Ikan Multi-K Manual de usuario

INTRODUCTION

Thank you for purchasing the ikan Multi-K. The Multi-K is extremely easy to use and will quickly become an

integral part of your production kit. For more information on this and many other innovative ikan products, please visit our

website: www.ikancorp.com.

PACKAGE CHECK LIST

Multi-K Light

Camera shoe mount

AC Adapter

GETTING STARTED

1. Power on the light using the Main Power switch

2. Control the amount of light with the Dimmer Knob clock-wise until you hear a “click”.

3. Turn the light off by twisting the Dimmer Knob counter clock-wise unit you hear a “click”.

4. The Multi-K can also be powered by the included AC adapter.

5. Adjust to desired color temperature

ADJUSTING THE BRIGHTNESS

The Dimmer Knob on the top of the light allows you to adjust the intensity of the light. Adjust the intensity of the light by

turning the Dimmer Knob clock-wise to increase the intensity and counter clock-wise to reduce it.

12v -18v Power

CONDITIONS OF WARRANTY SERVICE

• Free service for one year from the day of purchase if the problem is caused by manufacturing errors.

• The components and maintenance service fee will be charged if the warranty period has expired.

Free Service will not be Provided in the Following Situations: (* Even if the product is still within the warranty period.)

• Damage caused by abuse or misuse, dismantling, or changes to the product not made by the company.

• Damage caused by natural disaster, abnormal voltage, and environmental factors etc.

Power on / Dimmer knob

144 LED bulbs

¼-20 threaded hole

color temperatures

QUICK START GUIDE / Multi-K

Power

2800’ x

3200’ x

4000’ x

4800’ x

5600’ x

8500’ x

Checked by

Specifications:

• 2800°k - 6500°k Color Range

• DC12 - 18v

• Input: 6 x AA Batteries

• Weight: .8 lbs

• Dimensions: L 4.9” x W 4.3” x H 1.6”

Color temperature switch

6 AA Battery option

Back view

Front view

Side view

QUICK START GUIDE / Multi-K

The right amount of light

The ID 500 lux drop off

2800 K 3200 K 4000 K

4800 K 5600 K 6500 K

1 meter

3 meters

5 meters 1 fc / 10 lux

4 fc / 40 lux

168 fc / 1680 lux

1 meter

3 meters 4 fc / 40 lux

5 meters 2 fc / 20 lux

44 fc / 440 lux

1 meter

3 meters 5 fc / 50 lux

5 meters 2 fc / 20 lux

40 fc / 400 lux

1 meter

3 meters 3 fc / 30 lux

5 meters 1 fc / 10 lux

35 fc / 350 lux 1 meter

3 meters 3 fc / 30 lux

5 meters 1 fc / 10 lux

30 fc / 300 lux 1 meter

3 meters 2 fc / 20 lux

5 meters 1 fc / 10 lux

27 fc / 270 lux
