots on the hob�
• Sugar, synthetic materials or aluminium objects should not come
into contact with the cooking zones�
• Avoid placing hot containers on top of the control panel�
• If there is a drawer or a panel under the hob, this must be at least
2,5 cm from the lower part of the hob to ensure proper ventilation�
• Do not place inammable objects inside the draw located under the
hob�
IN CASE OF MALFUNCTION
• When a malfunction occurs turn off and disconnect the appliance�
• If cracks appear on the glass or it is broken, disconnect the applian-
ce and contact your authorized service centre�
• Any repairs should be made by authorized personnel�
Important safety warning

7
GB
Important safety warning
SUGGESTIONS
• Make sure that the pot is in the middle of the cooking zone� Ideally,
the bottom of the pot should cover the entire cooking zone�
• The magnetic eld produced by the induction hob could affect the
proper working of pacemakers� Detailed information should be obtai-
ned from your doctor�
• Avoid placing synthetic materials or aluminium objects in contact
with the cooking zone�

8
Ventilation
Ventilation of the hob is completely automatic� The cooling fan for the electronics located under the hob works
at slow speed up to the temperature level of the electronics� When the hob is used for a long time the speed of
the cooling fan increases� As soon as the electronics have been cooled the fan stops automatically�
First switch-on
Clean the hob’s surface with a damp cloth�
Induction
There is a coil underneath each cooking zone which, when a pot is placed on it, generates a variable electro-
magnetic eld, producing inductive power of a ferromagnetic substance on the bottom of the pot. The end result
is that the bottom of the pot placed above the cooking zone becomes heated� The type of material constituting
the pot is fundamental:
• All pots with a ferromagnetic bottom are suitable (this can be veried with a magnet)
• The following pots should not be used: copper, stainless steel, aluminium, glass, wood, ceramics
Pot of magnetic material
Induction currents
Electromagnetic coil
General description

9
P1
P3 P5
P2 P4
GB
Control description
Zone
P1 P2 P3 P4 P5
Diameter
Ø
(mm)
W x H (P4/P5, mm)
260 145 180 200x164 200x164
Power (watt)
2600 1400 1850 2100 2100
Booster (watt)
3700 2200 3000 3700 3700
Displayed functions
Displayed
value Description
0 Zero - the cooking zone is turned on
1-9 Level of power - select the cooking level
u Presence of pot - absence of pot or unsuitable pot
u Heating function
A Automatic heating - Function of automatic cooking
E Error - Electronic anomaly
F Error - Cooking zone anomaly
H Residual heat - The cooking zone is hot
P Booster - Excess power in the cooking zone
II Pause - Pause active
U and Π Merging two zones - the two zones become a unique zone (P4 and P5)

10
Control description
Functions
17
16
15
14
13
96
5
10 11
12 3 1 2
8
4
7
1 ON/OFF button
2
Break function key
3
Key function key
4
Control timer +
5
Control timer -
6
Timer Display (selected time)
7
Display icon min�
8
Display clock icon
9
Display cooking area
10
Display icon timer
11
Display merge cooking areas (zones merge)
12
Display slider (bar graph)
13
Slider (slider)
14
Level 3 heating function (95 ° C)
15
Level 2 heating function (70 ° C)
16
Level 1 heating function (42 ° C)
17
Heating function
