Ikan PSB10 Manual de usuario

www.ikancorp.com | 1.713.272.8822 | [email protected] because we’re ﬁlmmakers too

PSB10

Quick Start Guide

Presto Soft Boxes for 1 x 1 LED Lights

What’s Included

1 x Soft box

1 x Egg crate

1 x Storage pouch

www.ikancorp.com | 1.713.272.8822 | [email protected] because we’re ﬁlmmakers too

Getting Started

Thank you for buying the Presto Soft Box from Ikan. Please carefully read the instructions and guide before operating the products. The guide includes

product usage and maintenance. When you operate the product, please make sure that you have read the instructions carefully. All the content of the

manual is based on up-to-date information; technical data subject to change without notice.

Step-by-Step Guide to preparing and installing your Presto Soft Box

Step 1: Remove the Presto soft box from the

carrying pouch. (Note: be careful that the box

doesn’t spring open when removing it from

carrying pouch.)

Step 4: Check the inside of the soft box to make

sure that all of the material is fully expanded

and there are no cuts or openings.

Step 7: (Optional) The included egg crate can

be placed on the soft box to allow the soft light

to be more controlled with less light spill.

Step 2: Gently allow the frame of the soft box

to open and take shape. This allows the box to

take shape and start forming the frame.

Step 5: Placing the soft box on the light and

ﬁtting it into place. The soft box will slip over

the barn doors and slid around the edges of the

light. The back ﬂaps will ﬁt around the light and

the hook straps will attach to the loop patches

on the side ﬂaps.

Step 3: Straighten the rods at each corner of

the box. Allow the magnets to attach and form a

solid rod locking the box in open position.

Step 6: Once the back ﬂaps have been set take

the two long elastic straps and attach them over

the back of the light. (Note: Pushing the barn

doors out from the front of the box through the

diffusion will allow the box to stay on better.)

www.ikancorp.com | 1.713.272.8822 | [email protected] because we’re ﬁlmmakers too

Speciﬁcations

Compatibility

The PSB10 Presto Soft Box is compatible with the following Ikan lights:

LB10

LBX10

LW10

LWX10

RB10

RBX10

RW10

RWX10

Lyra Bi-Color 1 x 1 LED Panel

Lyra Bi-Color 1 x 1 LED Panel w/ DMX Control

Lyra Daylight 1 x 1 LED Panel

Lyra Daylight 1 x 1 LED Panel w/ DMX Control

Rayden Bi-Color 1 x 1 LED Panel

Rayden Bi-Color 1 x 1 LED Panel w/ DMX Control

Rayden Daylight 1 x 1 LED Panel

Rayden Daylight 1 x 1 LED Panel w/ DMX Control

Shipping Weight 3 lb

Shipping Dimensions 10 x 10 x 4 in

Product Weight 2 lb

Operational Dimensions 21 x 21 x 8 in

Build Material Canvas, Metal, Rayon

Learn More

More dynamic information at ofﬁcial website: www.ikancorp.com

Support

Contact email: [email protected]

CONDITIONS OF WARRANTY SERVICE

• Free service for one year from the day of purchase if the problem is caused by manufacturing errors.

• The components and maintenance service fee will be charged if the warranty period is expired.

Free Service will not be Provided in the Following Situations:(*Even if the product is still within the warranty period.)

• Damage caused by abuse or misuse, dismantling, or changes to the product not made by the company.

• Damage caused by natural disaster, abnormal voltage, and environmental factors, etc.
