ikeGPS IKE 4 Manual de usuario
IKE 4 user manual 1
IKE 4
user manual
Copyright © 2016 IKEGPS LTD.
IKE4-000-00-00-1.0
2 IKE 4 user manual
Visit http://ikegps.com/ike-4/ for
software updates • manuals • tutorials • videos
IKE 4 user manual 3
contents
introduction X
what’s in the box X
IKE 4 system overview X
system setup X
IKE 4 tripod X
IKE Field – how it works
IKE Field X
4 IKE 4 user manual
Introduction
Thank you for purchasing the IKE 4 Your IKE 4 is a location-based measuring solution that will
greatly increase your productivity when undertaking utility asset management surveys and
mobile computer, and precision GPS.
With your IKE solution you can quickly:
Collect geo-located pole photos
Measure wire span heights, even across busy roads
Determine wire clearances from vegetation or buildings
Make accurate attachment height measurements on captured photos
This document will guide you through:
Setting up your IKE system
Measuring attachment heights from a photo
IKE 4 user manual 5
1IKE device
2USB car charger
3power cable
4micro USB cable
5AC charger with plug adapter
6screwdriver
7shoulder strap for hard case
8hard case (not shown)
A SIM card and SD card are not included.
IMPORTANT: The IKE 4 device is
designed to be used with the IKE Tripod.
It should not be used while being held by
hand or placed close to the user’s body.
6
5
1
2
3
7
4
What’s in the box
1LCD display 7camera
2power button 8laser receive lens
3power port 9laser transmit lens
4USB port 10 stylus pen thread
5volume buttons 11 tripod screw thread
6
1
2
3
4
11
10
9
8
7
6
5
WARNING This equipment complies with FCC radiation exposure
limits set forth for an uncontrolled environment. In order to avoid the
possibility of exceeding the FCC radio frequency exposure limits,
human proximity to the antenna shall not be less than 20cm during
normal operation.
WARNING This device contains an eye safe class 1M laser product.
Invisible laser radiation is emitted from (and received into) the front
apertures. Avoid staring into the laser beam. This product complies with
IEC60825-1 Ed 2.0 and 21CFR1040.10 except for deviations pursuant to
Laser Notice No.50, dated July 26 2001.
CAUTION Use of controls or adjustments, or performance of
radiation exposure.
WARNING LASER RADIATION
DO NOT EXPOSE USERS OF TELESCOPIC OPTICS
CLASS 1M LASER PRODUCT
6 IKE 4 user manual
IKE 4 system overview
Plan
Capture Make measurements and capture data in your
forms using the IKE Field device
Upload
Measure
pole attachment heights
Export Export your collections to one of the following
formats: KML, JSON, PDF or SPIDA
IKE 4 user manual 7
system setup
IKE 4 software
accurate photo measurements and save marked-up photos.
IKE Field
Your device has been shipped with the latest factory software — your installed version shows
on the IKE Field device main screen. However, the team at IKE regularly makes product
improvements. Updates will be delivered to your device via the Google Play store. You only need
to update the software when prompted, and you will stay up to date.
IKE 4 documentation
IKE 4 setup guide
IKE 4 user manual (this guide)
The most comprehensive A-Z guide to using your IKE device
How to get the best results from your IKE, tips and tricks to improve performance, accuracy,
and productivity
additional software
• Google Earth™ – View your data and measurements by clicking on their location on aerial
photographs.
8 IKE 4 user manual
IKE 4 tripod
Your device is designed to be used with the IKE 4
tripod, which provides a stable platform to obtain
the most accurate results when measuring objects
such as target poles and wires. The tripod has a
low magnetic signature that will not affect the IKE
device’s compass, which helps provide accurate
measurements.
Important: Tripods other than the IKE tripod will likely
produce less accurate results than the IKE tripod.
IKE Field – how it works
IKE 4 user manual 9
IKE Field
IKE Field
Signing In
Settings
Creating a job
Downloading forms
Starting a collection
Viewing the map
Uploading data
Making measurements
signing In
This user information will be saved, so the next time
the application is opened it will already be logged in
to the most recent account.
10 IKE 4 user manual
settings
After turning on the IKE, navigate to the device’s
Settings.
There are four (4) separate Settings sections:
• Wireless & networks
• Device
• Personal
• System
Wireless & networks
• Wi-Fi — touch Wi-Fi, and then touch the slider
to move it to the On position. Chose a wireless
connection.
• Turbo download — touch Turbo download to
Fi and 4G/3G networks simultaneously. Touch the
slider to move it to the On position.
• Bluetooth — touch Bluetooth, and then touch
the slider to move it to the On position. Choose a
Bluetooth device
• Data usage — touch Data usage to check daily
and total data usage. Default is OVERVIEW. Touch
Wi-Fi to view app usages. Touch available monthly
segments to compare across time.
