Ikelite 69740 Manual de usuario

200DLM/A Underwater Housing for Canon EOS

M50, M50 Mark II, Kiss M

Product # 69740

Introduction

Thank you for your purchase of Ikelite products.

Our primary focus is to provide quality, professional grade products

for use in and under water. Our products are designed, manufactured,

and distributed from our sole facility in Indianapolis, USA where we

started in 1962.

We are available if you have any questions or want photo advice.

Send us an email 24 hours a day to [email protected]. We strive to

reply within 1 business day.

An electronic version of this instruction manual is available for

download via the product page on our website:

https://www.ikelite.com

In the Box

• Housing

• Rear o-ring # 0110 (installed)

• Front o-ring # 0132.36 (installed)

• .050” hex key # 0945.11

• 1/16” hex key # 0945.16

• Silicone lubricant 1cc tube

Important Notices

»This housing requires a compatible DLM lens port for

waterproof operation. The housing is not waterproof without a

DLM lens port attached.

»A bulkhead cap or sync cord must be attached to the housing

bulkhead for waterproof operation. Never submerge the

housing in water without either a sync cord or bulkhead cap

attached.

»Do not pull the shutter trigger without a camera installed. You

may accidentally detach or damage the control spring.

»Never leave a housing in a rinse tank, even if it is the only

system in the tank. Accidental damage may occur when the

user walks away from a housing while it is in the rinse tank.

»Do not use alcohol, cleaning agents, spray lubricants, Rain-X,

or other solvents on the housing or lens port. Use of an

incompatible chemical compound can damage the plastic and

o-rings, and may result in leaking.

»If you will be using the system in strong surf it is

recommended to draw a vacuum on the housing using the

optional vacuum kit (sold separately).

Contents

Introduction 2

In the Box 2

Important Notices 3

Getting to Know Your Housing 6

Tray Mounts 8

Accessory Ports 8

Trigger Extension 8

Setting Up Your Camera 9

Pre-Installation Checklist 9

Camera Settings 9

Exposure Settings 9

Setting Up Your Housing 10

Opening the Housing 10

Installing the Camera 10

Closing the Housing 11

Attaching a Lens Port 12

Installing the Lens and Port 12

Setting Up An External Strobe 15

Manual Strobe Exposure 15

TTL Strobe Exposure 15

Getting in the Water 16

Final Check 16

Entering the Water 16

Shooting Underwater 17

Learning about Underwater Photography 17

Maintaining Your Housing 18

Post-Dive 18

Lens Port 18

Storage 19

Servicing Recommendations 19

Lubricating Controls 20

Lubricating Push Buttons 20

Lubricating Control Shafts 21

Troubleshooting 23

Spare Parts 25

Limited Warranty 25

Service and Repairs 25

Getting to Know Your Housing

Shutter

Accessory

ports

Lid snap

Tray mounts

Lens

release

Port mount

Movie

Main dial

Multi-Function

button

CANON M50 I & II / 200FT

69740 MADE IN USA

INFO

Viewnder

Rear o-ring

CANON M50 I & II / 200FT

69740 MADE IN USA

INFO

Left

Playback

Lid

snap

hook

Up / Exposure

compensation

Down / Erase

Right / Flash

Power

switch

Information

Mode dial

AE Lock

AF Point

Selection

Tray Mounts

This housing features two 1/4-20 threaded tray mounts on the bottom

of the housing. The spacing between the tray mounts is 3” (76.2 mm).

Optional tray with handles and mounting hardware are sold separately.

It is recommended to detach and thoroughly rinse the tray mounts,

tray, and mounting hardware, with fresh water routinely during

continuous use and prior to storage.

Accessory Ports

This housing features a spare accessory port which may be used

for the attachment of optional accessories. This port accepts ttings

designed for a 1/2” through or 1/2-20 threaded hole.

The optional Vacuum Kit # 47012 may be installed in place of the side

accessory port. A hand pump with gauge allows you to draw a vacuum

on the house to simulate water pressure and check for leaks prior to

entering the water.

Visit ikelite.com for an updated list of compatible products.

»Do not remove or loosen the accessory port plug unless you

are installing a compatible accessory.

Trigger Extension

The shutter lever may be extended to be closer to your hand when

using an optional tray with right-hand quick release handle. This

requires the Trigger Extension # 4077.95.

Trigger extension and tray with quick release handle are sold

separately.

Setting Up Your Camera

Pre-Installation Checklist

1. Insert a fully charged camera battery.

2. Insert a properly formatted memory card.

3. Remove any attached lanyard or neck strap.

Camera Settings

• Set Flash ring to “On” when using an external strobe.

• Set AF assist beam to “Off” when using an external strobe.

• Set Red-eye reduc. to “Off” when using an external strobe.

Exposure Settings

Refer to the Cheat Sheets in the Photo School section of our website

for recommendations on exposure settings for a wide variety of

shooting situations:

https://www.ikelite.com/blogs/cheat-sheets

Setting Up Your Housing

Opening the Housing

1. Push the lid snap lock forward and lift the curved end away from

the housing.

Lock

2. Lid snaps are designed to provide enough force to compress the

o-ring for a proper seal. Keep rm pressure against the lid snap

while lifting it away.

3. Repeat with opposite lid snap.

4. Remove the housing back.

Installing the Camera

1. Remove any lanyard or neck strap which may be attached to the

camera.

2. Remove the camera mount plate from the housing.
